供应amp5227222-9 bnc连接器

价格：		面议
型号/规格：		5227222-9
品牌/商标：		MITSUMI（日本美上美）

详细介绍
企业详情

品牌	AMP	型号	5227222-9
接头形式	/	应用范围	电脑
接口类型	USB

Product Type Features:

Product Type= Connector Kit
Connector Type= BNC
Gender= Jack
Body Style= Straight
PCB Mount Angle= Vertical
Grade= Commercial
PCB Height (mm [in])= 34.93 [1.375]
PCB Retention Feature= Yes
Mounting Post Style= Standard
Mounting Post Length (mm [in]) = 1.85 [0.073]
Body Material= Polyester, PBT
Body Insulation= Without
Sealed= No
Isolated= No
Dielectric Material= Polymethylpentene
Color= Natural
Number of Ports = 1
Solder Terminal = Without
Comment = If an Insulating Bushing is required, see Part Number 330620.; Lockwasher and Jam Nut included.

Mechanical Attachment:

Surface Mountable = No
Panel Attachment= With
Panel Attachment Method = Lockwasher and Nut
Panel Attachment Style = Rear Mount

Electrical Characteristics:

Connector Impedance (?)= 50

Body Related Features:

Hardware Included= Yes
PCB Retention Method= Hold Down Post
Polarized= No

Contact Related Features:

Center Contact Material= Phosphor Bronze
Center Contact Plating= Gold

Industry Standards:

Government/Industry Qualification = No
RoHS/ELV Compliance= RoHS compliant, ELV compliant
Lead Free Solder Processes= Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS compliant

Conditions for Usage:

Terminate To= Printed Circuit Board

Other:

Brand = AMP
