供应.Steute电感式传感器
| 价 格： | 面议 | |
| 型号/规格： | EEx IS M12 B | |
| 品牌/商标： | steute |
型号：EEx IS M12 B
防爆1区，2区，21区，22区
金属外壳
寿命长
特别版本可以用在粉尘22区
Standards IEC 6
EN 50284; EN 5
Enclosure brass-nickel, PA
Nuts 2, brass-nickel
Switching system 3-wire DC; 3D version:
per DIN EN 6
Termination 2 m pre-wired cable PVC 2 x 0.5 mm2,
3D version: plug-in connector M12 x 1, 4-pole
Protection class IP 67
Switching distance sn EEx IS M12 b: 2 mm,
EEx IS M12 nb: 4 mm
Switching distance in % steel St 37: 100 %, stainless steel: 70 %, brass: 50 %, copper: 45 %, aluminium: 40 %
Input power Pi max. 50 mW
Input voltage Ui max. 12.6 VDC
Input current Ii max. 15.9 mA
Tightening torque for the nuts M12x1: 10 Nm
Ambient temperature –25 °C … +75 °C
Ex-marking II 1G EEx ia IIC T6,
II 1D IP67 T100°C
Approvals TÜV 06ATEX 553179
- 所属城市：北京 北京市
- [联系时请说明来自维库仪器仪表网]
- 联系人： 沈小姐
- 电话：010-62164681
- 传真：010-62985217
- 手机：13011890458
- QQ ：
供应.Steute防爆磁传感器
信息内容：型号：EEx RC 15 .Steute防爆磁传感器 防爆1区，2区，21区，22区 黄铜外壳 长寿命 开关距离可达30毫米 电缆长度1米 特别版本可以用在粉尘22区 Standards IEC 60947-5-2; EN 60079-0; EN 60079-18; EN 61241-0; EN 61241-1 Enclosure brass, nickeled Actuator series M permanent magnet Protection class IP 67 according to EN 60529 Contact material silver Switching system reed contacts Contact types NC contact, NO contact or change-over contact Termination cable, H05VV-F or Lapptherm 145 Cable section 1NO, 1NC: 3 x 0.75 mm2, 1CO: 4 x 0.75 mm2 Cable length 1, 2 and 5 m Switching voltage 250 V Switching current 1.5 A Switching capacity 1NC, 1CO: max.50 VA/W, 1NO: max.100 VA/W Utilisation category AC-15, DC-13 Bounce duration 0.3 … 0.,6 ms Ambient temperature H05VV-F: –20 °C … +70 ºC, Lapptherm 145: -40 °C … +70 °C Mechanical life > 1 million operations Electrical life 106 … 109 operations Switching time »Close« 3.5 … 4.5 ...
供应.Steute安全传感器
信息内容：型号：BZ 16 热塑性外壳 变频驱动 Standards IEC/EN 60947-5-3; EN 954-1; EN 1088 Enclosure glass-fibre reinforced, shock-proof thermoplastic, self-extinguishing Actuator BZ 16-B1 Protection class IP 67 or IP 69K to IEC/EN 60529 Contact material – Switching system Hall sensor Contact types 1 NC/1NO contact or 2 NC contacts Termination terminal space with self opening terminal for max. 2 x 1.5 mm2 (including conductor ferrules) Cable entry 3 x M20 x 1.5 Cable length – Uimp 24 VDC +/ -15 % Max. fuse rating 0.25 A gL/gG D-fuse Power consumption < 4 W Outputs Utilisation category AC-15, DC-13 Ie/Ue 2.5 A/250 VAC, 2.5 A/24 VDC Switching voltage max. 250 VAC Switching current max. 4 A Switching capacity max. 1000 VA Max. fuse rating 4 A gL/gG D-fuse Switching frequency max. 1 Hz Bounce duration - Ambient temperature 0 °C … +55 ºC Mechanical life > 10 million operations Electrical life – Switching time “Close” < 200 m...
