308

JS-RELAYS
VDE

ULTRA-MINIATURE
PC BOARD TYPE
POWER RELAY

mm inch
16.4
.646
16
.630
22
.866

FEATURES

• Ultra-miniature size with universal terminal footprint
• High contact capacity: 10 A
• UL class B coil insulation type available
• TV-5 type available

1 Form A type

→

 TV-5
1 Form C type

→

 TV-5 (N.O. side only)

• VDE, TÜV also approved
• Sealed construction for automatic cleaning

SPECIFICATIONS

Contact
Coil
Characteristics

Arrangement 1 Form A, 1 Form C
Initial contact resistance, max.
(By voltage drop 6 V DC 1 A)
100 m

Ω

Contact material Silver alloy
Rating
(resistive
load)
Nominal switching capacity
10 A 125 V AC
6 A 277 V AC
Max. switching power 1,662 VA
Max. switching voltage 250 V AC, 100 V DC
Max. switching current 10 A (AC), 5 A (DC)
Expected
life
(min.ope.)
Mechanical (at 180 cpm) 10

7

Electrical at 10 A 125 V AC,
6 A 277 V AC resistive
(at 20 cpm)
10

5

Nominal operating power 360 mW
Max. operating speed 20 cpm
Initial insulation resistance Min. 100 M

Ω

 (at 500 V DC)
Initial
breakdown
voltage*

1

Between open contacts 750 Vrms for 1 min.
Between contacts and coil 1,500 Vrms for 1 min.
Operate time*

2

(at nominal voltage)
Approx. 10 ms
Release time(without diode)*

2

 (at nominal
voltage)
Approx. 10 ms
Temperature rise (at nominal voltage) Max. 35

°

C
Shock resistance
Functional*

3

Min. 98 m/s

2

 {10 G}
Destructive*

4

Min. 980 m/s

2

 {100 G}
Vibration
resistance
Functional*

5

Approx. 98 m/s

2

 {10 G},
10 to 55 Hz at double
amplitude of 1.6 mm
Destructive
Approx. 117.6 m/s

2

 {12 G},
10 to 55 Hz at double
amplitude of 2 mm
Conditions for operation,
transport and storage*

6

(Not freezing and condens-
ing at low temperature)
Ambient
temp.
–40

°

C to +70

°

C
–40

°

F to +158

°

F
Humidity 5 to 85% R.H.
Unit weight Approx.12 g .423 oz

Remarks

* Specifications will vary with foreign standards certification ratings.
*

1

Detection current: 10mA
*

2

Excluding contact bounce time
*

3

Half-wave pulse of sine wave: 11ms; detection time: 10

µ

s
*

4

Half-wave pulse of sine wave: 6ms
*

5

Detection time: 10

µ

s
*

6

Refer to 5. Conditions for operation, transport and storage mentioned in AMBI-
ENT ENVIRONMENT (Page 61).

TYPICAL APPLICATIONS

1. Home appliances
Air conditioner, heater, etc.
2. Automotive
Power-window, car antenna, door-lock,
etc.
3. Office machines
PPC, facsimile, etc.
4. Vending machines

ORDERING INFORMATION
Ex. JS 1a B F 12V
Contact arrangement
1: 1 Form C
1a: 1 Form A
Nil: Class A insulation
B: Class B insulation
5, 6, 9, 12, 18, 24,
48 V
Coil insulation class
Nil: Sealed type
F: Flux-resistant type
Protective construction Coil voltage (DC)
UL/CSA, VDE, TÜV approved type is standard.
Notes:  1. Standard packing: Carton: 100 pcs. Case: 500 pcs.
             2. When ordering TV rated (TV-5) types, add suffix -TV.
JS

309

COIL DATA

Part No.
Nominal
voltage,
V DC
Pick-up
voltage,
V DC (max.)
(at 20

°

C68

°

F)
Drop-out
voltage,
V DC (min.)
(at 20

°

C68

°

F)
Coil
resistance,

Ω

 (

±

10%)
(at 20

°

C68

°

F)

Nominal
operating current,
mA (

±

10%)

