型号 | 可订制 |
面向高频50kHz以下大功率输出滤波电感和功率因数校正电感,具有体积小、重量轻、效率高等优点;铁芯开口,保证有优良的偏磁特性和恒电感特性;可在 -55癈—130癈温度范围内稳定地工作 。 PFC Inductors Character:Made of Fe-based amorphous ribbon, the inductors have high saturation magnetic flux density, high permeability, low loss. The open-loop core is characterized by fine constant inductance,good resistance to DC magnetic biasing and low loss. Application:Used as the inductors of various power supplies, especially as the output filter inductors of the high power great current supply and PFC inductors of the air-conditioner’s power supply. Specifications:
Type Constant inductance range Permeability Loss P 0.05T/2KHz (W/kg) OFC3 0~1600A/m 500 < 1 OFC2 0~4000A/m 200~250 2~4 OFC1 0~8000A/m 100~150 5 Type The size of the core(mm) The size of the protective box(mm) OD ID H OD ID H OFC2-20-12-08 20 12 8 24.8 10.4 11.6 OFC2-26-16-05 26 16 5 30.6 14.2 9.9 OFC2-26-16-10 26 16 10 30.6 14.2 13.6 OFC2-32-20-10 32 20 10 36.7 18 13.6 OFC2-40-25-10 40 25 10 45 22.6 13.6 OFC2-40-25-15 40 25 15 45 22.6 16.8 OFC2-50-32-15 50 32 15 55.3 29.6 16.8 OFC2-64-40-20 64 40 20 67.5 37.6 23.8 OFC2-60-41-25 60 41 25 66.7 37 29 OFC2-70-40-25 60 35 25 65.7 30 30 铁基非晶环形电感及功率因数校正电感
Note:Other specification of the PFC inductors may be consulted and specially designed.
型号 可定制 if(!properExist){ displayOfferProperties("middlePropertyData", "propertyArea"); } 面向高频50kHz以下大功率输出滤波电感和功率因数校正电感,具有体积小、重量轻、效率高等优点;铁芯开口,保证有优良的偏磁特性和恒电感特性;可在 -55°C—130°C温度范围内稳定地工作 。
性能特点: 具有高饱和磁感应强度、高导磁率和低铁损(是硅钢片的1/5 ~ 1/10),另外还有体积小、绕线少、性能稳定性高、滤波效果和抗干扰能力强、音质好、音效佳等显著特点。主要应用于音响输出变压器、PFC 磁芯、高频放大器、逆变电源中的电抗器磁芯及中高频变压器磁芯。 非晶、微晶合金与硅钢片磁芯性能比较: 性能指标 铁基非晶 微晶合金 冷轧硅钢 饱和磁感 Bs ( T ) 1.56 1.25 2.03 磁导率(μm) 45×104 60×104 4×104 矫顽力 Hc (A/M) 4 1.2 30 铁损( W/Kg ) P1.0T/1KHz ≤ 4 P0.2T/20KHz ≤ 3.4 P1.0T/1KHz ≤ 20 电阻率( μΩ•cm ) 130 130 47 比重 d(g/cm3) 7.2 x103 7.25 7.65 磁芯型号:内窗口宽(b)×内窗口长(c)-叠厚 (a)×带宽即磁芯的高度(d)
