SMA射频同轴连接器SMA-KF3
| 价 格： | 面议 |
品牌:国产 型号:SMA-KF-3 应用范围:通讯 种类:射频同轴(RF) 接口类型:SMA 接触件材质:黄铜 绝缘体材质:聚四氟乙烯
SMA连接器
| dzsc/18/1943/18194316.jpg |
| MALE | FEMALE | |||||
| Min | Max | Min | Max | |||
| A | 1.245 | 1.295 | 1.245 | 1.295 1)2) | A | |
| B | 4.178 | 4.178 1) | B | |||
| C | 4.59 | 4.60 | 4.67 | C | ||
| D | 2.54 | 1.68 | 1.98 | D | ||
| E | 0.902 | 0.940 | 5.28 | 5.49 | E | |
| F | 1/4-36UNS-2B | 1/4-36UNS-2A | F | |||
| G | 3.43 | 4.32 | G | |||
| H | HEX 5/16’ | 0.05 | H | |||
| I | 0.05 | 0.25 | I | |||
| 1)Contact diametes refer to 50 Ohm | ||||||
| 2)resilient dim.To meet electrical and mechanical requirements | ||||||
适用标准 GB11316-89
IEC60169-15
MIL-C-39012
| Technical Characteristics | 技术参数 |
| Electrical characteristics | 电气性能 |
| 图片 Photo | 型号 Type | 配用电缆 Cable | 尺寸 Dimension | 图形 Figure | ||
| D | d | L | ||||
| dzsc/18/1943/18194316.jpg | SMA-KF3 | SYV-50-2-1 | Φ3.2 | 22 | dzsc/18/1943/18194316.jpg | |
| SFF-50-1.5-1 | ||||||
| SMA-KF4 | SYV-50-2-2 | Φ4.2 | 22 | |||
| SFF-50-2-1 | ||||||
| SMA-KF5 | SYV-50-3 | Φ5.3 | 24 | |||
| SFF-50-3-1 | ||||||
