供应日本SMK原装进口板对板连接器CPB7324
| 价 格： | 面议 | |
| 型号/规格： | CPB7324-0250F | |
| 品牌/商标： | SMK |
深圳微导科技有限公司是的电子元件供应商,总部设在香港,与国外知名元件厂家建立有稳定的合作关系，为国内外生产厂家及贸易商提供优质，价廉的产品及高效，及时的服务。相信我们的服务及优良的产品一定会使您及您公司如日中天。
dzsc/11/2211/11221150.jpg
Series PB-4A Product Name 0.4mm Pitch Board to Board Connector Parts No. CPB7324-0250F Outline・Feature · Usage Mobile phones, DSCs, etc Standard External Dimension Width: 8.1mm Depth: 2.7mm Height: 0.8mm Packaging Taping/Reel
|
Pitch |
0.4mm |
|
Mating Height |
0.8mm |
|
Number of Pins |
24 |
|
Rating |
AC/DC 50V 0.2A |
|
Contact Resistance |
30mΩ |
|
Insulation Resistance |
100MΩ |
|
Withstanding Voltage |
100V |
|
Operating Temperature Range |
-40℃ ～ 85℃ |
|
Socket Housing |
Thermoplastic Resin, Black |
|
Socket Contact |
Cu Alloy, Au Plating |
|
Socket Hold Down |
Cu Alloy, Sn Plating |
|
Plug Housing |
|
|
Plug Contact |
|
|
Plug Hold Down |
|
|
Socket/Plug |
Socket |
|
Hold Down |
With |
