品牌:五丰WUFENG 型号:WUF-YDJ09 转速:高速球 是否支持红外:是 使用环境:室外 安装方式:吊装 电压:220V 功率:220W 镜头:可选 图像传感器:可选 有效像素:可选 信噪比:可选 重量:可选 工作温度:可选 旋转速度:220度/秒 照度:0

1.功能简介

●

● 无级变速，人性化的变焦速度自动匹配技术；

● 手控速度0.5o/S平稳运行，巡航速180o/S定位；

● 风扇控温；

● 预留网络模块接口，可选装模块为网络球；

● 支持电源同步；

● 支持PELCO-P、PELCO-D、通讯协议；

●255个预置位随意储存，并支持自动巡航功能，6条巡航路径，每条可存储16个预置位点；

●1条自动扫描,每条可设置左右限位和扫描速度；

● 自动识别SONY、HITACH、LG、CNB ,国产等品牌摄像机；

● 英文OSD菜单可选

● 红外灯,一种12颗大灯杯,距离80-150米,根据镜头的倍数不同起用不同的灯组

● 3条自动扫描,一条左扫描,一条右扫描,一条左右扫描

● 看守功能，可设置球机空闲一段时间后自动运行预置位、自动扫描、自动巡航、模式路径等功能；

● 精巧的机械驱动装置，支持水平360o连续旋转，无监视肓区；

● 无级变速，人性化变焦/速度自动匹配技术；

● 垂直90o旋转，具备自动翻转功能；

● 手动速度：0.01o～180o/秒，巡航速200o/秒；

● 标配电源为24V/3A

● 吊装壁装支架可选

● 内置三台散热风扇，传感器智能控制；

● 外置散热风扇，可工作在60℃高温条件下；

● 球体外壳采用铸铝材质，坚固耐用；

function introduction

1.Adopt stepless speed, humanized zoom speed automatic matching technology

2 the lowest manual speed is 0.5 o/S ,smooth operation, cruising speed at most 180o/S accurate position

3.fan control temperature,

4.reserve network module interfaces, oblique module for network ball

5. support simultaneous power

6.support PELCO - P, PELCO - D, communication protocol

7. 255 preset point random storage and support the automatic cruise function, 6 cruise path, each can stored 16 preset point

8. 1 set limit speed scanning each can set the automatic scanning and left-right limit

9 automatically identificate SONY, HITACH, LG, CNB, home made brand camera,

10 OSD English menu can be chosen

11.an infrared lamp, 12headlamps cup,, 80-150 meters from the camera, according to the different lens multiples different DengZu is used (8509A)

12.Infrared lamp, 4 types 1 degrees array light cup,4 star30 degrees headlight cup, distance 80-120 meters, according to the different lens multiples different DengZu is used(8509B)

13. three article automatic scanning, a right scanning ,a left scanning, a left-right scanning

14. guard function, can install machines rest a short time after automatic operation automatic scanning, preset, automatic cruise, model path

15. adopts exquisite drivers device , support horizontal 360o continuous rotation, no surveillance blind area

16.Adopts stepless speed, humanized zoom/speed automatic matching technology

17.Adopts vertical 90o rotation, with automatic flip function,

18. manual speed: 0.01 o ~ 180o/SEC, the highest cruising speed is 200o/SEC.

19. standard power 24V/3A

20.lifting and wall loading is optional

21. built-in three cooling fans, sensors, intelligent control

22.external cooling fan, can work under 60 ° c high temperature conditions in

23. adopts aluminum sphere shell, durable
