供应 贴片保险丝 0603FA 巴斯曼BUSSMANN CC06H
| 价 格： | 面议 | |
| 型号/规格： | 0603 | |
| 品牌/商标： | BUSSMANN（巴斯曼） |
Features
- Halogen free
- High inrush withstand capability
- Fast-acting performance
- RoHS compliant
- Lead free
- Capacity alpha mark on fuse for easy identification
- Standard termination design for easy solder ability
- Compatible with standard lead-free solder reflow and wave soldering processes
- Excellent environmental integrity
|
Catalog Number |
Amp Rating5 |
Alpha Marking |
Voltage Rating Vdc |
Interrupting Rating (amps)1, 4 |
Typical Resistance (Ω)2 |
Typical Melt I2t3 |
Typical Voltage Drop (V) |
Typical Power Loss (W) |
Agency Approvals cRUus |
|
CC06H1A |
1 |
B |
32 |
50 |
0.225 |
0.02 |
0.295 |
0.3 |
x |
|
CC06H1.5A |
1.5 |
H |
32 |
50 |
0.122 |
0.07 |
0.22 |
0.33 |
x |
|
CC06H2A |
2 |
K |
32 |
50 |
0.061 |
0.2 |
0.16 |
0.32 |
x |
|
CC06H2.5A |
2.5 |
L |
32 |
50 |
0.045 |
0.25 |
0.145 |
0.36 |
x |
|
CC06H3A |
3 |
O |
32 |
50 |
0.027 |
0.3 |
0.11 |
0.33 |
x |
|
CC06H3.5A |
3.5 |
R |
32 |
50 |
0.021 |
0.6 |
0.1 |
0.35 |
x |
|
CC06H4A |
4 |
S |
32 |
50 |
0.018 |
1 |
0.1 |
0.4 |
x |
|
CC06H5A |
5 |
T |
32 |
50 |
0.013 |
2 |
0.088 |
0.44 |
x |
1. DC Interrupting Rating (measured at rated voltage, time constant of less than 50 microseconds, battery source).
2. DC Cold Resistance are measured at <10% of rated current in ambient temperature of 20ºC - FOR REFERENCE ONLY - CONTROLLED VALUES HELD BY PLANT AND SUBJECT TO CHANGE WITHOUT NOTICE.
3. Typical Pre-arching I2t are measured at 10In current.
4. The insulation resistance after breaking capacity test is higher than 0.1MΩ when measured by 2X rated voltage.
5. Device designed to carry rated current for 4 hours minimum. An operating current 80% or less of rated current is recommended, with further design derating required at elevated ambient temperature. See Temperature Derating Curve on next page.
