供应NDK温补压控晶振
| 价 格： | 面议 | |
| 型号/规格： | NT3225SA-10M-26M | |
| 品牌/商标： | NDK | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 贴片式 | |
| 主要用途： | |
- Supports low power supply voltage. (Supports DC +2.4 V±0.1 V to +3.4 V±5 %.)
- Ultra-compact and light with a height, cubic volume, and weight of Max. 1.0 mm, 0.007 cm3, and 0.024 g, respectively.
- Low power consumption.
- A surface-mount crystal oscillator. (Reflow soldering is possible.)
- Lead-free. Meets the requirements for re-flow profiling using lead-free solder.
dzsc/17/5533/17553352.jpg
- dzsc/17/5533/17553352.gif
- dzsc/17/5533/17553352.gif
Specifications
Dimensions
dzsc/17/5533/17553352.jpg
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 袁野
- 电话：0755-62352200
- 传真：0755-83777332
- 手机：15986803377
- QQ ：
供应13/26MHz温补晶振
信息内容：Specifications Nominal frequency (MHz) 10 to 26Please click above Frequency Range(link) to go to NDK's standard frequencies and Ordering Codes page. Package Size (L×W×H : mm) 3.2×2.5×1.0 Supply Voltage (V) +3.0 Load Impedance 10 kΩ//10 pF Operating Temperature Range(*1) / Storage Temperature Range (°C) -30 to +75 / -40 to +85 Current Consumption (mA) Max. 1.5 Output Voltage Min. 0.8 V(p-p) (DC Coupling (*2)) Frequency/Temperature Characteristics Max. ±2.5×10-6 Frequency/Voltage Coefficient Max. ±0.3×10-6 / +3.0 V ±5 % Frequency/Load Coefficient Max. ±0.2×10-6/(10 kΩ//10 pF)±10 % Long-term Frequency Stability Max. ±1.0 ×10-6/year*1. Ambient temperature range within which the specified characteristics of a product can be achieved.*2. A DC-cut capacitor is not embedded in this crystal oscillator. Connect a DC-cut capacitor (1,000 pF) to the line-out terminal of the oscillator.When ordering our products, sp...
供应10M-26M温补压控晶振
信息内容：Specifications Nominal frequency (MHz) 10 to 26Please click above Frequency Range(link) to go to NDK's standard frequencies and Ordering Codes page. Package Size (L×W×H : mm) 3.2×2.5×1.0 Supply Voltage (V) +3.0 Load Impedance 10 kΩ//10 pF Operating Temperature Range(*1) / Storage Temperature Range (°C) -30 to +75 / -40 to +85 Current Consumption (mA) Max. 1.5 Output Voltage (V) Min. 0.8 V(p-p) (DC Coupling (*2)) Frequency/Temperature Characteristics Max. ±2.5×10-6 Frequency/Voltage Coefficient Max. ±0.3×10-6 / +3.0 V ±5 % Frequency/Load Coefficient Max. ±0.2×10-6/(10 kΩ//10 pF)±10 % Long-term Frequency Stability Max. ±1.0 ×10-6/year Frequency Control Range ±9.0×10-6 to ±15.0×10-6 / +1.5±1V (*3)*1. Ambient temperature range within which the specified characteristics of a product can be achieved.*2. A DC-cut capacitor is not embedded in this crystal oscillator. Connect a DC-cut capacitor (1,000 ...
