供应日本LAMBDA DC/DC电源PH50-PH300系列

价格：		面议
型号/规格：		PH50S110-5,PH100S280-12,PH300F110-15
品牌/商标：		TDK-LAMBDA

详细介绍
企业详情

DC TYPE POWER SUPPLIES (DC TO DC CONVERTERS)

窗体顶端

Result: 1 - 100 of 162

No.	Part Number	Product Lifecycle Stage	Shape	Symbol of Mount	Insulation	Multi Output	Input Voltage Edc(Max) [V]	Output Voltage 1(Nom) [V]	Output Current 1(Max) [A]	Output Voltage 2(Nom) [V]	Output Current 2(Max) [A]	Maximum Output Power(Max) [W]	Body Length(L)(Nom) [mm]	Body Breadth(W)(Nom) [mm]	Body Height(T)(Nom) [mm]
1	PH100F24-12	PROD	power-module		insulation	1	36	12	8.4			100.8	83	86	12.7
2	PH100F24-15	PROD	power-module		insulation	1	36	15	6.7			100.5	83	86	12.7
3	PH100F24-2	PROD	power-module		insulation	1	36	2	20			40	83	86	12.7
4	PH100F24-24	PROD	power-module		insulation	1	36	24	4.2			100.8	83	86	12.7
5	PH100F24-28	PROD	power-module		insulation	1	36	28	3.6			100.8	83	86	12.7
6	PH100F24-3	PROD	power-module		insulation	1	36	3	20			60	83	86	12.7
7	PH100F24-5	PROD	power-module		insulation	1	36	5	20			100	83	86	12.7
8	PH100S280-12	PROD	power-module		insulation	1	400	12	8.4			100.8	62	86	12.7
9	PH100S280-15	PROD	power-module		insulation	1	400	15	6.7			100.5	62	86	12.7
10	PH100S280-24	PROD	power-module		insulation	1	400	24	4.2			100.8	62	86	12.7
11	PH100S280-28	PROD	power-module		insulation	1	400	28	3.6			100.8	62	86	12.7
12	PH100S280-3.3	PROD	power-module		insulation	1	400	3.3	20			66	62	86	12.7
13	PH100S280-5	PROD	power-module		insulation	1	400	5	20			100	62	86	12.7
14	PH100S48-12	PROD	power-module		insulation	1	76	12	8.4			100.8	62	86	12.7
15	PH100S48-15	PROD	power-module		insulation	1	76	15	6.7			100.5	62	86	12.7
16	PH100S48-24	PROD	power-module		insulation	1	76	24	4.2			100.8	62	86	12.7
17	PH100S48-28	PROD	power-module		insulation	1	76	28	3.6			100.8	62	86	12.7
18	PH100S48-3.3	PROD	power-module		insulation	1	76	3.3	20			66	62	86	12.7
19	PH100S48-5	PROD	power-module		insulation	1	76	5	20			100	62	86	12.7
20	PH150F110-12	PROD	power-module		insulation	1	185	12	12.5			150	83	86	12.7
21	PH150F110-15	PROD	power-module		insulation	1	185	15	10			150	83	86	12.7
22	PH150F110-2	PROD	power-module		insulation	1	185	2	30			60	83	86	12.7
23	PH150F110-24	PROD	power-module		insulation	1	185	24	6.3			151.2	83	86	12.7
24	PH150F110-28	PROD	power-module		insulation	1	185	28	5.4			151.2	83	86	12.7
25	PH150F110-3	PROD	power-module		insulation	1	185	3	30			90	83	86	12.7
26	PH150F110-5	PROD	power-module		insulation	1	185	5	30			150	83	86	12.7
27	PH150F280-12	PROD	power-module		insulation	1	400	12	12.5			150	83	86	12.7
28	PH150F280-15	PROD	power-module		insulation	1	400	15	10			150	83	86	12.7
29	PH150F280-2	PROD	power-module		insulation	1	400	2	30			60	83	86	12.7
30	PH150F280-24	PROD	power-module		insulation	1	400	24	6.3			151.2	83	86	12.7
31	PH150F280-28	PROD	power-module		insulation	1	400	28	5.4			151.2	83	86	12.7
32	PH150F280-3	PROD	power-module		insulation	1	400	3	30			90	83	86	12.7
33	PH150F280-5	PROD	power-module		insulation	1	400	5	30			150	83	86	12.7
34	PH150F48-12	PROD	power-module		insulation	1	76	12	12.5			150	83	86	12.7
35	PH150F48-15	PROD	power-module		insulation	1	76	15	10			150	83	86	12.7
36	PH150F48-2	PROD	power-module		insulation	1	76	2	30			60	83	86	12.7
37	PH150F48-24	PROD	power-module		insulation	1	76	24	6.3			151.2	83	86	12.7
