现货UL认证固态继电器Crydom进口继电器SSR
| 价 格： | 123.45 | |
| 型号/规格： | Crydom | |
| 品牌/商标： | Crydom |
现货UL认证固态继电器Crydom进口继电器SSR
全国400热线4006-022-002 咨询Crydom继电器：
固态继电器原理 什么是固态继电器
直流固态继电器 VDE认证固态继电器资料
CE认证固态继电器型号 固态继电器交流
SSR固态继电器 固态继电器价格
欧姆龙固态继电器 三相固态继电器
1200V隔离
SCR输出
零电压开关或瞬时开关
EMC标准设计
Panel Mount AC Output CW 48 Series
Ratings from 10A to 125A @ 48-660 VAC - AC or DC control
The newest family to the SSR range;
Ratings from 10A to 125A @ 48-660 VAC
- SCR output for heavy industrial loads - EMC Compliant for reliable operation in harsh environments
- Removable IP 20 touch-safe cover
- DBC substrate for superior thermal performance - LED input status indicator
- AC or DC input - Zero-crossing (resistive loads)
or random-fire (inductive loads) output
Part Number Control Voltage Range Maximum Load Current Operating Voltage Range Input Type PDF
Part Number Control Voltage Maximum Load Current Line Voltage Range Specification PDF Check Stock
CWA4810 90-280 VAC 10 Amps 48-660 VAC
CWA4810-10 90-280 VAC 10 Amps 48-660 VAC
CWA4810E 18-36 VAC 10 Amps 48-660 VAC
CWA4810E-10 18-36 VAC 10 Amps 48-660 VAC
CWA4825 90-280 VAC 25 Amps 48-660 VAC
CWA4825-10 90-280 VAC 25 Amps 48-660 VAC
CWA4825E 18-36 VAC 25 Amps 48-660 VAC
CWA4825E-10 18-36 VAC 25 Amps 48-660 VAC
CWA4850 90-280 VAC 50 Amps 48-660 VAC
CWA4850-10 90-280 VAC 50 Amps 48-660 VAC
CWA4850E 18-36 VAC 50 Amps 48-660 VAC
CWA4850E-10 18-36 VAC 50 Amps 48-660 VAC
CWA4890 90-280 VAC 90 Amps 48-660 VAC
CWA4890-10 90-280 VAC 90 Amps 48-660 VAC
CWA4890E 18-36 VAC 90 Amps 48-660 VAC
CWA4890E-10 18-36 VAC 90 Amps 48-660 VAC
CWA48125 90-280 VAC 125 Amps 48-660 VAC
CWA48125-10 90-280 VAC 125 Amps 48-660 VAC
CWA48125E 18-36 VAC 125 Amps 48-660 VAC
CWA48125E-10 18-36 VAC 125 Amps 48-660 VAC
CWD4810 4-32 VDC 10 Amps 48-660 VAC
CWD4810-10 4-32 VDC 10 Amps 48-660 VAC
CWD4825 4-32 VDC 25 Amps 48-660 VAC
CWD4825-10 4-32 VDC 25 Amps 48-660 VAC
CWD4850 4-32 VDC 50 Amps 48-660 VAC
CWD4850-10 4-32 VDC 50 Amps 48-660 VAC
CWD4890 4-32 VDC 90 Amps 48-660 VAC
CWD4890-10 4-32 VDC 90 Amps 48-660
CWD48125 4-32 VDC 125 Amps 48-660 VAC
CWD48125-10 4-32 VDC 125 Amps 48-660 VAC Spec Document
- 所属城市：北京 北京市
- [联系时请说明来自维库仪器仪表网]
- 联系人： 关生
- 电话：010-68008911
- 传真：010-68008901
- 手机：4006-022-002
- QQ ：
CRYDOM固态继电器SSR固态继电器D2440快达固态继电器
信息内容：CRYDOM固态继电器SSR固态继电器D2440快达固态继电器全国400热线4006-022-002快达固态继电器280V AC/40A, 3-32V DC固态继电器SSR280VAC/25A, 3-32V DC 直流控制 Independently controlled dual output solid-state relay Ratings from 25A to 40A @ 24-530 VAC Industry standard package SCR output for heavy industrial loads DC Control Zero-crossing (resistive loads) or random-fire (inductive loads) output安装方式 Chassis Mount 端子 Screw Terminal 包装 Hockey Puck 电路 SPST-NO (1 Form A) 负载电流 50A 电压 - 输入 3 ~ 32VDC 电压 - 输出24 ~ 280 V 输出方式 AC,过零输出固态继电器无铅，RoHS Status RoHS CompliantD2425D-10; D2425DED2425DE-10; D2440DD2440D-10; D2440DED2440DE-10; H12D4825DH12D4825D-10; H12D4825DEH12D4825DE-10; H12D4840DH12D4840D-10; H12D4840DEH12D4840DE-10D2402 Obsolete use D2410D2410 PM IP00 280VAC/10A, 3-32VDC In, ZCD2410-10 PM IP00 280VAC/10A, 3-32VDC In, RND2410-B PM IP00 280VAC/10A, 3-32VDC In, ZCD2410F PM IP00 280VAC/10A, 3-32VDC In, ZCD24110 PM IP00 280VAC/110A, 3-32VDC In, ZCD24110-10 PM ...
D2425固态继电器CRYDOM固态继电器SSR快达固态继电器
信息内容：D2425固态继电器CRYDOM固态继电器SSR快达固态继电器全国400热线4006-022-002快达固态继电器固态继电器SSR280VAC/25A, 3-32V DC 直流控制 Independently controlled dual output solid-state relay Ratings from 25A to 40A @ 24-530 VAC Industry standard package SCR output for heavy industrial loads DC Control Zero-crossing (resistive loads) or random-fire (inductive loads) output安装方式 Chassis Mount 端子 Screw Terminal 包装 Hockey Puck 电路 SPST-NO (1 Form A) 负载电流 50A 电压 - 输入 3 ~ 32VDC 电压 - 输出24 ~ 280 V 输出方式 AC,过零输出固态继电器无铅，RoHS Status RoHS CompliantD2425D-10; D2425DED2425DE-10; D2440DD2440D-10; D2440DED2440DE-10; H12D4825DH12D4825D-10; H12D4825DEH12D4825DE-10; H12D4840DH12D4840D-10; H12D4840DEH12D4840DE-10D2402 Obsolete use D2410D2410 PM IP00 280VAC/10A, 3-32VDC In, ZCD2410-10 PM IP00 280VAC/10A, 3-32VDC In, RND2410-B PM IP00 280VAC/10A, 3-32VDC In, ZCD2410F PM IP00 280VAC/10A, 3-32VDC In, ZCD24110 PM IP00 280VAC/110A, 3-32VDC In, ZCD24110-10 PM IP00 280VAC/110A, 3-3...
