COSEL电源模块,ZUW系列DC-DC电源模块
| 价 格： | 面议 | |
| 型号/规格： | DC-DC | |
| 品牌/商标： | ZUW152412 |
http://www.lm-power.cn
ZUW系列
Low-profile isolated DC-DC converters supporting 5V • 12V • 24V • 48V input. Comes with metal case. Wide lineup of 1.5W-25W/dual output allows you to select a product most optimal to the load.
| 产品名称 | 输入电压(V) | 输出电压(V) | 效率(%) | 输出功率(W) | 外观尺寸 |
| ZUW1R50512 | 4.5-9 | ±12V | 67 | 1.5 | 27.5*7*18 |
| ZUW1R50515 | 4.5-9 | ±15V | 67 | 1.5 | 27.5*7*18 |
| ZUW1R51212 | 9-18 | ±12V | 71 | 1.5 | 27.5*7*18 |
| ZUW1R51215 | 9-18 | ±15V | 71 | 1.5 | 27.5*7*18 |
| ZUW1R52412 | 18-36 | ±12V | 71 | 1.5 | 27.5*7*18 |
| ZUW1R52415 | 18-36 | ±15V | 71 | 1.5 | 27.5*7*18 |
| ZUW1R54812 | 36-72 | ±12V | 71 | 1.5 | 27.5*7*18 |
| ZUW1R54815 | 36-72 | ±15V | 71 | 1.5 | 27.5*7*18 |
| ZUW30512 | 4.5-9 | ±12V | 70 | 3 | 35*7*23 |
| ZUW30515 | 4.5-9 | ±15V | 70 | 3 | 35*7*23 |
| ZUW31212 | 9-18 | ±12V | 74 | 3 | 35*7*23 |
| ZUW31215 | 9-18 | ±15V | 74 | 3 | 35*7*23 |
| ZUW32412 | 18-36 | ±12V | 74 | 3 | 35*7*23 |
| ZUW32415 | 18-36 | ±15V | 74 | 3 | 35*7*23 |
| ZUW34812 | 36-72 | ±12V | 75 | 3 | 35*7*23 |
| ZUW34815 | 36-72 | ±15V | 75 | 3 | 35*7*23 |
| ZUW60512 | 4.5-9 | ±12V | 75 | 6 | 44.5*7*28 |
| ZUW60515 | 4.5-9 | ±15V | 75 | 6 | 44.5*7*28 |
| ZUW61212 | 9-18 | ±12V | 77 | 6 | 44.5*7*28 |
| ZUW61215 | 9-18 | ±15V | 77 | 6 | 44.5*7*28 |
| ZUW62412 | 18-36 | ±12V | 77 | 6 | 44.5*7*28 |
| ZUW62415 | 18-36 | ±15V | 77 | 6 | 44.5*7*28 |
| ZUW64812 | 36-72 | ±12V | 77 | 6 | 44.5*7*28 |
| ZUW64815 | 36-72 | ±15V | 77 | 6 | 44.5*7*28 |
| ZUW100512 | 4.5-9 | ±12V | 75 | 8.4 | 45*7*35 |
| ZUW100515 | 4.5-9 | ±15V | 75 | 9 | 45*7*35 |
| ZUW101215 | 9-18 | ±15V | 81 | 10.5 | 45*7*35 |
| ZUW102415 | 9-18 | ±15V | 81 | 10.5 | 45*7*35 |
| ZUW104815 | 18-36 | ±15V | 81 | 10.5 | 45*7*35 |
| ZUW101212 | 18-36 | ±12V | 81 | 10.8 | 45*7*35 |
| ZUW102412 | 36-72 | ±12V | 81 | 10.8 | 45*7*35 |
| ZUW104812 | 36-72 | ±12V | 81 | 10.8 | 45*7*35 |
| ZUW150512 | 4.5-9 | ±12V | 81 | 14.4 | 45*8.5*50 |
| ZUW150515 | 4.5-9 | ±15V | 81 | 15 | 45*8.5*50 |
| ZUW151215 | 9-18 | ±12V | 83 | 15 | 45*8.5*50 |
| ZUW152415 | 9-18 | ±15V | 83 | 15 | 45*8.5*50 |
| ZUW154815 | 18-36 | ±15V | 83 | 15 | 45*8.5*50 |
| ZUW151212 | 18-36 | ±12V | 83 | 15.6 | 45*8.5*50 |
| ZUW152412 | 36-72 | ±12V | 83 | 15.6 | 45*8.5*50 |
| ZUW154812 | 36-72 | ±12V | 83 | 15.6 | 45*8.5*50 |
| ZUW250515 | 4.5-9 | ±15V | 82 | 20.1 | 65*8.5*50 |
| ZUW250512 | 4.5-9 | ±12V | 82 | 20.2 | 65*8.5*50 |
| ZUW251212 | 9-18 | ±12V | 85 | 25.2 | 65*8.5*50 |
| ZUW252412 | 9-18 | ±12V | 85 | 25.2 | 65*8.5*50 |
| ZUW254812 | 18-36 | ±12V | 85 | 25.2 | 65*8.5*50 |
| ZUW251215 | 18-36 | ±15V | 85 | 25.5 | 65*8.5*50 |
| ZUW252415 | 36-72 | ±15V | 85 | 25.5 | 65*8.5*50 |
| ZUW254815 | 36-72 | ±15V | 85 | 25.5 | 65*8.5*50 |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 蔡
- 电话：0755-82915895/82915035/82915136/82964948
- 传真：0755-82916505
- 手机：
- QQ ：
PLCC座，PLCC插座，LCC座，LCC插座
信息内容：高品质PLCC插座（"Hi-rel" SMT/Soldertail PLCC SOCKET) E-tec „hi-rel“ SMT/ Soldertail PLCC sockets correspond to JEDEC Norms. Precision stamped contact design provides special „push-down effect“ onto the leads of the chip. For very high shock and vibration applications a chip retention clip can be obtained on request. Inside polarisation corner prevents wrong insertion of the chips. Stand-off’s under the base prevent solder shorts. Chips can be easily removed with the Universal extraction tool PUL-200. http://www.lingmei.com.cn/PLCC-LCC%20Socket.htm