38	PH150F48-28	PROD	power-module		insulation	1	76	28	5.4			151.2	83	86	12.7
39	PH150F48-3	PROD	power-module		insulation	1	76	3	30			90	83	86	12.7
40	PH150F48-5	PROD	power-module		insulation	1	76	5	30			150	83	86	12.7
41	PH150S110-12	PROD	power-module		insulation	1	185	12	12.5			150	72	86	12.7
42	PH150S110-15	PROD	power-module		insulation	1	185	15	10			150	72	86	12.7
43	PH150S110-24	PROD	power-module		insulation	1	185	24	6.3			151.2	72	86	12.7
44	PH150S110-28	PROD	power-module		insulation	1	185	28	5.4			151.2	72	86	12.7
45	PH150S110-5	PROD	power-module		insulation	1	185	5	30			150	72	86	12.7
46	PH150S280-12	PROD	power-module		insulation	1	400	12	12.5			150	72	86	12.7
47	PH150S280-15	PROD	power-module		insulation	1	400	15	10			150	72	86	12.7
48	PH150S280-24	PROD	power-module		insulation	1	400	24	6.3			151.2	72	86	12.7
49	PH150S280-28	PROD	power-module		insulation	1	400	28	5.4			151.2	72	86	12.7
50	PH150S280-3.3	PROD	power-module		insulation	1	400	3.3	30			99	72	86	12.7
51	PH150S280-5	PROD	power-module		insulation	1	400	5	30			150	72	86	12.7
52	PH150S48-12	PROD	power-module		insulation	1	76	12	12.5			150	72	86	12.7
53	PH150S48-15	PROD	power-module		insulation	1	76	15	10			150	72	86	12.7
54	PH150S48-24	PROD	power-module		insulation	1	76	24	6.3			151.2	72	86	12.7
55	PH150S48-28	PROD	power-module		insulation	1	76	28	5.4			151.2	72	86	12.7
56	PH150S48-3.3	PROD	power-module		insulation	1	76	3.3	30			99	72	86	12.7
57	PH150S48-5	PROD	power-module		insulation	1	76	5	30			150	72	86	12.7
58	PH300F110-12	PROD	power-module		insulation	1	185	12	25			300	146	86	12.7
59	PH300F110-15	PROD	power-module		insulation	1	185	15	20			300	146	86	12.7
60	PH300F110-2	PROD	power-module		insulation	1	185	2	60			120	146	86	12.7
61	PH300F110-24	PROD	power-module		insulation	1	185	24	12.6			302.4	146	86	12.7
62	PH300F110-28	PROD	power-module		insulation	1	185	28	10.8			302.4	146	86	12.7
63	PH300F110-3	PROD	power-module		insulation	1	185	3	60			180	146	86	12.7
64	PH300F110-5	PROD	power-module		insulation	1	185	5	60			300	146	86	12.7
65	PH300F24-12	PROD	power-module		insulation	1	36	12	20			240	146	86	12.7
66	PH300F24-28	PROD	power-module		insulation	1	36	28	10.8			302.4	146	86	12.7
67	PH300F280-12	PROD	power-module		insulation	1	400	12	25			300	146	86	12.7
68	PH300F280-15	PROD	power-module		insulation	1	400	15	20			300	146	86	12.7
69	PH300F280-2	PROD	power-module		insulation	1	400	2	60			120	146	86	12.7
70	PH300F280-24	PROD	power-module		insulation	1	400	24	12.6			302.4	146	86	12.7
71	PH300F280-28	PROD	power-module		insulation	1	400	28	10.8			302.4	146	86	12.7
72	PH300F280-3	PROD	power-module		insulation	1	400	3	60			180	146	86	12.7
73	PH300F280-5	PROD	power-module		insulation	1	400	5	60			300	146	86	12.7
74	PH300F48-12	PROD	power-module		insulation	1	76	12	25			300	146	86	12.7
75	PH300F48-15	PROD	power-module		insulation	1	76	15	20			300	146	86	12.7
76	PH300F48-2	PROD	power-module		insulation	1	76	2	60			120	146	86	12.7
77	PH300F48-24	PROD	power-module		insulation	1	76	24	12.6			302.4	146	86	12.7
78	PH300F48-28	PROD	power-module		insulation	1	76	28	10.8			302.4	146	86	12.7
79	PH300F48-3	PROD	power-module		insulation	1	76	3	60			180	146	86	12.7
80	PH300F48-5	PROD	power-module		insulation	1	76	5	60			300	146	86	12.7
