BGA测试座/BGA原型贴片测试插座,Clameshell Type

价格：		面议
型号/规格：		E-TEC
品牌/商标：		E-TEC

详细介绍
企业详情

www.lingmei.com.cn

Over View

Clamshell sockets are available for any chip size and grid pattern
Available in SMT, thru-hole and solderless compression type versions
Compact design
Custom versions available on request.

dzsc/16/9129/16912919.gifClamshell-Type BGA Socket Data Sheet

dzsc/16/9129/16912919.jpg
　

MECHANICAL DATA

Contact life:	10,000 cycles min.
Retention System life:	10,000 cycles min.
Solderability:	exceeds MIL-STD-202 Method 208
Individual contact force:	40 grams max.

MATERIAL

Insulator (RoHS Compliant):	High temp plastic or epoxy FR4
Terminal (RoHS compliant):	Brass
Contact (RoHS compliant):	BeCu

ELECTRICAL DATA

Contact resistance:	< 100 mΩ
Current rating:	500 mA max.
Insulation resistance at 500V DC:	100 MΩ if 0.50 to 0.80mm pitch 500 MΩ 1.00mm pitch upwards
Breakdown voltage at 60 Hz:	500V min.
Capacitance:	< 1 pF
Inductance:	< 2 nH
Operating temperature:	-55°C to +125°C ; 260°C for 60 sec.
