供应BGA测试座/老化测试座
| 价 格： | 面议 | |
| 型号/规格： | BGA测试座/老化测试座 | |
| 品牌/商标： | 进口 |
BGA老化测试座 BGA SOCKET Pitch=0.5mm
| PART NUMBER | PIN COUNT | BODY SIZE | GRID SIZE | MFR. |
| OTB-84(484)-0.5-14 | 84 | 7X7 | 12X12 | ENPLAS |
| BGA-96(288)-0.5-15 | 96 | 6X6 | 10X10 | ENPLAS |
| OTB-108(484)-0.5-09 | 108 | 8X8 | 14X14 | ENPLAS |
| BGA-113(484)-0.5-01 | 113 | 7X7 | 12 | ENPLAS |
| BGA-144(484)-0.5-03 | 144 | 8X8 | 14 | ENPLAS |
| BGA-160(484)-0.5-05 | 160 | 8X8 | 14 | ENPLAS |
| BGA-177(484)-0.5-07 | 177 | 9X9 | 15 | ENPLAS |
| BGA-192(484)-0.5-02 | 192 | 10X10 | 17 | ENPLAS |
| BGA-225(288)-0.5-08 | 225 | 10X10 | 18X18 | ENPLAS |
| OTB-244(484)-0.5-06 | 244 | 12X12 | 21X21 | ENPLAS |
| BGA-254(484)-0.5-04 | 254 | 11X11 | 21 | ENPLAS |
| BGA-256(288)-0.5-* | 256 | 9X9 | 16X16 | ENPLAS |
| BGA-256(288)-0.5-11 | 256 | 11X11 | 21X21 | ENPLAS |
| BGA-261(512)-0.5-03 | 261 | 12X12 | 22X22 | ENPLAS |
| OTB-280(484)-0.5-10 | 280 | 11X11 | 19X19 | ENPLAS |
| OTB-289(484)-0.5-06 | 289 | 12X12 | 21X21 | ENPLAS |
| BGA-320(784)-0.5-01 | 320 | 13X13 | 24X24 | ENPLAS |
| BGA-321(784)-0.5-02 | 321 | 14X14 | 25X25 | ENPLAS |
| OTB-356(784)-0.5-01 | 356 | 13X13 | 24X24 | ENPLAS |
| BGA-432(512)-0.5-* | 432 | 14X14 | 24X24 | ENPLAS |
- 所属城市：北京 北京市
- [联系时请说明来自维库仪器仪表网]
- 联系人： 刘小姐
- 电话：010-51601686
- 传真：010-82533566
- 手机：
- QQ ：
供应BGA测试座Pitch=0.75mm/老化测试座
信息内容：BGA老化测试座 BGA SOCKET Pitch=0.75mm 详细型号列表 Part Number Pin Count Pitch Grid Size IC Dimensions Socket Dimensions MFR. A x B C x D NP291-03617-* 36 0.75 6x6 6.5x10.50 28.5x27.3 YAMAICHI NP291-04805-3* AC-16001 36 0.75 6x8 6x8 64x64 YAMAICHI NP291-04002-2 AC-11318 40 0.75 5x8 7.628x9.228 27.5x22.5 YAMAICHI NP291-04002-2-G4-BF-* 40 0.75 5x8 5.74x7.48 27.5x22.5 YAMAICHI NP291-04009-2-G4-BF-* 40 0.75 5x8 5.857x7.508 27.5x22.5 YAMAICHI NP291-04013-* 40 0.75 6x11 5.55x9.10 18x24 YAMAICHI NP291-04019 40 0.75 6x11 6.15x10.65 16x19 YAMAICHI NP291-04414-* 44 0.75 6x11 7.75x14.35 18x24 YAMAICHI NP291-04808-*AC-13177 45 0.75 6x8 7.45x7.55 28.3x27.3 YAMAICHI NP291-04812 AC-15741 46 0.75 6x8 6.50x7.91 28.3x27.3 YAMAICHI NP291-04812-2-* AC-14680 46 0.75 6x8 6.50x7.91 28.3x27.3 YAMAICHI NP291-04805-1* 48 0.75 6x8 9x15 32x32 YAMAICHI NP291-04805-3* 48 0.75 6x8 ...
供应BGA测试座Pitch=0.8mm/老化测试座
信息内容：BGA老化测试座 BGA SOCKET Pitch=0.80mm Part Number Pitch () Pin Count MFR. OTB-54(192)-0.8-06 0.8 54 ENPLAS OTB-60(180)-0.8-07 0.8 60 ENPLAS OTB-60(108)-1.0X0.8-01 0.8 60 ENPLAS OTB-65(256)-0.8-09 0.8 65 ENPLAS OTB-64(144)-0.8-02 0.8 64 ENPLAS OTB-64(120)-0.8-01 0.8 64 ENPLAS OTB-72(150)-0.8-01 0.8 72 ENPLAS OTB-80(256)-0.8-19 0.8 80 ENPLAS OTB-80(180)-0.8-01 0.8 80 ENPLAS OTB-80(144)-0.8-02 0.8 80 ENPLAS OTB-81(256)-0.8-06 0.8 81 ENPLAS OTB-81(256)-0.8-07 0.8 81 ENPLAS OTB-92(180)-0.8-02 0.8 92 ENPLAS OTB-96(256)-0.8-22 0.8 96 ENPLAS OTB-100(256)-0.8-13 0.8 100 ENPLAS OTB-100(256)-0.8-10 0.8 100 ENPLAS OTB-100(144)-0.8-01 0.8 100 ENPLAS OTB-121(256)-0.8-17 0.8 121 ENPLAS OTB-128(192)-0.8-03 0.8 128 ENPLAS OTB-128(144)-0.8-03 0.8 128 ENPLAS OTB-144(256)-0.8-13 0.8 144 ENPLAS OTB-145(256)-0.8-12 0.8 145 ENPLAS OTB-156(484)-...