81	PH300S280-12	PROD	power-module		insulation	1	400	12	25			300	83	86	12.7
82	PH300S280-15	PROD	power-module		insulation	1	400	15	20			300	83	86	12.7
83	PH300S280-24	PROD	power-module		insulation	1	400	24	12.5			300	83	86	12.7
84	PH300S280-28	PROD	power-module		insulation	1	400	28	10.8			302.4	83	86	12.7
85	PH300S280-3.3	PROD	power-module		insulation	1	400	3.3	50			165	83	86	12.7
86	PH300S280-48	PROD	power-module		insulation	1	400	48	6.3			302.4	83	86	12.7
87	PH300S280-5	PROD	power-module		insulation	1	400	5	50			250	83	86	12.7
88	PH300S48-12	PROD	power-module		insulation	1	76	12	25			300	83	86	12.7
89	PH300S48-15	PROD	power-module		insulation	1	76	15	20			300	83	86	12.7
90	PH300S48-24	PROD	power-module		insulation	1	76	24	12.5			300	83	86	12.7
91	PH300S48-28	PROD	power-module		insulation	1	76	28	10.8			302.4	83	86	12.7
92	PH300S48-3.3	PROD	power-module		insulation	1	76	3.3	50			165	83	86	12.7
93	PH300S48-48	PROD	power-module		insulation	1	76	48	6.3			302.4	83	86	12.7
94	PH300S48-5	PROD	power-module		insulation	1	76	5	50			250	83	86	12.7
95	PH50S110-12	PROD	power-module		insulation	1	185	12	4.2			50.4	41	86	12.7
96	PH50S110-15	PROD	power-module		insulation	1	185	15	3.4			51	41	86	12.7
97	PH50S110-24	PROD	power-module		insulation	1	185	24	2.1			50.4	41	86	12.7
98	PH50S110-28	PROD	power-module		insulation	1	185	28	1.8			50.4	41	86	12.7
99	PH50S110-5	PROD	power-module		insulation	1	185	5	10			50	41	86	12.7
100	PH50S24-12	PROD	power-module		insulation	1	36	12	4.2			50.4	41	86	12.7
No.	Part Number	Product Lifecycle Stage	Shape	Symbol of Mount	Insulation	Multi Output	Input Voltage Edc(Max) [V]	Output Voltage 1(Nom) [V]	Output Current 1(Max) [A]	Output Voltage 2(Nom) [V]	Output Current 2(Max) [A]	Maximum Output Power(Max) [W]	Body Length(L)(Nom) [mm]	Body Breadth(W)(Nom) [mm]	Body Height(T)(Nom) [mm]
101	PH50S24-15	PROD	power-module		insulation	1	36	15	3.4			51	41	86	12.7
102	PH50S24-24	PROD	power-module		insulation	1	36	24	2.1			50.4	41	86	12.7
103	PH50S24-28	PROD	power-module		insulation	1	36	28	1.8			50.4	41	86	12.7
104	PH50S24-3.3	PROD	power-module		insulation	1	36	3.3	10			33	41	86	12.7
105	PH50S24-5	PROD	power-module		insulation	1	36	5	10			50	41	86	12.7
106	PH50S280-12	PROD	power-module		insulation	1	400	12	4.2			50.4	41	86	12.7
107	PH50S280-15	PROD	power-module		insulation	1	400	15	3.4			51	41	86	12.7
108	PH50S280-24	PROD	power-module		insulation	1	400	24	2.1			50.4	41	86	12.7
109	PH50S280-28	PROD	power-module		insulation	1	400	28	1.8			50.4	41	86	12.7
110	PH50S280-3.3	PROD	power-module		insulation	1	400	3.3	10			33	41	86	12.7
111	PH50S280-5	PROD	power-module		insulation	1	400	5	10			50	41	86	12.7
112	PH50S48-12	PROD	power-module		insulation	1	76	12	4.2			50.4	41	86	12.7
113	PH50S48-15	PROD	power-module		insulation	1	76	15	3.4			51	41	86	12.7
114	PH50S48-24	PROD	power-module		insulation	1	76	24	2.1			50.4	41	86	12.7
115	PH50S48-28	PROD	power-module		insulation	1	76	28	1.8			50.4	41	86	12.7
116	PH50S48-3.3	PROD	power-module		insulation	1	76	3.3	10			33	41	86	12.7
117	PH50S48-5	PROD	power-module		insulation	1	76	5	10			50	41	86	12.7
118	PH600S280-12	PROD	power-module		insulation	1	400	12	50			600	146	86	12.7
119	PH600S280-15	PROD	power-module		insulation	1	400	15	40			600	146	86	12.7
