贴片电感 贴片铁氧体电感 功率电感 标准电感
| 价 格： | 面议 |
应用范围:振荡 种类:电感线圈 品牌:美莱/MELED 型号:MLCI160808-R33K 封装形式:贴片电感 绕线形式:多层平绕式 导磁体性质:铁氧体磁芯 磁芯形状:长方形 工作频率:低频 安装方式:贴片式 骨架材料:无 品质因数Q:0 电感量:0.033（mH） 额定电流:0（mA） 分布电容:0（F）
Multilayer Chip Inductors
MLCII160808(0603) / MLCII201209(0805)
MLCI201212(0805) / MLCI321611(1206)
Features (特長)
● To prevent EMI interference noises between electronic circuits. (可降低噪音及濾波電磁干擾)
●High Q and high reliability and ferrite material. (高品質因素、高可靠性、鐵氧磁體材質)
Application (用途)
● Notebook Computer, Disc Drive Unit(CD/DVD), Inkjet Printer, Hard Disk Drive, Copying Machine, Display Monitor, Gaming Machine, Color TV, Video Tape Recorder, DVD Player, Video Camera, Digital Still Camera, Car Electronics, Lowest EMI. (筆記型電腦、磁片驅動裝置、噴墨印表機、硬碟磁碟機、影印機、顯示監視器、遊戲機、彩色電視、錄放影機、光碟機、攝影機、數位相機、汽車電子產品、防干擾對策)
Product Identification (產品識別)
MLCI160808-(Ex. MLCI160808-47NM)
dzsc/17/8962/17896241.jpg1dzsc/17/8962/17896241.jpg2dzsc/17/8962/17896241.jpg3
1. Multilayer Chip Inductors (積層式晶片電感)
(MLCI160808, MLCI201209, MLCI201212, MLCI321611)
2. Inductance (電感值)
3. Tolerance (誤差值) ( 參照表S 0.3nH, J 5%, K 10%, M 20% )
Configurations & Dimensions (結構圖及規格尺寸)
Type (型式) | A | B | C | D | E | F | G |
MLC160808 (0603) | 1.6 ± 0.2 | 0.8 ± 0.2 | 0.8 ± 0.2 | 0.2~0.6 | 0.7 | 0.7 | 0.7 |
MLCI201209 (0805) | 2.0 ± 0.2 | 1.25 ± 0.2 | 0.85 ± 0.2 | 0.2~0.8 | 1.0 | 0.8 | 1.0 |
MLCI201212 (0805) | 2.0 ± 0.2 | 1.25 ± 0.2 | 1.25 ± 0.2 | 0.2~0.8 | 1.0 | 0.8 | 1.0 |
MLCI321611 (1206) | 3.2 ± 0.2 | 1.6 ± 0.2 | 1.1 ± 0.2 | 0.4~1.0 | 1.4 | 1.1 | 2.2 |
MLCI160808(0603)
Electrical Characteristics for MLCI160808 Series [MLCI160808系列電子特性規格]
Part Number | Inductance | Q | Freq. (MHz) | SRF(MHz) | DCR(Ω) | IDC(mA) |
MLCI160808 –47NM | 0.047 | 10 | 50 | 260 | 0.30 | 50 |
MLCI160808 –68NM | 0.068 | 10 | 50 | 250 | 0.30 | 50 |
MLCII160808 –82NM | 0.082 | 10 | 50 | 245 | 0.30 | 50 |
MLCI160808 –R10K | 0.10 | 15 | 25 | 240 | 0.50 | 50 |
MLCI160808 –R12K | 0.12 | 15 | 25 | 205 | 0.50 | 50 |
MLCI160808 –R15K | 0.15 | 15 | 25 | 180 | 0.60 | 50 |
MLCI160808 –R18K | 0.18 | 15 | 25 | 165 | 0.60 | 50 |
MLCI160808 –R22K | 0.22 | 15 | 25 | 150 | 0.80 | 50 |
MLCI160808 –R27K | 0.27 | 15 | 25 | 136 | 0.80 | 50 |
MLCI160808 –R33K | 0.33 | 15 | 25 | 125 | 0.85 | 35 |
MLCI160808 –R39K | 0.39 | 15 | 25 | 110 | 1.00 | 35 |
MLCI160808 –R47K | 0.47 | 15 | 25 | 105 | 1.35 | 35 |
MLCI160808 –R56K | 0.56 | 15 | 25 | 95 | 1.55 | 35 |
MLCI160808 –R68K | 0.68 | 15 | 25 | 90 | 1.70 | 35 |
MLCI160808 –R82K | 0.82 | 15 | 25 | 85 | 2.10 | 35 |
MLCI160808 –1R0K | 1.00 | 35 | 10 | 75 | 0.60 | 25 |
MLCI160808 –1R2K | 1.20 | 35 | 10 | 65 | 0.80 | 25 |
MLCI160808 –1R5K | 1.50 | 35 | 10 | 60 | 0.80 | 25 |
MLCI160808 –1R8K | 1.80 | 35 | 10 | 55 | 0.95 | 25 |
MLCI160808 –2R2K | 2.20 | 35 | 10 | 50 | 1.15 | 15 |
MLCI160808 –2R7K | 2.70 | 35 | 10 | 45 | 1.35 | 15 |
MLCI160808 –3R3K | 3.30 | 35 | 10 | 40 | 1.55 | 15 |
MLCI160808 –3R9K | 3.90 | 35 | 10 | 35 | 1.70 | 15 |
MLCI160808 –4R7K | 4.70 | 35 | 10 | 33 | 2.10 | 15 |
MLCI160808 –5R6K | 5.60 | 35 | 4 | 22 | 1.55 | 5 |
MLCI160808 –6R8K | 6.80 | 35 | 4 | 20 | 1.70 | 5 |
MLCI160808 –8R2K | 8.20 | 35 | 4 | 18 | 2.10 | 5 |
MLCI160808 –100K | 10.00 | 30 | 2 | 17 | 1.85 | 3 |
MLCI160808 –120K | 12.00 | 30 | 2 | 15 | 2.10 | 3 |
MLCI160808 –150K | 15.00 | 20 | 1 | 14 | 1.70 | 1 |
