供应供molex543935181 FPC连接器
| 价 格： | 面议 | |
| 型号/规格： | 543935181 | |
| 品牌/商标： | MOLEX（美国莫仕） |
| 品牌 | Molex莫莱克斯 | 型号 | 543935181 |
| 应用范围 | 通讯 | 种类 | FFC/FPC |
| 接口类型 | * | 芯数 | 51p |
| Product Family | FFC/FPC Connectors |
| Series | 54393 |
| Product Name | Easy-On™ |
| Circuits (Loaded) | 51 |
| Contact Position | Bottom |
| Durability (mating cycles max) | 20 |
| Entry Angle | 90° Angle |
| Mated Height (in) | 0.077 In |
| Mated Height (mm) | 1.95 mm |
| Material - Metal | Phosphor Bronze |
| Material - Plating Mating | Gold |
| Material - Plating Termination | Gold |
| Number of Rows | 1 |
| Orientation | Right Angle |
| PCB Locator | No |
| PCB Retention | Yes |
| Packaging Type | Embossed Tape on Reel |
| Pitch - Mating Interface (in) | 0.012 In |
| Pitch - Mating Interface (mm) | 0.30 mm |
| Polarized to PCB | Yes |
| Stackable | No |
| Temperature Range - Operating | -20°C to +85°C |
| Termination Interface: Style | Surface Mount |
| Wire/Cable Type | FPC only |
| Current - Maximum per Contact | 0.2A |
| Voltage - Maximum | 50V |
| Product Specification | PS-54393-064, RPS-54393-081, RPS-54393-082 |
| Sales Drawing | SD-54393-023, SD-54393-024 |
- 所属城市：北京 北京市
- [联系时请说明来自维库仪器仪表网]
- 联系人： 黄建辉
- 电话：010-62650287
- 传真：010-62650582
- 手机：13522771111
- QQ ：