120	PH600S280-24	PROD	power-module		insulation	1	400	24	25			600	146	86	12.7
121	PH600S280-28	PROD	power-module		insulation	1	400	28	21.5			602	146	86	12.7
122	PH600S280-3.3	PROD	power-module		insulation	1	400	3.3	100			330	146	86	12.7
123	PH600S280-48	PROD	power-module		insulation	1	400	48	12.5			600	146	86	12.7
124	PH600S280-5	PROD	power-module		insulation	1	400	5	100			500	146	86	12.7
125	PH75F110-12	PROD	power-module		insulation	1	185	12	6.3			75.6	62	86	12.7
126	PH75F110-15	PROD	power-module		insulation	1	185	15	5			75	62	86	12.7
127	PH75F110-2	PROD	power-module		insulation	1	185	2	15			30	62	86	12.7
128	PH75F110-24	PROD	power-module		insulation	1	185	24	3.2			76.8	62	86	12.7
129	PH75F110-28	PROD	power-module		insulation	1	185	28	2.7			75.6	62	86	12.7
130	PH75F110-3	PROD	power-module		insulation	1	185	3	15			45	62	86	12.7
131	PH75F110-5	PROD	power-module		insulation	1	185	5	15			75	62	86	12.7
132	PH75F280-12	PROD	power-module		insulation	1	400	12	6.3			75.6	62	86	12.7
133	PH75F280-15	PROD	power-module		insulation	1	400	15	5			75	62	86	12.7
134	PH75F280-2	PROD	power-module		insulation	1	400	2	15			30	62	86	12.7
135	PH75F280-24	PROD	power-module		insulation	1	400	24	3.2			76.8	62	86	12.7
136	PH75F280-28	PROD	power-module		insulation	1	400	28	2.7			75.6	62	86	12.7
137	PH75F280-3	PROD	power-module		insulation	1	400	3	15			45	62	86	12.7
138	PH75F280-5	PROD	power-module		insulation	1	400	5	15			75	62	86	12.7
139	PH75F48-12	PROD	power-module		insulation	1	76	12	6.3			75.6	62	86	12.7
140	PH75F48-15	PROD	power-module		insulation	1	76	15	5			75	62	86	12.7
141	PH75F48-2	PROD	power-module		insulation	1	76	2	15			30	62	86	12.7
142	PH75F48-24	PROD	power-module		insulation	1	76	24	3.2			76.8	62	86	12.7
143	PH75F48-28	PROD	power-module		insulation	1	76	28	2.7			75.6	62	86	12.7
144	PH75F48-3	PROD	power-module		insulation	1	76	3	15			45	62	86	12.7
145	PH75F48-5	PROD	power-module		insulation	1	76	5	15			75	62	86	12.7
146	PH75S110-12	PROD	power-module		insulation	1	185	12	6.3			75.6	41	86	12.7
147	PH75S110-15	PROD	power-module		insulation	1	185	15	5			75	41	86	12.7
148	PH75S110-24	PROD	power-module		insulation	1	185	24	3.2			76.8	41	86	12.7
149	PH75S110-28	PROD	power-module		insulation	1	185	28	2.7			75.6	41	86	12.7
150	PH75S110-5	PROD	power-module		insulation	1	185	5	15			75	41	86	12.7
151	PH75S280-12	PROD	power-module		insulation	1	400	12	6.3			75.6	41	86	12.7
152	PH75S280-15	PROD	power-module		insulation	1	400	15	5			75	41	86	12.7
153	PH75S280-24	PROD	power-module		insulation	1	400	24	3.2			76.8	41	86	12.7
154	PH75S280-28	PROD	power-module		insulation	1	400	28	2.7			75.6	41	86	12.7
155	PH75S280-3.3	PROD	power-module		insulation	1	400	3.3	15			49.5	41	86	12.7
156	PH75S280-5	PROD	power-module		insulation	1	400	5	15			75	41	86	12.7
157	PH75S48-12	PROD	power-module		insulation	1	76	12	6.3			75.6	41	86	12.7
158	PH75S48-15	PROD	power-module		insulation	1	76	15	5			75	41	86	12.7
159	PH75S48-24	PROD	power-module		insulation	1	76	24	3.2			76.8	41	86	12.7
160	PH75S48-28	PROD	power-module		insulation	1	76	28	2.7			75.6	41	86	12.7
161	PH75S48-3.3	PROD	power-module		insulation	1	76	3.3	15			49.5	41	86	12.7
162	PH75S48-5	PROD	power-module		insulation	1	76	5	15			75	41	86	12.7

