品牌 | 3M | 型号 | 10214-6212PC |
应用范围 | 通讯 | 种类 | 线对线 |
接口类型 | MDR | 支持卡数 | 二合一 |
形状 | 条形 | 制作工艺 | 熔接 |
特性 | 防潮 | 接触件材质 | PBT |
芯数 | 14 | 针数 | 14 |
Insulation
Material: Glass Reinforced Polyester (PBT)
Flammability: UL 94V-0
Color: Black
Contact Material: Copper Alloy (C521)
Plating
Underplating: 80 μ″ (2.0 μm) Nickel - QQ-N-290, Class 2
Wiping Area: 30 μ″ (0.76 μm) Min Gold - MIL-G-45204, Type II, Grade C
Solder Tails: See ordering information
Body
Material: Zinc Alloy
Plating: Nickel
Shroud & Latch Hook
Material: Steel
Plating: Nickel
Marking: 3M Logo & Part Number
InsulationMaterial: Glass Filled Polyester (PBT)Flammability: UL 94V-0Color: GrayContact Material: Copper AlloyPlating:Underplating: 100 μ″ [ 2.54 μm ] NickelWiping Area: 30 μ″ [ 0.76 μm ] GoldShellMaterial: SteelPlating: TinStrain Relief Material: Stainless Steel .016 [ 0.40 ] ThickWire Accommodation: 26 and 28 AWG Solid or StrandedMarking: 3M Logo and Contact Position NumbersCurrent Rating: 1 AInsulation Resistance: > 1 × 109Ω at 500 VDCWithstanding Voltage: 1000 Vrms at Sea LevelTemperature Rating: -55°C to 105°C"
