供应干簧式继电器G1A050000/G1A120000/G1A240000

价 格： 面议
型号/规格：G1A050000/G1A120000/G1A240000
品牌/商标：COSMO

G Type
Type Number contact FORM Contact Resistance(mohm Max) Insulation Resistance (ohm min) Power Consumtion (VA max) Maximum Switching Voltage Maximum Switching Current Minimum Breakdown Voltage Nominal Voltage Must Operate(VDC) Coil Resistance e+/-10% Must Release(VDC) Circuit UL
G1A030000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 3 2.1 63 0.3
dzsc/15/4584/15458463.JPG
G1A050000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 5 3.5 500 0.5
dzsc/15/4584/15458463.JPG
G1A060000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 6 4.2 500 0.6
dzsc/15/4584/15458463.JPG
G1A080000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 8 5.6 700 0.8
dzsc/15/4584/15458463.JPG
G1A090000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 9 6.3 700 0.9
dzsc/15/4584/15458463.JPG
G1A120000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 12 8.4 1050 1.2
dzsc/15/4584/15458463.JPG
 ◎
G1A240000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 24 16.8 2080 2.4
dzsc/15/4584/15458463.JPG
G1A031000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 3 2.1 63 0.3
dzsc/15/4584/15458463.JPG
G1A051000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 5 3.5 500 0.5
dzsc/15/4584/15458463.JPG
G1A061000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 6 4.2 500 0.6
dzsc/15/4584/15458463.JPG
G1A081000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 8 5.6 700 0.8
dzsc/15/4584/15458463.JPG
G1A091000 100 100 100G 10 200 VDC 0.5A 1500 VDC 9 6.3 700 0.9
dzsc/15/4584/15458463.JPG
G1A121000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 12 8.4 1050 1.2
dzsc/15/4584/15458463.JPG
 ◎
G1A241000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 24 16.8 2080 2.4
dzsc/15/4584/15458463.JPG
G1A032000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 3 2.1 63 0.3
dzsc/15/4584/15458463.JPG
G1A052000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 5 3.5 500 0.5
dzsc/15/4584/15458463.JPG
G1A062000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 6 4.2 500 0.6
dzsc/15/4584/15458463.JPG
G1A082000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 8 5.6 700 0.8
dzsc/15/4584/15458463.JPG
G1A092000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 9 6.3 700 0.9
dzsc/15/4584/15458463.JPG
G1A122000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 12 8.4 1050 1.2
dzsc/15/4584/15458463.JPG
 ◎
G1A242000 1A SPST 100 100G 10 200 VDC 0.5A 1500 VDC 24 16.8 2080 2.4
dzsc/15/4584/15458463.JPG
G2A030000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 3 2.1 63 0.3
dzsc/15/4584/15458463.JPG
G2A050000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 5 3.5 500 0.5
dzsc/15/4584/15458463.JPG
G2A060000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 6 4.2 500 0.6
dzsc/15/4584/15458463.JPG
G2A080000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 8 5.6 700 0.8
dzsc/15/4584/15458463.JPG
G2A090000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 9 6.3 700 0.9
dzsc/15/4584/15458463.JPG
G2A120000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 12 8.4 1050 1.2
dzsc/15/4584/15458463.JPG
 ◎
G2A240000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 24 16.8 2080 2.4
dzsc/15/4584/15458463.JPG
G2A031000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 3 2.1 63 0.3
dzsc/15/4584/15458463.JPG
G2A051000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 5 3.5 500 0.5
dzsc/15/4584/15458463.JPG
G2A061000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 6 4.2 500 0.6
dzsc/15/4584/15458463.JPG
G2A081000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 8 5.6 700 0.8
dzsc/15/4584/15458463.JPG
G2A091000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 9 6.3 700 0.9
dzsc/15/4584/15458463.JPG
G2A121000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 12 8.4 1050 1.2
dzsc/15/4584/15458463.JPG
 ◎
G2A241000 2A DPST 100 100G 10 200 VDC 0.5A 1500 VDC 24 16.8 2080 2.4
dzsc/15/4584/15458463.JPG
