表面安装贴片电感线圈
| 价 格： | 面议 |
SMD 空心线圈是一种高频率 , 低损耗的电感器 , 其绕制可依客户之规格设计 , 工作频率可达 1GHz, 应用于通讯卫星 , 微波通讯 , 扼波器等 .
dzsc/01/7682/176829.jpg
dzsc/01/7682/176829.jpg
|
TYPE |
A |
B |
W |
P |
F |
K |
CHIPS/REEL |
|
A51 |
1.40 |
1.20 |
8.00 |
4.00 |
3.5 |
1.50 |
4000 |
|
A52 |
2.05 |
1.20 |
8.00 |
4.00 |
3.5 |
2.10 |
4000 |
|
ED |
1.70 |
3.90 |
12.00 |
4.00 |
3.5 |
2.00 |
4000 |
|
FN(1) |
1.70 |
2.60 |
12.00 |
4.00 |
3.5 |
2.00 |
4000 |
|
GE |
1.90 |
1.40 |
8.00 |
4.00 |
3.5 |
2.20 |
4000 |
|
GH |
1.80 |
2.00 |
8.00 |
4.00 |
3.5 |
2.00 |
4000 |
|
ELK34 |
2.20 |
2.70 |
8.00 |
4.00 |
3.5 |
2.20 |
6000 |
|
HN |
1.80 |
1.65 |
8.00 |
4.00 |
3.5 |
2.00 |
4000 |
|
FP(1) |
1.70 |
3.10 |
12.00 |
4.00 |
3.5 |
2.00 |
4000 |
|
HP(2) |
1.70 |
1.10 |
8.00 |
4.00 |
3.5 |
1.70 |
4000 |
|
4T,5T |
2.50 |
2.40 |
12.00 |
8.00 |
5.5 |
2.80 |
3000 |
|
6T,7T |
2.50 |
3.10 |
12.00 |
8.00 |
5.5 |
2.80 |
3000 |
dzsc/01/7682/176829.jpg
| dzsc/01/7682/176829.jpg | 单位 mm
|
| SMT 线圈电感器 |
这种 SMD 电感器有极高的 Q 值和很宽的频率范围 , 其电性公差能分别控制在 + 5% 或 + 10% 电感器由耐高温材料封装而成 , 成型后 , 较小的外型公差 , 产品顶部平坦 , 适合气动设备安装 , 引脚通过镀锡处理 .
dzsc/01/7682/176829.jpg
dzsc/01/7682/176829.jpg
| SIZE | A(max) | B(max) | C | D(max) | Tape Width |
| A | .145 | .130 | .115+.010 | .145 | .472 |
| 3.68 | 3.30 | 2.92+0.25 | 3.68 | 12.00(1) | |
| B | .270 | .130 | .228+.010 | .145 | .630 |
| 6.86 | 3.30 | 5.79+0.25 | 3.68 | 16.00 | |
| C | .120 | .115 | .095+.010 | .100 | .472 |
| 3.04 | 2.92 | 2.41+0.25 | 2.54 | 12.00(2) | |
| D | .240 | .106 | .190+.010 | .100 | .472 |
| 6.09 | 2.69 | 4.82+0.25 | 2.54 | 12.00(2) |
| SIZE | A | B | C | D | E |
| A | .165+.012 | .130+.012 | .050 | .050 | .065+.012 |
| 4.19+0.30 | 3.30+0.30 | 1.27 | 1.27 | 1.65+0.30 | |
| B | .285+.012 | .130+.012 | .050 | .050 | .185+.012 |
| 7.24+0.30 | 3.30+.030 | 1.27 | 1.27 | 1.65+0.30 | |
| C | .135+.012 | .120+.012 | .038 | .038 | .059+.012 |
| 3.43+0.30 | 3.04+0.30 | 0.965 | 0.965 | 1.50+0.3 | |
| D | .250+.012 | .120+0.12 | .038 | .038 | .174+.012 |
