供应色环电感
| 价 格： | 0.06 | |
| 型号/规格： | LGA0307 | |
| 品牌/商标： | 三一 | |
| 环保类别： | 无铅环保型 | |
| 主要用途： | 家用电器 | |
| 额定电流： | 0.02A | |
| 额定电压： | 220V | |
| 外形尺寸： | 3x7mm |
Features 特征
1. Coating epoxy resin that ensures the humidity resistance to be long life.
树脂涂装可耐环境干燥及长寿命
2. Low Cost. 低成本
Applications 用途
1. Electronics products 电子产品
2. Communication equipment 通讯器材
3. Computer Devices 电脑周边器材
4. TV, VCR 电视，摄影机
Product Identification：产品识别
LGA 0307 – 100 K
1 2 3 4
1. Product Type 产品类型
2. Size尺寸：0204,0307,0410,0510
3. Inductance 电感值 100 for 10uH
4. Tolerance 误差值（J±5%，K±10%，M±20%）
Electrical Characteristics for LGA Series
LGA系列电气特性参数
|
Part NO. |
L (μH) |
Q (MIN) |
Freq. (MHz) |
SRF(MHz)(min) |
DCR(Ω)(max) |
IDC(mA)(max) | ||||||||||
|
0204 |
0307 |
0410 |
0204 |
0307 |
0410 |
0204 |
0307 |
0410 |
0204 |
0307 |
0410 |
0204 |
0307 |
0410 | ||
|
1R0K |
1.0 |
50 |
65 |
50 |
25.2 |
25.2 |
25.2 |
110 |
180 |
157 |
0.22 |
0.12 |
0.09 |
270 |
700 |
920 |
|
1R2K |
1.2 |
40 |
50 |
50 |
7.96 |
7.96 |
7.96 |
100 |
165 |
144 |
0.30 |
0.18 |
0.10 |
260 |
700 |
880 |
|
1R5K |
1.5 |
40 |
50 |
55 |
7.96 |
7.96 |
7.96 |
80 |
150 |
131 |
0.35 |
0.20 |
0.23 |
250 |
700 |
830 |
|
1R8K |
1.8 |
40 |
70 |
60 |
7.96 |
7.96 |
7.96 |
65 |
125 |
121 |
0.45 |
0.23 |
0.25 |
240 |
655 |
790 |
|
2R2K |
2.2 |
40 |
50 |
80 |
7.96 |
7.96 |
7.96 |
55 |
85 |
110 |
0.55 |
0.25 |
0.28 |
230 |
630 |
750 |
|
2R7K |
2.7 |
40 |
60 |
85 |
7.96 |
7.96 |
7.96 |
50 |
80 |
100 |
0.60 |
0.28 |
0.30 |
220 |
595 |
720 |
|
3R3K |
3.3 |
40 |
60 |
90 |
7.96 |
7.96 |
7.96 |
42 |
75 |
94 |
0.65 |
0.30 |
0.34 |
210 |
575 |
670 |
|
3R9K |
3.9 |
45 |
60 |
90 |
7.96 |
7.96 |
7.96 |
38 |
65 |
86 |
0.85 |
0.32 |
0.37 |
200 |
555 |
640 |
|
4R7K |
4.7 |
45 |
50 |
90 |
7.96 |
7.96 |
7.96 |
34 |
45 |
80 |
1.00 |
0.35 |
0.39 |
190 |
530 |
620 |
|
5R6K |
5.6 |
45 |
50 |
80 |
7.96 |
7.96 |
7.96 |
32 |
36 |
74 |
1.15 |
0.40 |
0.43 |
180 |
500 |
590 |
|
6R8K |
6.8 |
40 |
50 |
80 |
7.96 |
7.96 |
7.96 |
27 |
30 |
58 |
1.20 |
0.45 |
0.48 |
175 |
470 |
550 |
|
8R2K |
8.2 |
40 |
50 |
85 |
7.96 |
7.96 |
7.96 |
26 |
28 |
53 |
1.25 |
0.55 |
0.52 |
165 |
425 |
530 |
|
100K |
10 |
40 |
50 |
85 |
7.96 |
7.96 |
7.96 |
24 |
22 |
45 |
1.5 |
0.72 |
0.58 |
160 |
370 |
500 |
|
120K |
12 |
50 |
50 |
75 |
2.52 |
2.52 |
2.52 |
19 |
20 |
30 |
2.2 |
0.80 |
0.63 |
150 |
350 |
480 |
|
150K |
15 |
50 |
50 |
