供应CBB61 250v-25uf压缩机空调电容器
| 价 格： | 面议 |
品牌:容鑫 型号:CBB61 介质材料:有机薄膜 应用范围:低压 外形:长方形 功率特性:小功率 频率特性:低频 调节方式:微调 引线类型:同向引出线 允许偏差:±5（%） 耐压值:250（V） 标称容量:25uf 损耗:≤0.002 额定电压:250（V） 额定电流:1（A）
dzsc/18/1912/18191226.jpgdzsc/18/1912/18191226.jpg电容器特点：具有损耗小、抗湿性强、电气性能优良、可靠性好、容量大、使用寿命长和良好的自愈性能。
capacitors Features：With a small loss,anti-moist,excellent electrical performance,reliability,large capacity,long life and good self-healing properties.
产品用途：适用于频率50Hz(60Hz)的交流电源供电的单相电机启动和运行，主要是电风扇、抽油烟机的理想配套组件，有助于单相交流电动机的起动和运转。另该产品也广泛由于节电设备中。Capacitors Use：AppIied to starting and better working of single-phase motor in 50Hz(60Hz) AC electric power system. It is widely used for electric fan,range hood,air exchange fan,washing machine, and also power saver.
1、技术参数technical parameters：
| 容量 Capacitance Range | 0.47μF—35μF |
| 容量偏差 Capacitance Tolerance | ±5% , ±10% |
| 额定电压 Rated Alternate Voltage | 250VAC, 350AC, 370AC, 400VAC, 440VAC, 450VAC,500VAC |
| 额定频率 Rated Frequency | 50/60 Hz |
| 损耗角 Dissipation Factors | ≤0.002（1KHz，20℃） |
| 使用温度 Operating Temp. | -40℃ ~ +85℃ or -40℃ ~ +70℃ |
| 外壳材料 Case Material | PBT, PP, Aluminium, Flammability Class - UL 94 V -2, 750C (RTI) |
| 电介质Dielectric | Polypropylene with self healing SH |
| 绝缘电阻 Insulation Resistance | ≥3000S |
| 气候类别 Weather Category | 40/85/21, 40/70/21 |
| 引出端电压 Withstand voltage(Terminal to Terminal) | 2 X Rated Voltage |
| 引出端与外壳间电压 Withstand voltage (Terminal to Case) | Minimum 2000 V AC for 1 Min. |
| 参考标准Ref. Standard | IEC - 252-1993 |
| 质量体系Quality System | ISO 9001：2008 |
| 认证证书Approvals | CQC,CE |
| 应用范围Application | Electrical motor, pump, washing machine, Power saver |
2、外形尺寸overall dimensions：
特殊规格可以按照客户要求Special specs are available on request
| L×H×B（mm） | L×H×B（mm） | L×H×B（mm） | ||
| 32×10×20 | 47×17.5×34.5 | 47×22×34.5 | ||
| 32×11×22 | 47×20×37.5 | 47×18×41 | ||
| 32×20×22 | 48×22×35 | 37×19×33 | ||
| 36×10×20 | 48×23×35 | 67×20×50 | ||
| 36×11×22 | 50×23×40 | 46×21×36 | ||
| 36×12×22 | 58×25×42 | 45×26×45 | ||
| 36×11×24.5 | 58×28×50 | 58×27×45 | ||
| 36×15×25 | 58×31×57 | 60×29×54 | ||
| 37×16×29.5 | 58×25×38 | 双俯耳Double ear | ||
| 37×13.5×24 | 59×28×40 | 45×15×40 | ||
| 38×13.5×24 | 59×30×40 | 46×18×41 | ||
| 38×15×25 | 59×41.5×50.5 | 46×22×44 | ||
| 38×17×28 | 60×30×53 | 47×17×30 | ||
| 38×18.5×29 | 无耳NO EAR | 48×18×38 | ||
| 38×20×30 | 37×14×24 | More info,please contact us | ||
| 47×17×28 | 37×14×27 | |||
| 47×20.5×33 | 37.5×15.5×26.5 | |||
| 47×17×31 | 37×17×28.5 | |||
| 47×22×35 | 47.5×18×32 |
注Note:
- 所属城市：浙江 温州
- [联系时请说明来自维库仪器仪表网]
- 联系人： 王华
- 电话：0577-62760255
- 传真：0577-62760255
- 手机：
- QQ ：
供应CBB65油浸空调电容器
