Application
1. Industrial Electronic Instrument, PLC, Timers, Temperature Control & Measure.
2. White goods.
3. Building Automation.
4. Air Conditioner.
5. Actuating Driver.
Performance (at Initial Value)
􀂄 Contact Resistance.............100 mΩ Max.@1A,6VDC
􀂄 Operate Time.......................8 mSec. Max.
􀂄 Release Time......................4 mSec. Max.
􀂄 Dielectric Strength:
Between Coil & Contact......4,000VAC at 50/60 Hz
for one minute.
Between Contacts...............1,000VAC at 50/60 Hz
for one minute.
􀂄 Surge Strength....................10,000V (between coil
& contact 1.2x50μSec.)
􀂄 Insulation Resistance..........100 MegaΩ Min. at
500VDC.
􀂄 Max. On/Off Switching:
Electrical..............................15 Cycles per Minute.
Mechanical..........................300 Cycles per Minute.
􀂄 Temperature Range.............-40～85°C
􀂄 Humidity Range...................45～85% RH.
􀂄 Coil Temperature Rise.........40°C Max.
􀂄 Vibration:
Endurance...........................10 to 55 Hz dual
amplitude width
1.5mm.
Error Operation....................10 to 55 Hz dual
amplitude width
1.5mm.
􀂄 Shock:
Endurance...........................1,000m/S2.
Error Operation....................100 m/S2.
􀂄 Life Expectancy:
Mechanical..........................107 Operations at No
load condition.
Electrical..............................105 Operations at Rated Resistive Load.
􀂄 Weight.................................about 6.0 g.
Safety Standard & Its File Number
􀂄 C-UL....................................E141060
􀂄 VDE.....................................40013405
