供应Z型、120VAC,10a,直流控制固态继电器Z120D10
AC Power Series 120/240 Volt:Plastic Package (Z Series)
Z120D10
Z240D10
Nominal AC Line Voltage Nominal
120
240
Current Rating (Amps)
10
10
1 cycle Surge (Amps) Peak
110
110
Nominal Signal Input Resistance (Ohms)
1000
1000
Signal Pick-up Voltage
3VDC (32V allowed)
3VDC (32V allowed)
Signal Drop-out Voltage
1 VDC
1 VDC
Peak Repetitive Voltage Maximum
600
600
Maximum Output Voltage Drop
1.6 volts
1.6 volts
Off-State Leakage (mA) Maximum**
6 mA
12 mA
Operating Voltage Range (Volts AC)
12-140
24-280
I2t Rating t=8.3 (ms)
50
50
Isolation Voltage
4,000 VRMS
4,000 VRMS
θjc* (°C/Watt) Dissipation (Watts/Amp)
4
4
Notes: θjc* = Thermal resistance junction to base. Maximum junction temperature is 110°C.** Operating Frequency: 25 to 65 Hz (operates at 400 Hz with 6 times the o...
