优惠供应台湾三华（sapphire）有源差分探头SI9010
| 价 格： | 1.00 | |
| 型号/规格： | SI9010 | |
| 品牌/商标： | 品极（Pintek） |
|
Model |
SI-9010 |
|
Bandwidth |
DC to 70MHz(-3db) |
|
Attenuation Ratio |
1:100/1000 |
|
Accuracy |
+/- 2% |
|
Input Impedance |
10Mohm//10pF each side to ground |
|
Input Voltage | |
|
-Differential Input Voltage |
+/-700V(DC+Peak AC)or 700Vrms@1/100 |
|
7000V(DC+Peak AC) or 5000Vrms@1/1000 | |
|
-Common Mode Voltage |
+/-7000V(DC+Peak AC)or 2500Vrms@1/100 & 1/1000 |
|
-Absolute Max. Voltage |
+/-7000V(DC+Peak AC) or 2500Vrms@1/100 & 1/ +/-7000V(DC+Peak AC)+/-7000V(DC+Peak AC) or 5000Vrms@1/100 & 1/ |
|
Output Voltagee=3>t Voltage | |
|
- Swing (into 50kohm load) |
+/-7V |
|
-Offset (typical) |
<+/-5mV |
|
-Noise (typical) |
0.9mVrms |
|
-Source Impedance (typical) |
50 ohm |
|
CMRR (typical) |
-80dB@50Hz; -60dB@1MHz |
|
Power Requirements | |
|
-Standard |
4xAA cells or 6VDC/200mA mains adaptor** or regulated 9VDC/120mA mains adaptor |
|
-Options |
Power leads |
|
Length of BNC Cable |
|
|
Length of Input Leads |
|
|
Weight (Including 4 cells) |
|
|
Dimension (LxWxH) |
|
