供应1.0AMPERES/ FR10X贴片二极管
| 价 格： | 面议 | |
| 型号/规格： | 1.0AMPERES/ FR10X | |
| 品牌/商标： | 搏扬 | |
| 封装形式： | 贴片 | |
| 环保类别： | 普通型 | |
| 安装方式： | 贴片式 | |
| 包装方式： | 散装 | |
| 功率特性： | | |
| 频率特性： | | |
| 整流电流： | | |
| 反向击穿电流： | |
|
FAST RECOVERY RECTIFIERSdzsc/17/2311/17231115.gif 0201 FR10X.pdf | ||||||||
| TYPE | Maximum Recurrent Peak Reverse Voltage VRRM V |
Maximum Average Forward Rectified Current IO A |
Peak Forward Surge Current 8.3ms Single Half Sine-Wave IFSM A |
Maximum DC Reverse Current @VRRM IR µ A |
Maximum Forward Voltage @TA = 25℃ IF A |
Maximum Forward Voltage @TA = 25℃ VF V |
Maximum Reverse Recovery Time *Trr nS |
|
| FR101 | 50 | 1.0 | 30 | 5.0 | 1.0 | 1.3 | 150 | |
| FR102 | 100 | 1.0 | 30 | 5.0 | 1.0 | 1.3 | 150 | |
| FR103 | 200 | 1.0 | 30 | 5.0 | 1.0 | 1.3 | 150 | |
| FR104 | 400 | 1.0 | 30 | 5.0 | 1.0 | 1.3 | 150 | |
| FR105 | 600 | 1.0 | 30 | 5.0 | 1.0 | 1.3 | 250 | |
| FR106 | 800 | 1.0 | 30 | 5.0 | 1.0 | 1.3 | 500 | |
| FR107 | 1000 | 1.0 | 30 | 5.0 | 1.0 | 1.3 | ||
- 所属城市：广东 广州
- [联系时请说明来自维库仪器仪表网]
- 联系人： 周建忠 先生
- 电话：0020-81859010
- 传真：0020-81920559
- 手机：13802747878
- QQ ：
供应3.0 AMPERES/SR3X0 贴片二极管
信息内容：SKY BARRIER RECTIFIERS dzsc/17/2311/17231119.gif 0505 SR3X0.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV SR320 20 3.0 80 1.0 3.0 0.450 SR330 30 3.0 80 1.0 3.0 0.550 SR340 40 3.0 80 1.0 3.0 0.600 SR350 50 3.0 80 1.0 3.0 0.700 SR360 60 3.0 80 1.0 3.0 0.700
供应1.0 AMPERES/MX贴片二极管
信息内容：SURFACE MOUNT STANDARD RECTIFIERS dzsc/17/2311/17231120.gif 0901 MX.pdf TYPE Maximum RecurrentPeak Reverse VoltageVRRMV Maximum AverageForward RectifiedCurrentIOA MaximumPeak Forward Surge Current 8.3ms SingleHalf Sine-WaveIFSMA MaximumDC ReverseCurrent@VRRMIRµ A Maximum Forward Voltage@TA = 25℃IFA Maximum Forward Voltage@TA = 25℃VFV M1 50 1.0 30 5.0 1.0 1.1 M2 100 1.0 30 5.0 1.0 1.1 M3 200 1.0 30 5.0 1.0 1.1 M4 400 1.0 30 5.0 1.0 1.1 M5 600 1.0 30 5.0 1.0 1.1 M6 800 1.0 30 5.0 1.0 1.1 M7 1000 1.0 30 5.0 1.0 1.1