75 |
2.52 |
2.52 |
2.52 |
18 |
16 |
20 |
2.5 |
0.88 |
0.72 |
145 |
335 |
460 |
|
180K |
18 |
50 |
50 |
70 |
2.52 |
2.52 |
2.52 |
17 |
15 |
14 |
2.8 |
1.00 |
0.77 |
140 |
315 |
430 |
|
220K |
22 |
50 |
60 |
65 |
2.52 |
2.52 |
2.52 |
16 |
13 |
7.9 |
3.0 |
1.20 |
0.84 |
130 |
285 |
410 |
|
270K |
27 |
55 |
60 |
65 |
2.52 |
2.52 |
2.52 |
14 |
11 |
7.6 |
3.5 |
1.35 |
0.94 |
80 |
270 |
390 |
|
330K |
33 |
55 |
50 |
55 |
2.52 |
2.52 |
2.52 |
13 |
10 |
6.3 |
3.8 |
1.50 |
1.03 |
76 |
255 |
370 |
|
390K |
39 |
50 |
50 |
55 |
2.52 |
2.52 |
2.52 |
12 |
9.5 |
6.3 |
4.2 |
1.70 |
1.12 |
74 |
240 |
350 |
|
470K |
47 |
50 |
50 |
45 |
2.52 |
2.52 |
2.52 |
11 |
8.5 |
6.3 |
5.8 |
2.30 |
1.22 |
70 |
205 |
340 |
|
560K |
56 |
50 |
55 |
45 |
2.52 |
2.52 |
2.52 |
10 |
7.5 |
6.2 |
6.4 |
2.60 |
1.34 |
68 |
195 |
320 |
|
680K |
68 |
50 |
55 |
40 |
2.52 |
2.52 |
2.52 |
9.5 |
6.5 |
5.7 |
7.2 |
3.20 |
1.47 |
64 |
185 |
305 |
|
820K |
82 |
50 |
55 |
35 |
2.52 |
2.52 |
2.52 |
9.0 |
6.0 |
5.3 |
8.5 |
3.50 |
1.62 |
46 |
175 |
290 |
|
101K |
100 |
50 |
60 |
30 |
2.52 |
2.52 |
2.52 |
7.2 |
5.5 |
4.8 |
11 |
3.80 |
1.80 |
44 |
165 |
275 |
|
121K |
120 |
30 |
75 |
70 |
0.796 |
0.796 |
0.796 |
6.5 |
5.4 |
3.8 |
19 |
3.80 |
3.70 |
42 |
160 |
185 |
|
151K |
150 |
30 |
75 |
80 |
0.796 |
0.796 |
0.796 |
6.0 |
4.75 |
3.5 |
22 |
4.40 |
4.20 |
39 |
150 |
175 |
|
181K |
180 |
30 |
75 |
80 |
0.796 |
0.796 |
0.796 |
5.2 |
4.35 |
3.3 |
24 |
5.0 |
4.60 |
37 |
140 |
165 |
|
221K |
220 |
30 |
75 |
70 |
0.796 |
0.796 |
0.796 |
4.5 |
4.0 |
3.0 |
28 |
5.7 |
5.10 |
35 |
130 |
155 |
|
271K |
270 |
30 |
70 |
70 |
0.796 |
0.796 |
0.796 |
3.5 |
3.7 |
2.8 |
29 |
6.5 |
5.80 |
28 |
120 |
145 |
|
331K |
330 |
30 |
70 |
65 |
0.796 |
0.796 |
0.796 |
3.0 |
3.4 |
2.6 |
30 |
9.5 |
6.40 |
26 |
100 |
137 |
|
391K |
390 |
30 |
70 |
65 |
0.796 |
0.796 |
0.796 |
2.7 |
2.8 |
2.4 |
32 |
10.5 |
7.00 |
25 |
95 |
133 |
|
471K |
470 |
30 |
70 |
60 |
0.796 |
0.796 |
0.796 |
2.6 |
2.4 |
2.25 |
35 |
12.5 |
7.70 |
24 |
90 |
126 |
|
561K |
560 |
30 |
70 |
60 |
0.796 |
0.796 |
0.796 |
2.5 |
2.2 |
2.1 |
40 |
14.5 |
8.50 |
23 |
85 |
120 |
|
681K |
680 |
30 |
70 |
55 |
0.796 |
0.796 |
0.796 |
2.2 |
2.0 |
1.95 |
42 |
18.0 |
9.40 |
22 |
75 |
113 |
|
821K |
820 |
30 |
60 |
55 |
0.796 |
0.796 |
0.796 |
2.1 |
1.6 |
1.85 |
46 |
23.7 |
12.0 |
21 |
65 |
100 |
|
102K |
1000 |
30 |
60 |
50 |
0.796 |
