LED1210PLCC4发白色贴片发光二极管欧西朗
| 价 格： | 面议 | |
| 型号/规格： | LWE67C-U1V2 | |
| 品牌/商标： | OSRAM | |
| 封装形式： | 树脂封装 | |
| 环保类别： | 无铅环保型 | |
| 安装方式： | 贴片 | |
| 功率特性： | | |
| 频率特性： | | |
| 发光颜色： | 白 | |
| 外形尺寸： | mm | |
| 包装方式： | 卷带编带包装 |
LWE67C-U1V2 Package: white P-LCC-4 package colored diffused resin Feature of the device: more brightness due to a lower thermal resistance Color coordinates: x = 0.33, y = 0.33 acc. to CIE 1931 (white) color temperature Typ.: 5600 K Color reproduction index: 80 Viewing angle at 50 % IV: 120°, (Lambertian Emitter) Typ. efficiency: 20.0 lm/W white Grouping parameter: luminous intensity forward voltage color coordinates Soldering Technique: IR reflow soldering TTW soldering ESD-withstand voltage: up to 2 kV acc. to JESD22-A114-D 本公司提供大量国内外LED各大品牌,规格书,相片,技术资料,请登陆:www.southbeam.com
- 所属城市：广东 深圳
- [联系时请说明来自维库仪器仪表网]
- 联系人： 陈创光
- 电话：755-83986189
- 传真：755-83012828
- 手机：13823606811
- QQ ：
LED1210发黄色贴片发光二极管欧西朗
信息内容：LYM676-Q2S1 Hyper Mini TOPLED?, yellow, colorless clear - Lead (Pb) Free - RoHS compliant Package: white SMT package, colorless clear resin Feature of the device: small package 2.3 x 1.3 x 1.4 mm Dominant Wavelength: 587 nm yellow Viewing angle at 50 % IV: 120°, (Lambertian Emitter) Typ. efficiency: 11.0 lm/W yellow Grouping parameter: luminous intensity wavelength Soldering Technique: IR reflow soldering TTW soldering ESD-withstand voltage: up to 2 kV acc. to JESD22-A114-B 本公司提供大量国内外LED各大品牌,规格书,相片,技术资料,请登陆:www.southbeam.com
LED1210发绿色贴片发光二极管
信息内容：LGT670-L1M2 TOPLED?, green, colorless clear - Lead (Pb) Free - RoHS compliant Package: white P-LCC-2 package colorless clear resin Feature of the device: extremely wide viewing angle ideal for backlighting and coupling in light guides Dominant Wavelength: 570 nm green Viewing angle at 50 % IV: 120°, (Lambertian Emitter) Typ. efficiency: 2.5 lm/W green Grouping parameter: luminous intensity wavelength Soldering Technique: TTW soldering, IR reflow soldering ESD-withstand voltage: up to 2 kV acc. to JESD22-A114-D 本公司提供大量国内外LED各大品牌,规格书,相片,技术资料,请登陆:www.southbeam.com
