产品名称:LED天花灯|LED橱柜灯|LED展柜灯|天花灯|天花射灯
LED天花灯（橱柜灯，展柜灯）
产品特点：
1.Led 天花灯是采用优质的铝合金外壳，喷沙/氧化/喷漆与及钝化处理，外观铝合金材质，精致。还配有内置驱动电源。
2.光源寿命长达50，000小时。
3.有高能和节省能源的特点，比原始光源节省多达50%的能效。
4.无污染，非红外线，环保等特点。全新设计，铝制外壳比塑料外壳更易散热.
5.产品适用于家居装饰，商店展示橱窗，餐厅，办公室等室内装饰照明。
6.保修期:1年.
7.采用美国CREE光源或其他有保障光源,铝合金材质；具有光效高、光衰小、寿命长等优点；
8.产品广泛使用在橱柜照明，展柜照明，居家别墅照明，商业商场、酒店，写字楼休闲场所装饰照明等。
产品参数:
1.产品功率：1W,3W,4W,5W,7W,9W,12W,和18W
2.输入电压：AC90-260V
3.工作电压：23V
4.工作频率：50-60HZ
5.工作温度：50-65℃
6.环境温度：-20-+50℃
7.发光角度：30°、45°、60°
dzsc/17/2223/17222326.jpg
| Name |
Size
mm |
Wattage
w |
Life-time
h |
size (mm) |
Discription. |
| L |
W |
H |
|
| Downlight 1*1w |
Ø52 |
1 |
50,000 |
52mm |
52mm |
40mm |
Size:diameter52mm
Voltage:110v/220v
LED:1*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS.
|
| Downlight 3*1W |
Ø90 |
3 |
50,000 |
90mm |
90mm |
60mm |
Size:diameter95mm
Voltage:110v/220v
LED:3*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS
|
| Downlight 5*1W |
Ø107 |
5 |
50,000 |
107mm |
107mm |
60mm |
Size:diameter107mm
Voltage:110v/220v
LED:5*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS.
|
| Downlight 7*1W |
Ø107 |
7 |
50,000 |
107mm |
107mm |
70mm |
Size:Ø107mm
Voltage:110v/220v
LED:7*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS. |
| Downlight 7*1W |
Ø95 |
7 |
50,000 |
|
|
|
Size:Ø95mm
Voltage:110v/220v
LED:7*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS.
|
| Downlight 9*1 039 |
Ø135 |
9 |
50,000 |
135mm |
135mm |
60mm |
Size:diameter135mm
Voltage:110v/220v
LED:9*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS.
|
| Downlight 12*1W |
Ø135 |
12 |
50,000 |
135mm |
135mm |
70mm |
Description:Model:EDP-TH-018
Size:diameter135mm
Voltage:110v/220v
LED:12*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS.
|
| Downlight 15*1W |
Ø168 |
15 |
50,000 |
|
|
|
Size:Ø168*H145mm (140mm)
Voltage:110v/220v
LED:15*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS.
|
| Downlight 18*1W |
Ø168 |
18 |
50,000 |
|
|
|
Size:Ø168*H145mm
Voltage:110v/220v
LED:18*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS. |
| Downlight 14*1W |
|
14 |
50,000 |
|
|
|
Size:L360*W210mm
Voltage:110V/220V
LED:14*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS.
|
| Downlight 9*1W |
|
9 |
50,000 |
|
|
|
Voltage:110v/220v
LED:9*1W
Material:Aluminum alloy
Weight:g
Color:available in red,green,yellow,blue,white,warm white.
Quality certificate:CE,FCC,CCC,ROHS.
| |