窗体底端

西安浩南电子科技有限公司

公司信息未核实

所属城市：陕西西安
[联系时请说明来自维库仪器仪表网]
联系人： 刘彦成
电话：029-88231631
传真：029-88231651/65676937/65676938
手机：13720726368
QQ ：

公司相关产品

供应WHM1535AE、WHM2040AE万通WanTcom功率放大器

信息内容：

WanTcom是一家正在迅速成长的射频/微波及通讯子系统的器件设计和制造公司。其产品主要应用在无线通讯和网络通讯领域。WanTcom（万通）公司的核心竞争力主要体现在依托强大的设计能力，为客户提供高性能和高可靠性的产品。WanTcom（万通）公司的标准产品包括低噪声放大器（LNA）、超线性功率放大器（PA）。此外，WanTcom（万通）公司还能根据客户的技术要求提供的性价比和解决方案的定制产品。　　WanTcom（万通）提供的射频/微波放大器和相关的子系统，其噪声系数可低至0.35dB、IP3可高达 60 dBm。产品的应用领域涵盖了蜂窝通信基站、微波通讯、雷达前端、卫星通讯、微波及射频的测试和测量应用。　　WanTcom（万通）还可以依据MIL-STD-202和MIL-STD-883标准提供高质量核高性能的OEM产品。WHM02AE WHM0003AE WHM0520-18AE WHM25-1525AE WHM2026AE WHM0510AEWHM1722AE WHM0105AE WHM0530AE WHM0525AE WHM1045AE WHM13-3530AEWHM1535AE WHM2040AE WHM0913R WHM0002AE WHM04-2045AE WHM0010AEWHM0202AE WHM005-15AE WHM0715AE WHM0015AE WHM16-2550AWBA0510AS WBA1730-40A WBA3340-40A WBA1045B WB...

详细内容>>

供应WHM0530AE/WHM0525AE万通WanTcom低噪声放大器

信息内容：

详细内容>>

维库仪器仪表

供应日本LAMBDA DC/DC电源PH50-PH300系列

供应WHM1535AE、WHM2040AE万通WanTcom功率放大器

供应WHM0530AE/WHM0525AE万通WanTcom低噪声放大器

相关产品
