供应韩国KOLON科隆0.95全彩oled显示屏
| 价 格： | 面议 | |
| 型号/规格： | 0.95inch | |
| 品牌/商标： | 韩国kolon |
Features
Display Format : 96(W) x R.G.B x 64(H) dots
Display Color : 65K colors
Driver Element : passive matrix OLED(Organic Light Emitting Diode)
Interface : 8bit parallel data with MPU(8080-series MPU)
Multiplexing Ratio : 1/64 Duty
Control IC / Drive IC : SSD1332 (Manufacturer : Solomon systech, Inc)
Polarizer : With Pol.
Applications : Display terminal for mobile phone, MP3 player
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 张勇
- 电话：0755-83849760
- 传真：0755-83849492
- 手机：13602559255
- QQ ：
供应韩国KOLON科隆2.0英寸全彩oled显示屏
信息内容：Features - Display Format : 160(W) x R.G.B. x 128(H) dots - Display Color : 262K/65K colors - Driver Element : passive matrix OLED(Organic Light Emitting Diode) - Interface : 16bits/8bits/6bits parallel data with MPU - Multiplexing Ratio : 1/160 Duty - Control IC / Drive IC : LD7222 (Manufacturer : LDT) - Polarizer : Without Pol - Applications : Display terminal for MP3
供应韩国LG.PHILIPS原装32英寸液晶屏现货
信息内容：General Features Active Screen Size 32 inches(800.4mm) diagonal Outline Dimension 760.0 mm(H) x 450.0 mm(V) x 48.0 mm(D) (Typ.) Pixel Pitch 170.25㎛ x 510.75㎛ x RGB Pixel Format 1366 horiz. by 768 vert. pixels RGB stripe arrangement Color Depth 8bit, 16,7 M colors Viewing Angle (CR>10) Viewing angle free ( R/L 178(Typ.), U/D 178(Typ.)) (0RT polarizer Luminance, White 500 cd/m2 (Center 1 point) (Typ.) Power Consumption Total 87.70Watt (Typ.) (Logic=3.70 W, Lamp=84W [IBL=87mA] Weight 6,150g (Typ.) Display Operating Mode Transmissive mode, normally black Surface Treatment Hard coating(3H), anti-glare treatment of the front polarizer
