简介：
Crossbow GP系列加速度计是一种低成本，通用型产品，可用于测量线加速度或振动值，量程有±4g, ±10g, 和±25g可选。它可提供宽动态范围，的频率响应，仅需4.9 至 5.5 VDC供电，可直接接标准数据采集设备。3-轴系列（GP3）可选择带有内部调压装置（-R 可选项)，以便适用5.5至36V的电源。 CXL-GP系列通用加速度传感器 | | 技术规格 | CXL04GP1
CXL04GP1Z
CXL04GP3 | CXL10GP1
CXL10GP1Z
CXL10GP3 | CXL25GP1
CXL25GP1Z
CXL25GP3 | 备注 | | 性能指标 | | | | | | 量程(g) | ± 4 | ± 10 | ± 25 | ± 5% | | 零g漂移(g) | ± 0.1 | ± 0.3 | ± 0.5 | 0°C to 70°C | | 灵敏度(mV/g) | 500 ± 15 | 200 ± 5 | 80 ± 2 | | | 横向灵敏度(% Span) | ± 5 | ± 5 | ± 5 | | | 非线性(% FS) | ± 0.2 | ± 0.2 | ± 0.2 | 典型值 | | 交叉轴误差(deg) | ± 2 | ± 2 | ± 2 | 典型值 | | 噪声(mg rms) | 10 | 25 | 25 | 典型值 | | 带宽(Hz)(1) | DC -100 | DC -100 | DC -100 | | | 环境指标 | | | | | | 工作温度(°C) | -40 to +85 | -40 to +85 | -40 to +85 | | | 工作温度-铝壳(°C) | -40 to +105 | -40 to +105 | -40 to +105 | | | 冲击(g) | 2000 | 2000 | 2000 | | | 电气指标 | | | | | | 电压(Volts) | + 4.9 to 5.5 | + 4.9 to 5.5 | + 4.9 to 5.5 | | | 电压-R可选项(Volts) | + 5.5 to 36 | + 5.5 to 36 | + 5.5 to 36 | | | 电流(mA) | 1/axis | 3/axis | 3/axis | 典型值 | | 零g输出(Volts) | + 2.375 ± 0.1 | + 2.375 ± 0.1 | + 2.375 ± 0.1 | @25°C | | 输出(Volts) | ± 2.0 ± 0.1 | ± 2.0 ± 0.1 | ± 2.0 ± 0.1 | | | 输出负载 | > 2.0 < 2 nF | > 2.0 < 2 nF | > 2.0 < 2 nF | | | 物理指标 | | | | | | 标准包装 | | | | | | 尺寸(in) | 0.78 x 1.75 x 1.07 | 0.78 x 1.75 x 1.07 | 0.78 x 1.75 x 1.07 | | | (cm) | 1.98 x 4.45 x 2.72 | 1.98 x 4.45 x 2.72 | 1.98 x 4.45 x 2.72 | | | 重量 | 1.62 oz (46 gm) | 1.62 oz (46 gm) | 1.62 oz (46 gm) | | | 铝壳包装(-AL可选项) | | | | | | 尺寸(in) | 0.95 x 2.00 x 1.20 | 0.95 x 2.00 x 1.20 | 0.95 x 2.00 x 1.20 | | | (cm) | 2.41 x 5.08 x 3.05 | 2.41 x 5.08 x 3.05 | 2.41 x 5.08 x 3.05 | | | 重量 | 2.40 oz (68 gm) | 2.40 oz (68 gm) | 2.40 oz (68 gm) | | | | , , | | | | 注释： | 1.-3dB, DC coupled sensor
Non-linearity is the deviation from a best fit straight line at full scale. | | Transverse sensitivity is error measured in the primary axis output created by forces induced in the orthogonal axis. | | Transverse sensitivity error is primarily due to the effects of misalignment. | | Zero g drift is specified as the typical change in 0 g level from its initial value at +25°C to its worst case value at Tmin or Tmax. | | 参数有可能随时改变，请恕不告知！ | | |
订货信息 | | 产品 | 轴数 | 量程(g) | 灵敏度(m V/g) | 噪声(mg rms) | 带宽(Hz) | | CXL04GP1 | X | ± 4 | 500 | 10 | DC-100 | | CXL04GP1Z | Z | ± 4 | 500 | 10 | DC-100 | | CXL04GP3 | TRI | ± 4 | 500 | 10 | DC-100 | | CXL10GP1 | X | ± 10 | 200 | 25 | DC-100 | | CXL10GP1Z | Z | ± 10 | 200 | 25 | DC-100 | | CXL10GP3 | TRI | ± 10 | 200 | 25 | DC-100 | | CXL25GP1 | X | ± 25 | 80 | 25 | DC-100 | | CXL25GP1Z | Z | ± 25 | 80 | 25 | DC-100 | | CXL25GP3 | TRI | ± 25 | 80 | 25 | DC-100 | | OPTIONS | | | | | | | -R | 电压调节器，可选5.5 – 36 VDC电压输入。（仅GP3型号有） | | -AL | 高温包装，工作温度(°C)：-40 to +105，（仅GP3型号有） |
|