0.796 |
0.252 |
2.0 |
1.15 |
1.40 |
52 |
30.0 |
17.0 |
20 |
60 |
100 |
|
J:+5%; K:+10% ; M:+20% | ||||||||||||||||
Electrical Characteristics for LGA Series
LGA系列电气特性参数
|
Part NO. |
L |
Q (MIN) |
Freq. (MHz) |
SRF(MHz)(min) (MHz)MIN |
DCR(Ω)(max) |
IDC(mA)(max) | ||||||||||||||||
|
0204 |
0307 |
0410 |
0204 |
0307 |
0410 |
0204 |
0307 |
0410 |
0204 |
0307 |
0410 |
0204 |
0307 |
0410 | ||||||||
|
R10 |
0.10 |
50 |
40 |
50 |
25.2 25.2 25.2 |
250 |
470 |
470 |
0.030 |
0.08 |
0.04 |
700 |
700 |
900 | ||||||||
|
R12 |
0.12 |
55 |
40 |
50 |
25.2 25.2 25.2 |
230 |
450 |
450 |
0.035 |
0.08 |
0.06 |
660 |
700 |
900 | ||||||||
|
R15 |
0.15 |
55 |
40 |
50 |
25.2 25.2 25.2 |
200 |
430 |
430 |
0.040 |
0.09 |
0.07 |
620 |
700 |
890 | ||||||||
|
R18 |
0.18 |
55 |
40 |
50 |
25.2 25.2 25.2 |
180 |
410 |
410 |
0.045 |
0.10 |
0.07 |
600 |
700 |
890 | ||||||||
|
R22 |
0.22 |
55 |
40 |
50 |
25.2 25.2 25.2 |
160 |
380 |
380 |
0.050 |
0.12 |
0.08 |
400 |
700 |
880 | ||||||||
|
R27 |
0.27 |
50 |
40 |
50 |
25.2 25.2 25.2 |
150 |
360 |
340 |
0.065 |
0.15 |
0.09 |
380 |
680 |
800 | ||||||||
|
R33 |
0.33 |
50 |
40 |
50 |
25.2 25.2 25.2 |
150 |
350 |
300 |
0.075 |
0.16 |
0.10 |
370 |
680 |
750 | ||||||||
|
R39 |
0.39 |
50 |
40 |
50 |
25.2 25.2 25.2 |
150 |
320 |
280 |
0.080 |
0.18 |
0.12 |
350 |
680 |
680 | ||||||||
|
R47 |
0.47 |
60 |
40 |
50 |
25.2 25.2 25.2 |
150 |
300 |
250 |
0.085 |
0.26 |
0.16 |
330 |
650 |
650 | ||||||||
|
R56 |
0.56 |
60 |
40 |
50 |
25.2 25.2 25.2 |
150 |
280 |
230 |
0.090 |
0.38 |
0.18 |
320 |
500 |
600 | ||||||||
|
R68 |
0.68 |
50 |
40 |
50 |
25.2 25.2 25.2 |
120 |
250 |
210 |
0.10 |
0.42 |
0.22 |
310 |
500 |
550 | ||||||||
|
R82 |
0.82 |
50 |
40 |
50 |
25.2 25.2 25.2 |
110 |
200 |
172 |
0.15 |
0.55 |
0.24 |
290 |
450 |
980 | ||||||||
|
| ||||||||||||||||||||||
|
Part Number |
L |
L Freq. (MHz) |
Q (MIN) |
Q Freq. (MHz) |
DCR(Ω)(max) |
IDC(mA)(max) | ||||||||||||||||
|
0510-122K |
1.2 |
1KHz |
80 |
0.252 |
9 |
75 | ||||||||||||||||
|
0510-152K |
1.5 |
1KHz |
80 |
0.252 |
10 |
69 | ||||||||||||||||
|
0510-182K |
1.8 |
1KHz |
80 |
0.252 |
11 |
60 | ||||||||||||||||
|
0510-222K |
2.2 |
1KHz |
80 |
0.252 |
14 |
58 | ||||||||||||||||
|
0510-272K |
2.7 |
1KHz |
80 |
0.252 |
18 |
52 | ||||||||||||||||
|
0510-332K |
3.3 |
1KHz |
80 |
0.252 |
22 |
48 | ||||||||||||||||
|
0510-392K |
3.9 |
1KHz |
80 |
0.252 |
26 |
