供应LP154W01-TLF1液晶屏
| 价 格： | 1.00 | |
| 型号/规格： | LP154W01-TLF1 | |
| 品牌/商标： | LG |
| 面板品牌： | LG飞利浦 (LG.Philips LCD) |
| 面板型号： | LP154WP1-TLA2 |
| 面板类型： | a-Si TFT-LCD，液晶屏 |
| 面板尺寸： | 15.4" (英寸) |
| 分 辨 率： | 1440(RGB)×900 |
| 显示模式： | TN，常白显示，透射式 |
| 表面处理： | 镜面 (Haze 0%)，Hard coating (3H) |
| 面板亮度： | 250 cd/m2 |
| 对 比 度： | 600:1 (Typ.) |
| 显示颜色： | 262K (6-bit) |
| 响应时间： | 16 (Typ.)(Tr+Td) |
| 可视角度： | 80/80/60/60 (Typ.)(CR≥10) (左/右/上/下) |
| 扫描频率： | 60Hz  |
| 灯管类型： | 1 pcs CCFL  |
| 信号类型： | LVDS (2 ch, 6-bit) |
| 面板电压： | 3.3V (Typ.) |
| RoHS： | dzsc/18/0613/18061383.gif |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 陈小姐
- 电话：0755-83033480/36624220
- 传真：-
- 手机：13510212507
- QQ ：
供应LP154W01-TLD2液晶屏
信息内容：面板品牌： LG飞利浦 (LG.Philips LCD) 面板型号： LP154WP1-TLA2 面板类型： a-Si TFT-LCD，液晶屏 面板尺寸： 15.4" (英寸) 分 辨 率： 1440(RGB)×900 显示模式： TN，常白显示，透射式 表面处理： 镜面 (Haze 0%)，Hard coating (3H) 面板亮度： 250 cd/m2 对 比 度： 600:1 (Typ.) 显示颜色： 262K (6-bit) 响应时间： 16 (Typ.)(Tr+Td) 可视角度： 80/80/60/60 (Typ.)(CR≥10) (左/右/上/下) 扫描频率： 60Hz 120Hz (60HZ输入)：内置MEMC电路120Hz+120Hz：120Hz面板+120Hz背光240Hz (60HZ输入)：内置MEMC电路" src="http://www.panelook.com/too-templates/cn/images/icon/icon_question.gif" align=absMiddle> 灯管类型： 1 pcs CCFL WLED、RGB LED数量：x strings、xSxP举例说明3S8P×2CN 3S：3 LED串联8P：8串并联2CN：2个端子" src="http://www.panelook.com/too-member/images/icon_question.gif" align=absMiddle> 信号类型： LVDS (2 ch, 6-bit) 面板电压： 3.3V (Typ.) RoHS： dzsc/18/0613/18061384.gif
供应LI-FE电池
信息内容：A123 Systems recognizes that the impending transportation revolution requires industry-specific solutions. To that end, we have developed the high energy 20Ah prismatic cell designed for PHEV, EV, and ReEV applications, offering very low cost per Watt-hour.The 20Ah uses the new HD electrode design, offering even higher capacity than the traditional ANR26650M1 design. Model: AHP 70165227 Capacity: 20Ah Size: 7.0X 166X227mm Weight: 480g Designed for plug-in hybrid and electric vehicle applications, the AMP20 prismatic cell is built to deliver high energy and power density combined. The AMP20 cell demonstrates industry-leading abuse tolerance coupled with excellent life performance under the most rigorous duty cycles. The AMP20 delivers high useable energy over a wide state of charge (SOC) range to minimize pack oversizing and offer very low cost per watt-hour.Primary Applications:Passenger and commercial plug-in hybrid electric vehicles (PHEVs)Pass...
