品牌:国产 型号:防水连接器, BNC ,RF连接器,RF连接线,电缆接头,视频监控线,BNC-KY BNC Bulkhead Jack crimp type 应用范围:通讯 种类:射频同轴(RF) 接口类型:BNC 形状:圆形 制作工艺:车削 特性:防水 接触件材质:Brass 铜 绝缘体材质:PTFE (聚四氟乙烯) 芯数:1 针数:1

BNC系列射频同轴连接器
SERIES RF COAXIAL CONNECTORS

BNC系列是一种卡口连接射频同轴连接器。它具有连接迅速，接触可靠等特点，广泛应用于无线电设备和电子仪器领域连接射频同轴电缆。

BNC series are one kind of cards of thing the mouth join the radio frequency coaxial connection device. It joins rapidly, keeps in touch with the characteristic such as being reliable, apply to the radio equipment and el

BNC 系列连接器设计于二十世纪四十年代。BNC（Bayonet Navy Connector）系列连接器具有特殊的卡口式连接方式，它的插座上有两个卡销，连接时只需把连接螺母转动 1/4圈即可锁定连接器。BNC 系列连接器适合需要频繁插拔的场合。

BNC 系列连接器可适配多种同轴电缆，如 RG-58，59，到 RG-179，RG-316 等。BNC系列连接器是应用最广泛的连接器之一。

界面尺寸 INTERFACE MATING DIMENSIONS

主要技术特性 TECHNICAL CHARACTERISTICS
温度范围 Temp.range -65～+165°C (PE Cable -40～+85°C)
振 动 Vibration MIL-STD-202, Method 213
特性阻抗 Impedance 50Ω, 75Ω
频率范围 Frequency Range DC～4GHz
工作电压 Working Voltage 500V max (有效值)
耐 压 Withstand Voltage 1500V rms (海平面最小值)
接触电阻 Contact resistance
内导体之间 Center Contact ≤ 1.5 mΩ
外导体之间 Outer Contact ≤ 1 mΩ
绝缘电阻 Insulation resistance ≥ 5000 MΩ
电压驻波比 VSWR 直式 Straight ≤ 1.22
弯式 Right angle ≤ 1.30
耐用性 Durability(mating) ≥500次（cycles）

材料与涂覆 MATERIAL & PLATING
壳体 shell 黄铜 brass 镀亮镍 nickel plated
插针 contact pin 黄铜 brass 镀硬金或银 gold or silver plated
插孔 socket 铍青铜 beryllium 镀硬金或银 gold or silver plated
弹性接触件elastic contact 铍青铜 beryllium 镀硬金或银 gold or silver plated
绝缘体 insulator 聚四氟乙烯 PTFE
压接套 crimp ferrule 铜合金 copper alloy 镀镍或镀金 nickel plated
o型密封件o-ring sealing 硅橡胶 6146 silastic

适用技术标准 APPLICABLE STANDARD
MIL-C-39012;
CECC 22120;
IEC 60169-8.

应用范围：

1：天线

2：交换设备

3：基站应用

4：电缆组件

7：数据通讯系统

8：无线通信系统

9：电信系统

10：GPS

11：计算机/局域网

12：示波器

13：网络应用

14：航空航天

15：卫星通信

16：检测仪器

17：电缆调制解调器

1.型号: BNC-C-KY

2.接口: BNC；

3. BNC-C-KY 同轴连接器材质:壳体黄铜(Brass) ,绝缘子:聚四氟乙烯(PTFE) ,针: 磷铜

4. BNC-C-KY 同轴连接器 特性阻抗:50 欧姆；

5.BNC-C-KY 同轴连接器 加工方式:车削；

6.BNC-C-KY 同轴连接器连接形式: 卡口连接型连接器, 内导体焊接,外导体压接；

7.BNC-C-KY 同轴连接器 相配电缆:RG58

8.BNC-C-KY 同轴连接器 净重:

9.BNC-C-KY 同轴连接器 电镀涂覆(镀层): 外壳镀镍/中心针镀纯金

产品应用:监控系统 监控安装 监控方案 监控摄像头信号线 CCTV 安装 /CCTV系统/ Monitor/ video 安防延长线，架设小型安防系统最理想的线缆/无线电设备和电子通信仪器中连接射频电缆和微带线/ 无线监控数字微波通信天线

RF 同轴跳线NEW: N 母头-RG223 , 1米 -TNC 公头

N 母头-RG223 , 1米 -BNC 公头

RF Cable assemblies recently produces : N Female to BNC Male straight RF Cable Jumper

Production according to customer's requirements ( RoHS Compliant ) Interface : BNC

FINISH (PLATING THICKNESS IN MICRO-INCHES):

1.Body: GOLD PL.0.8μ"MIN. OVER NICKEL PL.100μ" MIN. THICK OVER COPPER STRIKE or your request

1.Body: NICKEL PL.100μ" MIN. THICK OVER COPPER STRIKE or your request

2.Contact pin: GOLD PL.0.8μ"MIN. OVER NICKEL PL.100μ" MIN. THICK OVER COPPER STRIKE or your request

3.Application: Antenna /CCTV/VIDEO/MONITOR /RF INTERCONNECT

4.Packaging: 4 PCS/ Per valve bag or your request

5.Material: Body: brass or your request Pin: brass or Phosphor Bronze or beryllium Bronze or your request Insulator: PTFE Or your request

6.Product name: RF Connector for RG58 Cable with BNC FEMALE

7.Match cable : RG58/3D-FB Coaxial Cable

8.Primary Competitive Advantages:

● Packaging

● Price

● Product Features

● Product Performance

● Prompt Delivery

● Quality Approvals

● Reputation

● Service

● Green product

● Brand-name Parts

● Country of Origin

● Experienced Technical Staff

● Specifications

● OEM and ODM
9.product range:universal model for international purpose: SMA、SMB、SMC、MCX、MMCX、SSMA、SSMB、SSMC、BNC、TNC、N、CC4 series which meet the technical standards of IEC169、MIL-C-39012、DIN;RF Coaxial Connector, model L6、Q6、L8、L10、L12、L16、SL16、L9、Q9、TAC、FL10 which meet the standards of GB and SJ as well as all kinds of cable assemblies and jumpers.

Please feel free to contact me

10. Contact us : zjhwrf@zjhwrf.cn MSN:yoyuurwiuri@hotmail.com QQ:412725925

11. Production Capacity (Supply Ability): 200000 pcs/per month

12. Stock :yes

13. Sample requested :yes

14. After service: Production of all products according to customer's requirements ,such as belonging to the company confirmed the issue of product quality can be returned without conditions, or customer request for a change to meet the requirements of the product.