| 6.35+0.30 | 3.04+0.30 | 0.965 | 0.965 | 4.42+0.3 |
| 包装数/: | (1) 7" 700; 13" 2,000 Parts/reel: 7" 500; 13" 2,000 | |
| 测试治具 | (2) 7" 1000; 13" 3,000 | |
| ||
|
L值: nH 单位: m/m |
| ITEM NO | L | Q(MIN) | TOLERANCE | TEST FREQ |
| C02TC | 8.0 | 50 | ± 10% | 150MHZ |
| C03TC | 16.0 | 50 | ± 10% | 150MHZ |
| C04TC | 26.0 | 50 | ± 10% | 150MHZ |
| C05TC | 48.0 | 50 | ± 10% | 150MHZ |
| D06TC | 48.0 | 50 | ± 10% | 150MHZ |
| D07TC | 67.0 | 50 | ± 10% | 150MHZ |
| D08TC | 88.0 | 50 | ± 10% | 150MHZ |
| D09TC | 111.0 | 50 | ± 10% | 150MHZ |
| D10TC | 135.0 | 50 | ± 10% | 150MHZ |
| D11TC | 174.5 | 50 | ± 10% | 150MHZ |
| 测试仪器:HP4284A |
| 测试治具:HP16191A |
|
L值: nH 单位: m/m |
| ITEM NO | L | Q(MIN) | TOLERANCE | TEST FREQ |
| A03TC | 19.2 | 60 | ± 10% | 50MHZ |
| A04TC | 39.5 | 60 | ± 10% | 50MHZ |
| A05TC | 63.0 | 50 | ± 10% | 50MHZ |
| B06TC | 113.0 | 50 | ± 10% | 25.2MHZ |
| B07TC | 131.0 | 50 | ± 10% | 25.2MHZ |
| B08TC | 155.5 | 50 | ± 10% | 25.2MHZ |
| B09TC | 187.5 | 50 | ± 10% | 25.2MHZ |
| B10TC | 215.0 | 35 | ± 10% | 25.2MHZ |
| B11TC | 229.0 | 28 | ± 10% | 25.2MHZ |
| 测试仪器:HP4284A |
| 测试治具:HP16191A |
|
L值: nH 单位: m/m |
| ITEM NO | L | Q(MIN) | TOLERANCE | ???? ?TEST FREQ |
| C02T | 4.0 | 85 | ± 10% | 150MHZ |
| C03T | 6.1 | 70 | ± 10% | 150MHZ |
| C04T | 9.3 | 70 | ± 10% | 150MHZ |
| C05T | 13.3 | 60 | ± 5% | 150MHZ |
| D06T | 12.2 | 60 | ± 5% | 150MHZ |
| D07T | 16.2 | 60 | ± 5% | 150MHZ |
| D08T | 19.3 | 60 | ± 5% | 150MHZ |
| D09T | 22.3 | 55 | ± 5% | 150MHZ |
| D10T | 27.5 | 55 | ± 5% | 150MHZ |
| 测试仪器:HP4284A |
| 测试治具:HP16191A |
|
L值: nH 单位: m/m |
| ITEM NO | L | Q(MIN) | TOLERANCE | TEST FREQ |
| C02T | 4.0 | 85 | ± 10% | 150MHZ |
| C03T | 6.1 | 70 | ± 10% | 150MHZ |
| C04T | 9.3 | 70 | ± 10% | 150MHZ |
| C05T | 13.3 | 60 | ± 5% | 150MHZ |
| D06T | 12.2 | 60 | ± 5% | 150MHZ |
| D07T | 16.2 | 60 | ± 5% | 150MHZ |
| D08T | 19.3 | 60 | ± 5% | 150MHZ |
| D09T | 22.3 | 55 | ± 5% | 150MHZ |
| D10T | 27.5 | 55 | ± 5% | 150MHZ |
| 测试仪器:HP4284A |
| 测试治具:HP16191A |
