供应Green-Mode PWM控制器为反激变换器转换器SG6858TZ
| 价 格： | 面议 | |
| 型号/规格： | SG6858TZ | |
| 品牌/商标： | FSC |
SG6858TZ
Low Cost Green-Mode PWM Controller for Flyback Converters
| Attribute | Value | UOM |
|---|---|---|
| General Information | ||
| Device Marking(TOP MARK) | &E&E&Y &OAAIB&C &.&O&E&V |
|
| Family Code | 0GT | |
| Package Type | SSOT-6 | |
| Package Description | 006, PLASTIC MOLDED, SUPER SOT-6 PKG, SINGLE, SMD (33) | |
| Pin Count | 6 | |
| Maximum Reflow Temperature | 260C | |
| Restriction of Hazardous Substance | ||
| Standard Plating Finish | Matte Sn | |
| Base Metal/Leadframe Material | Copper,Iron,Zinc,Phosphorus,Lead (RoHS Exempt),Silver | |
| Lead Pitch | 950 | |
| Minimum Lead Spacing | 450 | |
| Die Fabrication | ||
| Fabrication Process Identifier | BSMC | |
| Package Assembly* | ||
| Plating Finish Layer Thickness | 8.0um - 13um | |
| Thermal Impedance (Theta JA) | 208 | °C/Watt |
| Thermal Impedance (Theta JC) | 999 | °C/Watt |
| Moisture Sensitivity | 1 | |
| Electrical Test | ||
| ESD Human Body Model (HBM) | 3 | V |
| ESD Machine Model (MM) | 200 | V |
| Package Assembly* | ||
| DAP Size | 1.57x0.99 MM | |
| Frame Material | Alloy194 | |
| UL Flammability Rating | UL94-V0 | |
| Die Attach Type | Epoxy / QMI9510 | |
