供应信号继电器FTR-MY/5.0*20.0*12.0
| 价 格： | 面议 | |
| 型号/规格： | FTR-MYAA024E/FTR-MYAA012E/FTR-MYAA009E/FTR-MYAA005E | |
| 品牌/商标： | FUJI/富士 |
FTR-MY
RoHS compliant since beginning of production
| Type | Power | |
| Status | Active | |
| Datasheet | PDF FTR-MY Series [456KB] | |
| Footprint | PDF FTR-MY Series [177KB] | |
| Description | Power relay: 1-pole, 3A, slim power relay suitable for such high density mounting and low profile applications as PLCs. | |
| Specifications | |
|---|---|
| Contact Rating | |
| Dimension | 5.0 x 20.0 x 12.0mm |
| Shape | Slim |
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 陈树辉
- 电话：0755-82534577/13076512089
- 传真：0755-82534577
- 手机：13686868407
- QQ ：
供应5A信号继电器G5SB/20.3*10.3*15.8
信息内容：G5SB PCB Relay Compact Single-pole Relay for Switching 5 A(Normally Open Contact), Fan Control of Air Conditioners, and Heating Control of Small Appliances. Environment-friendly, Pb-free. Compact SPDT Relay with high insulation. Incorporates a normally open contact that switches 5 A max. Ensures a withstand impulse voltage of 8,000 V between the coil and contacts. Conforms to UL and CSA.· UL508· CSA C22.2 (No.14)· VDE approval is in progress
供应15A小型功率继电器943糸列/19*15.5*15.5
信息内容：ORDERING INFORMATION 943 - 1A - 12 D S F 1 2 3 4 5 6 1 Model Number 943 2 Contact Arrangement1A = 1 Form A (SPST-NO)1B = 1 Form B (SPST-NC) 1C = 1 Form C (SPDT) 3 Coil Voltage3-48V 4 Coil Type D: DC 5 EnclosureNil = General TypeS = Sealed Type 6 Type Of Insulation Nil = Class A F = Class F COIL RATINGS (at 20℃) COILTYPE Coil NominalVoltage (V) CoilResistance(Ω+-10%) Pick-UpVoltage (V)<= Drop-OutVoltage (V)>= NominalCurrent(mA) DC Standard Coils 3 25 2.25 0.3 120 5 70 3.75 0.5 71 6 100 4.5 0.6 60 9 225 6.75 0.9 40 12 400 9 1.2 30 18 900 13.5 1.8 20 24 1600 18 2.4 15 48 6400 36 4.8 7.5 * Max Continuous Voltage at 20℃: 130% of Coil Nominal Voltage. Referential Data dzsc/15/4586/15458613.GIF OUTLINE DIMENSIONS dzsc/15/4586/15458613.gif Inter...
