■DESCRIPTION
The M211 is a bi-directional, single-pole, single-throw, normally open multipurpose solid-state relay in a miniature 4-pin small outline package. It is designed to replace electromechanical relays in general purpose switching applications. The relay consists of an integrated circuit that drives two rugged source-to-source enhancement type DMOS transistors - optically coupled to a light emitting diode. The output MOS transistors are protected with free-wheeling diodes that can handle up to 1.5A of inrush current, making the relay ideal for switching lamps and highly inductive loads.
|
|
■FEATURES
·High input-to-output isolation
·Low input control power consumption
·100mA maximum continuous load current
·35 ohms maximum on-resistance
·Long life/high reliability
·Ultra miniature 4-pin small outline package
■Application
·Telecom switching
·Tip/Ring control
·PCMCIA modules
·Multiplexers
·Meter reading systems
·Data acquisition
·Medical equipment
·Battery monitoring
·Home/Safety security systems |
dzsc/17/2623/17262343.jpg |
|
|
|
■OPTIONS/SUFFIXES |
|
|
-TR Tape and Reel |
|
|
■SCHEMATIC DIAGRAM |
|
| |
|
| dzsc/17/2623/17262343.gif | |
| ■MAXIMUM RATINGS 额定参数 |
|
PARAMETER |
UNIT |
MIN |
TYP |
MAX |
|
StorageTemperature 储存温度 |
°C |
-55 |
--- |
125 |
|
Operating Temperature 工作温度 |
°C |
-40 |
--- |
85 |
|
Continuous Input Current 持续输入电流 |
mA |
--- |
--- |
40 |
|
Transient Input Current 瞬间输入电流 |
mA |
--- |
--- |
400 |
Reverse Input Control Voltage
回流输入控制电压 |
V
|
6 |
--- |
--- |
|
Output Power Dissipation 输出功率消耗 |
mW |
--- |
--- |
400 | |
|
|
| ■ APPROVALS 认证 |
BABT CERTIFICATE #650192:
BS EN 60950, BS EN 41003, BS EN 60065 |
| ■ELECTRICAL CHARACTERISTICS - 25°C 电气特性 |
|
PARAMETER |
UNIT |
MIN |
TYP |
MAX |
TEST CONDITIONS |
|
INPUT SPECIFICATIONS 输入规格 |
--- |
--- |
--- |
--- |
--- |
| LED Forward Voltage 发光二极管运送电压 |
V |
|
1.2 |
1.5 |
If = 10mA |
| LED Reverse Voltage 发光二极管回流电压 |
V |
6 |
12 |
--- |
Ir = 10uA |
| Turn-On Current 接通时间 |
mA |
5 |
2.5 |
--- |
Io = 100mA |
| Turn-Off Current 关闭时间 |
mA |
--- |
0.5 |
--- |
--- |
| OUTPUT SPECIFICATIONS 输出规格 |
--- |
--- |
--- |
--- |
--- |
| Blocking Voltage 阻拦电压 |
V |
400 |
--- |
--- |
Io = 10uA |
| Continuous Load Current 持续负载电流 |
mA |
--- |
--- |
100 |
If = 5mA |
| On-Resistance 阻抗 |
Ω |
--- |
30 |
35 |
Io = 100mA |
| Leakage Current 漏电流 |
μ A |
--- |
0.2 |
10 |
Vo = 400V |
| Output Capacitance 输出电容 |
pF |
--- |
25 |
50 |
Vo = 25V, f = 1.0MHz |
| Offset Voltage 垂距电压 |
mV |
--- |
--- |
0.2 |
If = 5mA |
| COUPLED SPECIFICATIONS 结合规格 |
--- |
--- |
--- |
--- |
--- |
| Isolation Voltage 绝缘电压 |
V |
1500 |
--- |
--- |
T = 1 minute |
| Turn-On Time 接通时间 |
ms |
--- |
1 |
2 |
If = 5mA, Io = 100mA |
| Turn-Off Time 关闭时间 |
ms |
--- |
0.1 |
0.5 |
If = 5mA, Io = 100mA |
| Isolation Resistance 绝缘电阻 |
G Ω |
100 |
|
--- |
--- |
| Coupled Capacitance 结合电容 |
p F |
--- |
2 |
--- |
--- |
| Contact Transient Ratio 连接瞬间功率 |
V / μ s |
2000 |
7000 |
--- |
dV = 50V | |
| ■PERFORMANCE DATA 性能数据 |
| dzsc/17/2623/17262343.gif |
| |
| ■MECHANICAL DIMENSIONS |
| 4 PIN SMALL OUTLINE PACKAGE |
| dzsc/17/2623/17262343.gif |
dzsc/17/2623/17262343.gif |
|
END VIEW |
TOP VIEW |
| |
|
| dzsc/17/2623/17262343.gif |
|
|
BACK VIEW |
|
