电源模块，DC-DC，4-20MA，变送器
| 价 格： | 12.00 | |
| 型号/规格： | B0505S-1W | |
| 品牌/商标： | KSY |
|
FEATURES |
| ||
|
· 7 PIN SIP PACKAGE. · 1000VDC ISOLATION. · UNREGULATED OUTPUT TYPES. · UL 94V-0 PACKAGE MATERIAL. | |||
GENERAL SPECIFICATIONS | |||
|
· OUTPUT RIPPPLE(20MHz Band limited) |
|
ELECTRICAL SPECIFICATIONS | |
|
INPUT 3.3V AND 48V TYP. |
: 150mVp-p MAX | ||
|
INPUT5V,12V AND 24V TYP. |
: 100mVp-p MAX |
· |
:±10% |
|
· ISOLATION RESISTANCE |
:1000MΩ MIN @500VDC |
· OUTPUT VOLTAGE TOLERANCE |
:±5% |
|
· SWITHINGFREQUENCY |
:100KHz TYP. |
· LINE REGULATION(10% TO 100% F.L.) |
:1.2%/1% OF Vin |
|
· OPERATING TEMPERATURE |
: |
· LOAD REGULATION(10% TO 100% F.L.) |
|
|
· EFFICIENCY |
:70% TYP |
3.3V AND 5V OUTPUT TYPES |
:15% MAX |
|
· ISOLATION VOLTAGE |
:1000 VDC |
9V,12V AND 15V OUTPUT TYPES |
:10% MAX |
