供应AMP连接器767054-1MICTOR连接器

价格：		1.00
型号/规格：		767054-1
品牌/商标：		TE（美国泰科）

详细介绍
企业详情

Product Features (Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Connector
Mount Angle = Vertical

Termination Features:

Termination End Plating = Tin-Lead over Nickel

Body Features:

Number of Positions = 38
Vacuum Cover = Without
Centerline (mm [in]) = 0.64 [0.025]
Ground Bus Lead Length (mm [in]) = 2.74 [0.108]
Ground Bus Material = Phosphor Bronze
Ground Bus Mating Area Plating = Gold (5) over Palladium Nickel
Ground Bus Terminating Area = Tin-Lead

Contact Features:

Mated Stack Height (Vertical) (mm [in]) = 6.60 [0.260], 9.00 [0.354], 10.92 [0.430], 12.57 [0.495], 17.96 [0.707], 18.75 [0.738], 20.00 [0.785], 22.86 [0.900]
Contact Plating, Mating Area, Material = Gold (5) over Palladium Nickel
Contact Base Material = Copper Alloy

Housing Features:

Connector Style = Receptacle
Housing Material = Liquid Crystal Polymer (LCP)

Industry Standards:

RoHS/ELV Compliance = ELV compliant, 5 of 6 Compliant
Lead Free Solder Processes = Reflow solder capable to 245°C, Reflow solder capable to 260°C

Packaging Features:

Packaging Method = Tube

Other:

Ground Bus Lead Type = Barbed
Brand = AMP
