INPUT

Voltage

115 / 230Vac ± 15%

Frequency

50 / 60Hz ± 5%

Fuses

Fuse 6.3A / 250V Slow-Blow

Range

Resolution

Accuracy

AC WITHSTAND VOLTAGE

Output Voltage, KVAC

0-3.50

0.01

± (2% of setting + 5V)

Output Frequency

50Hz/60Hz ±0.1%, User Selection

Output Waveform

Sine Wave , Crest Factor = 1.3 - 1.5

Output Regulation

± (1% of output + 5V), From no load to full load

SETTINGS

HI and LO-Limit current, mA

0.00-40.00

0.01

± (2% of setting + 2 counts)

Ramp Timer, second

0.1 - 999.9

0.1

± (0.1% of setting + 0.05 sec)

Dwell Timer, second

0, 0.2 - 999.9

(0=continuous)

Current Offset, mA

0.00-2.00

0.01

± (2% of setting + 2 counts)

DUT Output

ON/OFF BY User Selection

Arc Detection(Option)

1-9 ranges (9 is the most sensitivity)

DC WITHSTAND VOLTAGE

Output Voltage, KVDC

0 -3.50

0.01

± (2% of setting + 5V)

DC Output Ripple

<5 % at 4KV/5mA

SETTINGS

HI and LO-Limit current, mA

0.00 - 5.00

0.01

± (2% of setting + 2 counts)

Ramp Timer, second

0.1- 999.9

0.1

± (0.1% of setting + 0.05 sec)

Dwell Timer, second

0, 0.2 - 999.9

(0=continuous)

Current Offset, mA

0.00 - 0.20

0.01

± (2% of setting + 2 counts)

DUT Output

ON/OFF BY User Selection

Arc Detection(Option)

1-9 ranges (9 is the most sensitivity)

Discharge Time

No capacitive Load is < 30 msec, capacitive Load is < 100 msec.

Maximum Capacitive Load DC Mode

1µF < 1KV,0.5µF < 3KV,0.75µF < 2KV, 0.08µF < 4KV

INSULATION RESISTANCE

Output Voltage, DCV

100 - 1000

1

± (2% of reading + 5 volts)

SETTINGS

HI-Limit, resistance, MΩ

0,1 - 1000 (0 = OFF)

1

Same as Resistance MEASUREMENT Accuracy

Lo-Limit, resistance, MΩ

1 - 1000

Delay Timer, second

0, 0.5 - 999.9

0.1

± (0.1% of setting + 0.05 sec)

(0=continuous)

GROUND BOND

Output AC Current, A

3.0 – 30.0

0.1

± (2 % of setting + 0.02A)

Output Voltage, Vac

AC 6 volts Max.

Output Frequency, Hz

50Hz/60Hz ±0.1%, User Selection

Milliohm Offset

0-100

1

± (2 % of setting + 2 counts)

SETTINGS

HI and LO-Limit Resistance, mΩ

0 – 510 (3.0-10.0A)

1

± (2 % of setting + 2 counts )

0 – 200 (10.1-25.0A)

0 – 150 (25.1-30.0A)

Dwell Timer, second

0, 0.5 - 999.9

0.1

± (0.1% of setting + 0.05 sec)

(0 = continuous)

MEASUREMENT

Range

Resolution

Accuracy

Voltage, KV(AC/DC)

0.00 - 3.50

0.01

± (1.5 % of reading +1 count)

Voltage, Vdc (IR only)

0 - 1000

1

± (1.5% of reading + 2 counts)

AC Current, mA

0.00 - 40.00

0.01

± (2% of reading + 2 counts)

DC Current, mA

0.00 – 5.00

0.01

AC Current, A (G.B)

0.0-30.0

0.1

± (3 % of reading + 3 counts)

Resistance, MΩ (IR)

1-999.9

0.1/0.01

100-499V ± (7% of reading + 2 counts)

500-1000V ± (3% of reading + 2 counts)

Resistance, mΩ (GB)

0-510

1

± (2 % of reading + 2 counts)

RUN TEST

DUT POWER

AC Voltage

0 - 277.0V, Single phase unblance, 0 - 30.0A maximum

Current

30A maximun continuous

Power Rating

8400W maximum

DUT Protection

Short Circuit current 50A < 3 sec, Inrush Current 180A Response time 10u sec.

SETTINGS

HI and LO Limit AC Voltage, V

0.0-277.0

0.1

± (1.5% of setting + 0.2 V), 60.0-277V

HI and LO Limit AC Current, A

0.0-30.0

0.1

± (2% of setting + 2 counts)

HI and LO Limit AC Power, W

0 - 8400

1

± (5% of setting + 6 counts)

HI and LO Limit Power Factor

0.000-1.000

0.001

W/VA, calculated and displayed to three significant digits

HI and LO Limit Leakage Current

0.0-010.00, Hi-Limit

0.01

± (2% of setting + 2 counts)

0=OFF

Delay Time, second

0.2-999.9

0.1

± (0.1% of setting + 0.05 sec)

Dwell Time, second

0, 0.1-999.9 (0=continuous)
