供应25.0AMPERES/ KBU25X贴片二极管
| 价 格： | 面议 | |
| 型号/规格： | 25.0AMPERES/ KBU25X | |
| 品牌/商标： | 搏扬 | |
| 封装形式： | 贴片 | |
| 环保类别： | 普通型 | |
| 安装方式： | 贴片式 | |
| 包装方式： | 散装 | |
| 功率特性： | | |
| 频率特性： | | |
| 整流电流： | | |
| 反向击穿电流： | |
|
BRIDGE RECTIFIERS dzsc/17/2311/17231171.gif 1708 KBU25X.pdf | ||||||||
| TYPE |
Maximum Recurrent |
Maximum Average Forward Rectified Current IO A |
MaximumPeak Forward |
Maximum |
Maximum Forward Voltage |
Maximum Forward Voltage |
||
| KBU25005 | 50 | 25.0 | 350 | 10.0 | 12.5 | 1.0 | ||
| KBU2501 | 100 | 25.0 | 350 | 10.0 | 12.5 | 1.0 | ||
| KBU2502 | 200 | 25.0 | 350 | 10.0 | 12.5 | 1.0 | ||
| KBU2504 | 400 | 25.0 | 350 | 10.0 | 12.5 | 1.0 | ||
| KBU2506 | 600 | 25.0 | 350 | 10.0 | 12.5 | 1.0 | ||
| KBU2508 | 800 | 25.0 | 350 | 10.0 | 12.5 | 1.0 | ||
| KBU2510 | 1000 | 25.0 | 350 | 10.0 | 12.5 | 1.0 | ||
- 所属城市：广东 广州
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周建忠 先生
- 电话：0020-81859010
- 传真：0020-81920559
- 手机：13802747878
- QQ ：
供应35.0AMPERES/ KBU35X贴片二极管
信息内容：产品参数 dzsc/17/2311/17231172.gif BRIDGE RECTIFIERS dzsc/17/2311/17231172.gif 1709 KBU35X.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV KBU35005 50 35.0 400 10.0 17.5 1.0 KBU3501 100 35.0 400 10.0 17.5 1.0 KBU3502 200 35.0 400 10.0 17.5 1.0 KBU3504 400 35.0 400 10.0 17.5 1.0 KBU3506 600 35.0 400 10.0 17.5 1.0 KBU3508 800 35.0 400 10.0 17.5 1.0 KBU3510 1000 35.0 400 10.0 17.5 1.0
供应10.0AMPERES/ KBU10X贴片二极管
信息内容：BRIDGE RECTIFIERS dzsc/17/2312/17231224.gif 1706 KBU10X.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV KBU10005 50 10.0 300 10.0 10.0 1.05 KBU1001 100 10.0 300 10.0 10.0 1.05 KBU1002 200 10.0 300 10.0 10.0 1.05 KBU1004 400 10.0 300 10.0 10.0 1.05 KBU1006 600 10.0 300 10.0 10.0 1.05 KBU1008 800 10.0 300 10.0 10.0 1.05 KBU1010 1000 10.0 300 10.0 10.0 1.05
