Part Number Chip λD(nm)If=20mA Angle2θ1/2 Vf(V)If=20mA IV(mcd)If=20mA Material Emitting color Min Max Min Max Min Max 2A4RX AlGaInP/GaAsP Red 620 660 60∽80 1.8 2.5 100 1000 2A4OX AlGaInP/GaAsP Orange 600 620 1.8 2.5 100 700 2A4YX AlGaInP/GaAsP Yellow 580 595 1.8 2.5 100 1000 2A4GX InGaN/GaN Green 490 550 2.8 3.6 150 1200 2A4WX InGaN/GaN White - - 2.8 3.6 150 1300 2A4BX InGaN/GaN Blue 440 480 2.8 3.6 150 800
Part Number Chip λD(nm)If=20mA Angle2θ1/2 Vf(V)If=20mA IV(mcd)If=20mA Material Emitting color Min Max Min Max Min Max 1A4RX AlGaInP/GaAsP Red 620 660 70∽90 1.8 2.5 100 800 1A4OX AlGaInP/GaAsP Orange 600 620 1.8 2.5 100 600 1A4YX AlGaInP/GaAsP Yellow 580 595 1.8 2.5 100 800 1A4GX InGaN/GaN Green 490 550 2.8 3.6 150 1000 1A4WX InGaN/GaN White - - 2.8 3.6 150 1100 1A4BX InGaN/GaN Blue 440 480 2.8 3.6 150 800