(at 20

°

C68

°

F)
Nominal
operating
power, mW
(at 20

°

C68

°

F)
Max.
allowable
voltage
(at 60

°

C140

°

F)
Sealed type Flux-resistant type
1 Form A 1 Form C 1 Form A 1 Form C
JS1a-5V JS1-5V JS1aF-5V JS1F-5V 5 3.5 0.5 69.4 72
360
130%V of
nominal
voltage
JS1a-6V JS1-6V JS1aF-6V JS1F-6V 6 4.2 0.6 100 60
JS1a-9V JS1-9V JS1aF-9V JS1F-9V 9 6.3 0.9 225 40
JS1a-12V JS1-12V

JS1aF-12V

JS1F-12V 12 8.4 1.2 400 30
JS1a-18V JS1-18V

JS1aF-18V

JS1F-18V 18 12.6 1.8 900 20
JS1a-24V JS1-24V

JS1aF-24V

JS1F-24V 24 16.8 2.4 1,600 15
JS1a-48V JS1-48V

JS1aF-48V

JS1F-48V 48 33.6 4.8 6,400 7.5

DIMENSIONS

mm inch

Note: Terminal No. 4 is only for
1 Form C type

General tolerance:

±

0.3

±

.012
16
.630
0.4
.016
3.9
.154
0.8
.031
5 4 N.C.
1
2 3 N.O.
0.8
.031
0.24
.009
12.2
.480
16
.630
12
.472
0.4
.016
0.4
.016
22
.866
2.3
.091
1.2
.047
2
.079

Schematic (Bottom view)
1a
1c
PC board pattern (Copper-side view)
1a
1c

Tolerance:

±

0.1

±

.004
N.O.
COM COIL
N.O.
N.C.
COM COIL
12
.472
4-1.3 dia.
4-.051 dia.
12.2
.480
2
.079
12
.472
5-1.3 dia.
5-.051 dia.
12.2
.480
2
.079

REFERENCE DATA

1. Maximum value for switching capacity 2. Operate/release time

Sample: 25 pcs., JS1-12V

3. Life curve

Ambient temperature: Room temperature
Contact voltage, V
Contact current, A
10 30
1
10
100
100
AC resistive load
DC resistive load
–
–
80 100 120 140
2
0
4
6
8
10
Max.
Max.
Min.
Min.
x
x
Coil applied voltage, %V
Operate/release time, ms
Operate time
Release time
100
10
1
56789 01234 10
125V AC resistive load
Contact current, A
Life, ×104
JS

 310

4-(1). Coil temperature rise

Sample: 5 pcs., JS1-12V
Measured portion: Inside the coil
Contact current: 5 A

4-(2). Coil temperature rise

Sample: 5 pcs., JS1-12V
Measured portion: Inside the coil
Contact current: 10 A

5. Ambient temperature characteristics

Sample: 6 pcs., JS1-12V
80 120 100 140
10
20
30
40
0
Coil applied voltage, %V
Temperature rise, °C
50°C
25°C
70°C
80 120 100 140
10
20
30
40
0
50°C
25°C
70°C
Coil applied voltage, %V
Temperature rise, °C
–60 –40 –20 0
20
20
10
–10
–20
40 60 80
Ambient
temperature °C
Pick-up voltage
Drop-out voltage
Changing
ration, %

6. Electrical life test
(10 A 125 V AC, resistive load)

Sample: 6 pcs., JS1-12V
Operating speed: 20 cpm
Ambient temperature: room temperature

(Circuit)
Change of pick-up and drop-out voltage Change of contact resistance
10A 125V AC
Contact welding
detection and
Mis-contacting
detection circuit
x –
510
0
2
4
6
8
10
Max.
Max.
Min.
Min.
x –
No. of operations, ×104
Pick-up/drop-out voltage, V
Pick-up voltage
Drop-out voltage
10 5
0
60
20
40
80
100
Max.
Max.
Min.
Min.
x –x –
No. of operations, ×104
Contact resistance, mΩ
Contact on the N.C. side
Contact on the N.O. side

For Cautions for Use, see Relay Technical Information (Page 48 to 76).

9/1/2000 All Rights Reserved, © Copyright Matsushita Electric Works, Ltd.
