现货供应！华仪（Extech）可程式交流电源供应器6705
| 价 格： | 1.00 | |
| 型号/规格： | 6705 | |
| 品牌/商标： | 华仪(Extech) |
简单介绍
·大型的 240 X 64 Graphic LCD 显示器，可同时显示 V,F,Arms,Apeak,P,PF,Time。·测试中可以透过飞梭旋纽(Rotary Knob)实时的调整显示中的电压/频率输出。
·Extech 6705 6710 6720 6730 6740 可程式交流电源供应器(Linear),咨询电话:0512-68551216/68551217/65090040
可程式交流电源供应器的详细介绍
·可编程设计；可以设定输出启始角度/结束角度及模拟突波(Surge)/下陷波(Drop)。
·可编辑50个记忆组；内含 9 测试步骤，记忆组间可连结测试仿真各种负载的电源特性。
·可储存呼叫 50 个记忆，且测试中可实时调整电压/频率的输出记忆功能。
·针对被测物的寿命试验，可设定自动测试循环的次数及以秒、分、时为单位的时间设定。
·使用先进的高密度电源技术设计，1KVA 容量高度只有 2U(8.9cm)。
·0.1mA/0.01W 量测分辨率(选配)，可节省自行外加 power meter 的成本。
·特殊的恒流装置，可轻易启动马达、压缩机等高启动电流之负载。
·可选配 Remote I/P(7 组记忆)接口自动化控制输出或 GPIB/RS232 接口作控制。
·输出过载、短路、过电压及过温度保护及警报。
·华仪 6705 6710 6720 6730 6740 可程式交流电源供应器(Linear),咨询电话:0512-68551216/68551217/65090040
|
Model |
6705 |
6710 |
6720 |
6730 |
6740 | ||
|
INPUT | |||||||
|
Phase |
1 Phase | ||||||
|
Voltage |
115/230Vac ± 15% |
230Vac ± 15% | |||||
|
Frequency |
47-63Hz | ||||||
|
OUTPUT | |||||||
|
Power rating |
500VA |
1000VA |
2000VA |
3000VA |
4000VA | ||
|
Max. Current(r.m.s) |
0-150V |
4.2A |
8.4A |
16.8A |
25.2A |
33.6A | |
|
0-300V |
2.1A |
4.2A |
8.4A |
12.6A |
16.8A | ||
|
Max. Current(peak) |
0-150V |
16.8A |
33.6A |
67.2A |
100.8A |
134.4A | |
|
0-300V |
8.4A |
16.8A |
33.6A |
50.4A |
67.2A | ||
|
Option 0-600V | |||||||
|
Max. Current(r.m.s) |
0-300V |
2.1A |
4.2A |
8.4A |
12.6A |
16.8A | |
|
0-600V |
1.05A |
2.1A |
4.2A |
6.3A |
8.4A | ||
|
Max. Current(peak) |
0-300V |
8.4A |
16.8A |
33.6A |
50.4A |
67.2A | |
|
0-600V |
4.2A |
8.4A |
16.8A |
25.2A |
33.6A | ||
|
Phase |
1Phase / 2W | ||||||
|
THD(Total Harmonic Distortation) |
<=0.5% at 45-500Hz (Resistive Load) | ||||||
|
Crest Factor |
>= 4 | ||||||
|
Line Regulation |
0.1% max for a ± 10% line change. | ||||||
|
Load Regulation |
<=0.5% (Resistive Load) | ||||||
|
Response Time |
< 100µS | ||||||
|
SETTING | |||||||
|
Voltage |
Range |
0-300V, 150/300V Auto or | |||||
|
0-600V,300/600V Auto(Option 0-600V) | |||||||
|
Resolution |
0.1V | ||||||
|
Accuracy |
±(0.5%+2 counts) | ||||||
|
Frequency |
Range |
45-500Hz | |||||
|
Resolution |
0.1Hz at 45-99.9Hz , 1Hz at 100-500Hz | ||||||
|
Accuracy |
±0.02% of setting | ||||||
|
Frequency |
Range |
45-1000Hz | |||||
|
(Option 45Hz-1KHz) |
Resolution |
0.1Hz at 45-99.9Hz , 1Hz at 100-1000Hz | |||||
|
|
Accuracy |
±0.02% of setting | |||||
|
Starting& Ending |
Range |
0-360° | |||||
|
Phase Angle |
Resolution |
1° | |||||
|
|
Accuracy |
±1°(45 - 65HZ) | |||||
|
MEASUREMENT | |||||||
|
Frequency |
Range |
0.0-1000.0Hz | |||||
|
Resolution |
0.1Hz | ||||||
|
Accuracy |
±0.1Hz | ||||||
|
Voltage |
Range |
0.0-300.0V / 0.0-600.0V | |||||
|
Resolution |
0.1V | ||||||
|
Accuracy |
± (0.5% of reading +2 counts) for 0-300V | ||||||
|
± (0.5% of reading +4 counts) for 0-600V | |||||||
|
Current(r.m.s) |
Range |
L |
0.000-3.500A | ||||
|
H |
3.00-35.00A | ||||||
|
Resolution |
L |
0.001A | |||||
|
H |
0.01A | ||||||
|
Accuracy |
L |
± (0.5% of reading +5 counts) for 0-300V | |||||
|
± (0.5% of reading +10 counts) for 0-600V | |||||||
|
H |
± (0.5% of reading +3 counts) | ||||||
|
Current(peak) |
Range |
0.0 -200.0A | |||||
|
Resolution |
0.1A | ||||||
|
Accuracy |
± (1% of reading +2 counts) | ||||||
|
Power |
Range |
L |
0.0-350.0W | ||||
|
H |
300-4000W | ||||||
|
Resolution |
L |
0.1W | |||||
|
H |
1W | ||||||
|
Accuracy |
L |
± (0.6% of reading +5 counts) | |||||
|
H |
± (0.6% of reading +2 counts) | ||||||
|
Power Factor |
Range |
0 - 1.000 | |||||
|
Resolution |
W / VA ,Calculated and displayed to three significant digits | ||||||
|
Accuracy | |||||||
