供应西码WESTCODE.R系列快速可控硅
| 价 格： | 面议 | |
| 型号/规格： | R0929LS08C R0964LS08D | |
| 品牌/商标： | 西码WESTCODE |
| 老型号 | 新型号 | VDRM /VRRM | ITAVTC=55OC | Tq(us) @200v/us | 尺寸 |
| R219SH08-12 | R0929LS08 -12C(D,E) | 800 | 929 | C15, D20, E25 | 58x34x27 |
| R220SH08-12 | R0964LS08-12 D(E,F) | 800 | 964 | D20,E25, F30 | 58x34x27 |
| R270SH04-08 | R0990lS04 -08A(B,C) | 401 | 990 | A10, B12, C15 | 58x34x27 |
| D315CH32-36 | R1127NC32-36R(S,T) | 3,200 | 1127 | R140,S160,T200 | 74x47x27 |
| R305SH14-21 | R1124NS14-21 K(M) | 1400.1800.2100 | 1124 | K60, M70 | 74x47x27 |
| D350SH24-26 | R1158NS24-26 N(P) | 2,400 | 1158 | N100, P120 | 74x47x27 |
| R350SH08-12 | R1211NS08-12 D(E) | 800 | 1121 | D20, E25 | 74x47x27 |
| R325SH10-14 | R1178NS10-14 E(F,G) | 1,000 | 1178 | E25,F30, G35 | 74x47x27 |
| R355SH08-12 | R1271NS08-12 D(E,G) | 800 1200 | 1271 | D20,E25, G35 | 74x47x27 |
| R395SH14-21 | R1275NS14 -18 L (M) | 1400.1800.2100 | 1275 | L65, M70 | 74x47x27 |
- 所属城市：北京 北京市
- [联系时请说明来自维库仪器仪表网]
- 联系人： 李先生
- 电话：010-87995668-87995880
- 传真：-
- 手机：18600503441
- QQ ：
供应西码WESTCODE.R系列快速可控硅
信息内容：老型号 新型号 VDRM /VRRM ITAVTC=55OC Tq(us) @200v/us 尺寸 R210SH10-12 R0487YS10-14D(E,F) 1000.1400 487 D20,E25 F30 42x25x14 R185SH08-12 R0577YS08-12C(D,E) 800.1200 577 C15, D20,E25 42x25x14 R216SH08-12 R0633YS10-12D(E,F) 1000.1200 633 D20, E25,F30 42x25x14 R181SH14-16 R0717LS14-16G(H,J) 1400.1400 717 G35, H40, J50 58x34x27 R175SH20-25 R0736LS20-25J(K,L,M) 2000.2500 736 J50,K60,L65,M70 58x34x27 R180SH06-10 R0809LS06 -10A (B,C) 600.1000 809 A10,B12, C15 58x34x27 R190SH10-14 R0830LS10-14D(E,F,G) 1000 1400 830 D20,E25F30,G35 58x34x27 R200SH16-21 R0878lS16-21 K(M) 1600.1800.2100 878 K60, M70 58x34x27
供应ABB快速恢复二极管
信息内容：型号 IGCT二极管 技术指标 5SDF03D4502 275A/4500V 60X34X26 5SDF05F4502 435A/4500V 75X47X26 5SDF10H4502 810A/4500V 93.5X62.8X26 5SDF10H4503 1170A/4500V 93.5X62.8X26 5SDF10H4520 1440A/4500V 93.5X62.8X26 5SDF16L4503 1650A/4500V 120X85X26 5SDF02D6004 175A/6000V 60X34X26 5SDF04F6004 380A/6000V 75X47X26 5SDF08H6005 585A/6000V 93.5X62.8X26 5SDF12L6004 1695A/6000V 120X85X26