45 | ||||||||||||||||
|
0510-472K |
4.7 |
1KHz |
80 |
0.252 |
32 |
40 | ||||||||||||||||
|
0510-562K |
5.6 |
1KHz |
70 |
0.252 |
34 |
37 | ||||||||||||||||
|
0510-682K |
6.8 |
1KHz |
70 |
0.252 |
45 |
34 | ||||||||||||||||
|
0510-822K |
8.2 |
1KHz |
50 |
0.252 |
60 |
31 | ||||||||||||||||
|
0510-103K |
10 |
1KHz |
50 |
0.0796 |
70 |
28 | ||||||||||||||||
|
0510-123K |
12 |
1KHz |
50 |
0.0796 |
82 |
24 | ||||||||||||||||
|
0510-153K |
15 |
1KHz |
50 |
0.0796 |
89 |
22 | ||||||||||||||||
|
0510-183K |
18 |
1KHz |
40 |
0.0796 |
141 |
14 | ||||||||||||||||
|
0510-223K |
22 |
1KHz |
40 |
0.0796 |
170 |
12 | ||||||||||||||||
|
0510-253K |
25 |
1KHz |
40 |
0.0796 |
185 |
11 | ||||||||||||||||
|
0510-273K |
27 |
1KHz |
40 |
0.0796 |
210 |
9.5 | ||||||||||||||||
|
0510-303K |
30 |
1KHz |
40 |
0.0796 |
240 |
8.5 | ||||||||||||||||
|
0510-333K |
33 |
1KHz |
40 |
0.0796 |
250 |
8.0 | ||||||||||||||||
|
J:+5%; K:+10% ; M:+20% | ||||||||||||||||||||||
- 所属城市：广东 珠海
- [联系时请说明来自维库仪器仪表网]
- 联系人： 舒小姐
- 电话：0756-8818578
- 传真：0756-8818579
- 手机：
- QQ ：
供应工字电感
信息内容：Features (特征) ● Open Magnetic circuit construction 开磁路构造设计 ● Low cost and high reliability 低成本及高可靠性 Applications (用途) ● Notebook, Inkjet printer, Copying machine, Display monitor, Cellular phone, ADSL modem, Gaming machine, Color TV, Video tape recorder, Video camera, Microwave oven, Lighting and Car electronics. 笔记本型电脑，喷墨打印机，影印机，显示监视器，手机，宽频数据机，游戏机，彩色电视，录放影机，摄影机，微波炉，照明设备，汽车电子产品 Product Identification：产品识别 LGB 0608 – 101 K 1 2 3 4 1. Product Type 产品类型 2. CORE Size 磁芯尺寸 3. Inductance电感值 101 for 100uH 4. Tolerance 误差值 (J 5%,K 10%,L 15%,M 20%,N 30%) Electrical Characteristics for LGB Series LGB系列电气特性参数 Part NO. Inductance(μH) IDC(mA)(Max) DCR(Ω)Max 0406 0608 0810 0912 1012 1016 1415 0406 0608 0810 0912 1012 1016 1415 1R0K 1.0 2000 4000 5500 ...
供应六孔磁珠
信息内容：Features (特征) ● Compact,medium current(up to 3 Amps) high impedance EMI suppression component. 体型小,大小电流(达3安培), 大阻抗值, 有效抑制EMI电磁波。 Applications:(应用) ● Power and signal filtering 电源和信号滤波 Product Identification：产品识别 IR6HX10 -2.5T 1 2 1. Product Type 产品类型 2. Turn 圈数 Shape and Size：（Dimensions are in mm） 图示和尺寸：（单位mm） P/N Z Ω MIN Freq. MHz Turn IR6HX10-1.5T 280 120 1.5 IR6HX10-2.0T 480 100 2.0 IR6HX10-2.5T 600 100 2.5 IR6HX10-3.0T 680 100 3 IR6HX10-1.5T+1.5T 600 100 1.5+1.5 Test Equipment：测试设备 Z: HP4191A RF Impedance analyzer
