VM-200T3 粘度计

品牌	ZHILI	型号	VM-200T3
类型	运动粘度计	测量范围	0.5-999（MPa﹒s）
准确度	±2%	装箱数	1

VM-200T2(T3)

VM-200 series are designed as the higher accurate bench type viscometer, with the same torsion-balanced type sensor as FVM-80A series.
With a larger detector, the flow height does not affect the accuracy of measurement as long as the detector is immersed into the fluid, of which feature is different from other VM series.
The measurement accuracy of viscosity is ±2% of reading and Repeatability is ±1%.

TYPEMeasuring MethodMeasuring RangeAccuracyRepeatabilityTemperature RangeCalibrating methodDisplaySystem requirementsAnalog outputDigital outputPower SourceDimensions(mm)
&
weightOptions

VM-200T2·VM-200T3
Torsional Oscillation
L	0.5 - 999mPa.s
M	10.0 - 5,000mPa.s
H	0.50 - 20.0Pa.s
±2%(Reading) *1
±1% *1
0 - 100°C
Calibration with Standrd Liquids for Calibrating Viscometers(JIS Z8809-2000)
3-digit display
10 - 40°C, 20 - 80%RH(Non Dewfall)
4 to 20 mA (each range)
RS-232C
Input AC100-240V 50/60Hz 0.6A Output DC9V 2600mA
Probe(VM200T3)	Ø60×H230[mm] 0.8kg
Controller (VM-200)	W110×H190×D230[mm] 1.7kg
Connecting Cable
AC adapter (UIA324-09)
Instruction Manual
Thermometer
Probe Guard
Stand for measurement
*1 Room temp, liquid temp, 23±3°C, stirred well
