供应美国R.M YOUNG85000风速风向传感器
| 价 格： | 面议 | |
| 型号/规格： | 85000 | |
| 品牌/商标： | R.M YOUNG |
风速 测量范围：0 to 70m/s分辨率：0.1m/s 精度：(30 m/s)±2% or 0.1m/s，(70m/s)±3% 风向 测量范围：0 to 360° 分辨率：1°，精度：±2° 串行输出 RS-232，RS-485 格式 ASCII Text，RMYT，NMEA，SDI-12 单位 m/s, MPH,Knots, Km/hr 工作温度 -50 to +50°C 电源 电压 9 to 16 VDC,30 mA typical 电压 24VDC,60W Max.Heater Power:(85004)
Ultrasonic Anemometer
Voltage and Serial Output
Model 85000
The YOUNG Model 85000 Ultrasonic Anemometer is a 2-axis, no-moving-parts wind sensor. It is ideal for general meteorological applications requiring accurate, reliable wind measurement.The sensor features durable, corrosion-resistant construction with opposing pairs of ultrasonic transducers secured in a streamlined molded frame. The 85000 is fully wind-tunnel tested and calibrated to provide accurate wind measurement over a wide operating range. Voltage outputs are provided for wind speed and wind direction. A variety of serial output formats are also available on the standard sensor. The sensor installs on readily available 1 inch (IPS) pipe.
Specifications
Wind Speed: 0 to 70 m/s (0 to 156 mph)
Resolution: 0.1 m/s
Accuracy: ± 2% or 0.1 m/s (30 m/s), ± 3% (70 m/s)
Wind Direction: 0 to 360 degrees
Resolution: 1 degree
Accuracy: ± 2 degrees
Serial Output: RS-232 or RS-485
Formats: ASCII TEXT, RMYT, NMEA, SDI-12
Units: m/s, MPH, Knots, Km/hr
Analog Voltage Outputs:
Wind Speed: 0 to 5000 mV
Wind Direction: 0 to 5000 mV
Power Requirement: 9 to 16 VDC, 30 mA typical (less than 1mA standby)
Operating Temperature: -50 to +50 C
Dimensions: 34cm high x 17cm wide
Weight: 0.7 kg (1.5 lb)
Shipping Weight: 1.6 kg (3.5 lb)
- 所属城市：陕西 西安
- [联系时请说明来自维库仪器仪表网]
- 联系人： 闫先生
- 电话：029-68530853
- 传真：029-62891999-8848
- 手机：18909245289
- QQ ：
供应美国R.M YOUNG 81000VRE风速风向传感器
信息内容：Ultrasonic Anemometer Voltage Inputs Model 81000VRE The YOUNG Model 81000VRE Ultrasonic Anemometer is a 3-axis, no-moving-parts wind sensor with four synchronized voltage input channels and serial output.The VRE model has an extended mast that separates the transducer array from the instrument body. Each sensor is individually wind-tunnel calibrated. Wind and sonic temperature is transmitted serially via RS-232 and RS-485. Signals from up to 4 additional voltage devices may also be included in the serial string. The sensor installs on standard 1 inch pipe. SpecificationsWind Speed: 0 to 40 m/s (0 to 90 mph)Resolution: 0.01 m/sThreshold: 0.01 m/s Accuracy: ± 1% ± 0.05m/s (30 m/s, ± 3% (40 m/s)Wind Direction: 0 to 360 degreesElevation Range: ± 60 degreesResolution: 0.1 degreeAccuracy: ± 2 degrees (30 m/s), ± 5 degrees (40 m/s)Speed of Sound: 300 to 360 m/sResolution: 0.01 m/sAccuracy: ± 0.1% ± 0.05 m/s (30 m/s)Sonic Temperature: -50 to +50 ˚CResolution: 0.01 m/sAccur...
供应美国R.M YOUNG 85106风速风向传感器
信息内容：Ultrasonic Anemometer Marine Model Model 85106 The YOUNG Model 85106 Ultrasonic Anemometer is a 2-axis, no-moving-parts wind sensor with special features for use in the marine environment. The sensor features durable, corrosion-resistant construction with opposing pairs of ultrasonic transducers secured in a reinforced, molded frame. Accessory bird spikes discourage perching on the anemometer. The 85106 is fully wind-tunnel calibrated. As supplied, the sensor is set up to deliver NMEA serial output, compatible with many marine devices. Additional serial outputs as well as voltage outputs are also available. The sensor installs on readily available 1 inch (IPS) pipe. Specifications Wind Speed: 0 to 70 m/s (0 to 156 mph) Resolution: 0.1 m/s Accuracy: ± 2% or 0.1 m/s (30 m/s), ± 3% (70 m/s) Wind Direction: 0 to 360 degrees Resolution: 1 degree Accuracy: ± 2 degrees Serial Output: RS-232 or RS-485 Formats: NMEA, ASCII Text, RMYT, SDI-12 Units: Knots, m/s, MPH, Km/hr Analog Volta...
