供应1.5AMPERES/ W0X贴片二极管
| 价 格： | 面议 | |
| 型号/规格： | 1.5AMPERES/ W0X | |
| 品牌/商标： | 搏扬 | |
| 封装形式： | 贴片 | |
| 环保类别： | 普通型 | |
| 安装方式： | 贴片式 | |
| 包装方式： | 散装 | |
| 功率特性： | | |
| 频率特性： | | |
| 整流电流： | | |
| 反向击穿电流： | |
|
BRIDGE RECTIFIERS dzsc/17/2311/17231121.gif 1102 WOX.pdf | ||||||||
| TYPE |
Maximum Recurrent |
Maximum Average Forward Rectified Current IO A |
MaximumPeak Forward |
Maximum |
Maximum Forward Voltage |
Maximum Forward Voltage |
||
| W005 | 50 | 1.5 | 50 | 10.0 | 1.5 | 1.1 | ||
| W01 | 100 | 1.5 | 50 | 10.0 | 1.5 | 1.1 | ||
| W02 | 200 | 1.5 | 50 | 10.0 | 1.5 | 1.1 | ||
| W04 | 400 | 1.5 | 50 | 10.0 | 1.5 | 1.1 | ||
| W06 | 600 | 1.5 | 50 | 10.0 | 1.5 | 1.1 | ||
| W08 | 800 | 1.5 | 50 | 10.0 | 1.5 | 1.1 | ||
| W10 | 1000 | 1.5 | 50 | 10.0 | 1.5 | 1.1 | ||
- 所属城市：广东 广州
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周建忠 先生
- 电话：0020-81859010
- 传真：0020-81920559
- 手机：13802747878
- QQ ：
供应1.0AMPERES/ SF1X贴片二极管
信息内容：SUPER FAST RECOVERY RECTIFIERS dzsc/17/2311/17231122.gif 0401 SF1X.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV Maximum Reverse Recovery Time*TrrnS SF11 50 1.0 30 10.0 1.0 0.95 35 SF12 100 1.0 30 10.0 1.0 0.95 35 SF13 150 1.0 30 10.0 1.0 0.95 35 SF14 200 1.0 30 10.0 1.0 0.95 35 SF15 300 1.0 30 10.0 1.0 1.25 35 SF16 400 1.0 30 10.0 1.0 1.25 35 SF17 600 1.0 30 10.0 1.0 1.50
供应8.0AMPERES/ RS80X贴片二极管
信息内容：BRIDGE RECTIFIERS dzsc/17/2311/17231123.gif 1711 RS80X.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV RS801 50 8.0 200 10.0 4.0 1.0 RS802 100 8.0 200 10.0 4.0 1.0 RS803 200 8.0 200 10.0 4.0 1.0 RS804 400 8.0 200 10.0 4.0 1.0 RS805 600 8.0 200 10.0 4.0 1.0 RS806 800 8.0 200 10.0 4.0 1.0 RS807 1000 8.0 200 10.0 4.0 1.0
