P6KE
PART NUMBER |
REVERSE STAND-OFF VOLTAGE V RWM (V) |
BREAKDOWN VOLTAGE V BR (V) MIN.@I T |
BREAKDOWN VOLTAGE V BR (V) MAX.@I T |
TEST CURRENT I T (mA) |
MAXIMUM CLAMPING VOLTAGE @Ipp Vc(V) |
PEAK PULSE CURRENT Ipp(A) |
REVERSE LEAKAGE @V RWM I R ( µA ) |
| UNI-POLAR |
BI-POLAR |
P6KE6.8A
P6KE7.5A
P6KE8.2A
P6KE9.1A |
P6KE6.8CA
P6KE7.5CA
P6KE8.2CA
P6KE9.1CA |
5.80
6.40
7.02
7.78 |
6.45
7.13
7.79
8.65 |
7.14
7.88
8.61
9.55 |
10
10
10
1 |
10.5
11.3
12.1
13.4 |
58.1
54.0
50.4
45.5 |
1000
500
200
50 |
P6KE10A
P6KE11A
P6KE12A
P6KE13A |
P6KE10CA
P6KE11CA
P6KE12CA
P6KE13CA |
8.55
9.40
10.20
11.10 |
9.50
10.50
11.40
12.40 |
10.50
11.60
12.60
13.70 |
1
1
1
1 |
14.5
15.6
16.7
18.2 |
42.1
39.1
36.5
33.5 |
10
5
5
5 |
P6KE15A
P6KE16A
P6KE18A
P6KE20A |
P6KE15CA
P6KE16CA
P6KE18CA
P6KE20CA |
12.80
13.60
15.30
17.10 |
14.30
15.20
17.10
19.00 |
15.80
16.80
18.90
21.00 |
1
1
1
1 |
21.2
22.5
25.2
27.7 |
28.8
27.1
24.2
22.0 |
5
5
5
5 |
P6KE22A
P6KE24A
P6KE27A
P6KE30A |
P6KE22CA
P6KE24CA
P6KE27CA
P6KE30CA |
18.80
20.50
23.10
25.60 |
20.90
22.80
25.70
28.50 |
23.10
25.20
28.40
31.50 |
1
1
1
1 |
30.6
33.2
37.5
41.4 |
19.9
18.4
16.3
14.7 |
5
5
5
5 |
P6KE33A
P6KE36A
P6KE39A
P6KE43A |
P6KE33CA
P6KE36CA
P6KE39CA
P6KE43CA |
28.20
30.80
33.30
36.80 |
31.40
34.20
37.10
40.90 |
34.70
37.80
41.00
45.20 |
1
1
1
1 |
45.7
49.9
53.9
59.3 |
13.3
12.2
11.3
10.3 |
5
5
5
5 |
P6KE47A
P6KE51A
P6KE56A
P6KE62A |
P6KE47CA
P6KE51CA
P6KE56CA
P6KE62CA |
40.20
43.60
47.80
53.00 |
44.70
48.50
53.20
58.90 |
49.40
53.60
58.80
65.10 |
1
1
1
1 |
64.8
70.1
77.0
85.0 |
9.4
8.7
7.9
7.2 |
5
5
5
5 |
P6KE68A
P6KE75A
P6KE82A
P6KE91A |
P6KE68CA
P6KE75CA
P6KE82CA
P6KE91CA |
58.10
64.10
70.10
77.80 |
64.60
71.30
77.90
86.50 |
71.40
78.80
86.10
95.50 |
1
1
1
1 |
92.0
103.0
113.0
125.0 |
6.6
5.9
5.4
4.9 |
5
5
5
5 |
P6KE100A
P6KE110A
P6KE120A
P6KE130A |
P6KE100CA
P6KE110CA
P6KE120CA
P6KE130CA |
85.50
94.00
102.00
111.00 |
95.00
105.00
114.00
124.00 |
105.00
116.00
126.00
137.00 |
1
1
1
1 |
137.0
152.0
165.0
179.0 |
4.5
4.0
3.7
3.4 |
5
5
5
5 |
P6KE150A
P6KE160A
P6KE170A
P6KE180A |
P6KE150CA
P6KE160CA
P6KE170CA
P6KE180CA |
128.00
136.00
145.00
154.00 |
143.00
152.00
162.00
171.00 |
158.00
168.00
179.00
189.00 |
1
1
1
1 |
207.0
219.0
234.0
246.0 |
2.9
2.8
2.6
2.5 |
5
5
5
5 |
P6KE200A
P6KE220A
P6KE250A
P6KE300A |
P6KE200CA
P6KE220CA
P6KE250CA
P6KE300CA |
171.00
185.00
214.00
256.00 |
190.00
209.00
237.00
285.00 |
210.00
231.00
263.00
315.00 |
1
1
1
1 |
274.0
328.0
344.0
414.0 |
2.2
1.9
1.8
1.5 |
5
5
5
5 |
P6KE350A
P6KE400A
P6KE440A
P6KE480A |
P6KE350CA
P6KE400CA
P6KE440CA
P6KE480CA |
300.00
342.00
376.00
408.00 |
332.00
380.00
418.00
456.00 |
368.00
420.00
462.00
504.00 |
1
1
1
1 |
482.0
548.0
602.0
658.0 |
1.3
1.1
1.0
0.9 |
5
5
5
5 |
P6KE510A
P6KE530A
P6KE540A
P6KE550A |
P6KE510CA
P6KE530CA
P6KE540CA
P6KE550CA |
434.00
450.00
459.00
467.00 |
485.00
503.50
513.00
522.50 |
535.00
556.50
567.00
577.50 |
1
1
1
1 |
698.0
725.0
740.0
760.0 |
0.9
0.8
0.8
0.8 |
5
5
5
5 |
