TP614.TP6141.按键开关
| 价 格： | 1.50 | |
| 型号/规格： | TP6141L | |
| 品牌/商标： | HIGHLYWELL |
Rating: 0.1A/30VDC
Insulation Reslstance: 100MΩ Min (at 500VDC)
Dielectric Strength: AC 500V(50/60Hz For 1 minute)
Contact resistance: 50mΩ max.(Initial)
Electrical life: 10,000 Cycles Min
Ambient temperature: -10 to + 80℃
Operating Force: 150±100gf(Momentary)
250±100gf(Alternate)
其他型号如下：TP13L TP614 TP6141L TP615L TP6151L TP6151HL TP6151ML TP6151HML TP6151RSL PB6151L-X-104 PB6152RSL PB6156RSL-X-102 TP617 TP627 TP617ML TP627ML PB6171FL PB6172FL PB6171L PB6271L PB6172ML PB671ML PB6173ML PB6273ML
欢迎来电及网上咨询。
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 胡松
- 电话：0755-83654796-803
- 传真：0755-83657595
- 手机：13699851006
- QQ ：
PB-309A.PB-309B海立按钮开关
信息内容：额定功率: 1A 125VAC or 3A 125VAC接触电阻： 50mΩ max.耐电压： AC 1000V (50/60Hz for 1 minute)绝缘电阻： 100MΩ min (DC 500V)电气寿命： 50,000 cycle机械寿命： 100,000 cycle PB101A OFF-(ON) 安装孔 7MMPB101B ON-(OFF) PB307A ON-(OFF) 安装孔 12*12MMPB307B OFF-(ON)PB309A ON-OFF 安装孔 12*12MMPB301A ON-OFF 安装孔 12MMPB301B OFF-(ON) PB302A ON-OFF 安装孔 12MMPB302B OFF-(ON)PB303A ON-OFF 安装孔 12MMPB303B OFF-(ON)PB304A ON-OFF 安装孔 12MMPB304B OFF-(ON)PB305A ON-OFF 安装孔 12MMPB305B OFF-(ON)PB308A ON-OFF 安装孔 12MMPB308B OFF-(ON)
PB-307A.PB-307B海立按钮开关
信息内容：额定功率: 1A 125VAC or 3A 125VAC接触电阻： 50mΩ max.耐电压： AC 1000V (50/60Hz for 1 minute)绝缘电阻： 100MΩ min (DC 500V)电气寿命： 50,000 cycle机械寿命： 100,000 cycle PB101A OFF-(ON) 安装孔 7MMPB101B ON-(OFF) PB307A ON-(OFF) 安装孔 12*12MMPB307B OFF-(ON)PB309A ON-OFF 安装孔 12*12MMPB301A ON-OFF 安装孔 12MMPB301B OFF-(ON) PB302A ON-OFF 安装孔 12MMPB302B OFF-(ON)PB303A ON-OFF 安装孔 12MMPB303B OFF-(ON)PB304A ON-OFF 安装孔 12MMPB304B OFF-(ON)PB305A ON-OFF 安装孔 12MMPB305B OFF-(ON)PB308A ON-OFF 安装孔 12MMPB308B OFF-(ON)
