CRYDOM固态继电器D2450进口固态继电器SSR快达继电器
| 价 格： | 面议 | |
| 型号/规格： | D2450 | |
| 品牌/商标： | SCHNEIDER（施耐德） |
CRYDOM固态继电器D2450进口固态继电器SSR快达固态继电器
全国400热线4006-022-002快达固态继电器
固态继电器SSR
直流控制固态继电器
Independently controlled dual output solid-state relay
Ratings from 25A to 40A @ 24-530 VAC
Industry standard package
SCR output for heavy industrial loads
DC Control
Zero-crossing (resistive loads) or random-fire (inductive loads) output
安装方式 Chassis Mount
端子 Screw Terminal
包装 Hockey Puck
电路 SPST-NO (1 Form A)
负载电流 50A
电压 - 输入 3 ~ 32VDC
电压 - 输出24 ~ 280 V
输出方式 AC,过零输出固态继电器
无铅，RoHS Status RoHS Compliant
快达固态继电器型号：
D2425D-10; D2425DE
D2425DE-10; D2440D
D2440D-10; D2440DE
D2440DE-10; H12D4825D
H12D4825D-10; H12D4825DE
H12D4825DE-10; H12D4840D
H12D4840D-10; H12D4840DE
H12D4840DE-10
D2402 Obsolete use D2410
D2410 PM IP00 280VAC/10A, 3-32VDC In, ZC
D2410-10 PM IP00 280VAC/10A, 3-32VDC In, RN
D2410-B PM IP00 280VAC/10A, 3-32VDC In, ZC
D2410F PM IP00 280VAC/10A, 3-32VDC In, ZC
D24110 PM IP00 280VAC/110A, 3-32VDC In, ZC
D24110-10 PM IP00 280VAC/110A, 3-32VDC In, RN
D24125 PM IP00 280VAC/125A, 3-32VDC In, ZC
D24125-10 PM IP00 280VAC/125A, 3-32VDC In, RN
D2425 PM IP00 280VAC/25A, 3-32VDC In, ZC
D2425-10 PM IP00 280VAC/25A, 3-32VDC In, RN
D2425-B PM IP00 280VAC/25A, 3-32VDC In, ZC
D2425D Dual PM IP00 280VAC/25A, 4-15VDC,ZC
D2425D-10 Dual PM IP00 280VAC/25A, 4-15VDC,RN
D2425F PM IP00 280VAC/25A, 3-32VDC In, ZC
D2425F-10 PM IP00 280VAC/25A, 3-32VDC In, RN
D2440 PM IP00 280VAC/40A, 3-32VDC In, ZC
D2440-10 PM IP00 280VAC/40A, 3-32VDC In, RN
D2440-B PM IP00 280VAC/40A, 3-32VDC In, ZC
D2440D Dual PM IP00 280VAC/40A, 4-15VDC,ZC
D2440D-10 Dual PM IP00 280VAC/40A, 4-15VDC,RN
D2450 PM IP00 280VAC/50A, 3-32VDC In, ZC
D2450-10 PM IP00 280VAC/50A, 3-32VDC In, RN
D2450-B PM IP00 280VAC/50A, 3-32VDC In, ZC
D2475 PM IP00 280VAC/75A, 3-32VDC In, ZC
D2475-10 PM IP00 280VAC/75A, 3-32VDC In, RN
D2475-B PM IP00 280VAC/75A, 3-32VDC In, ZC
D2490 PM IP00 280VAC/90A, 3-32VDC In, ZC
D2490-10 PM IP00 280VAC/90A, 3-32VDC In, RN
D2490-B PM IP00 280VAC/90A, 3-32VDC In, ZC
