| GENERAL FEATURES & SPECIFICATIONS |
一般功能和规格 |
|
AR-813 |
AR-833 |
AR-823 |
|
| Measuring Range |
1～100,000lux |
0.01～50,000lux |
1～100,000lux |
|
| 测量范围 |
|
| Accuracy |
<4%rgd±0.5%f.s |
<3%rgd±0.5%f.s |
<3%rgd±0.5%f.s |
|
| 测量精确度 |
|
| Unit Selection |
Lux |
Lux |
Lux/Fc |
|
| 单位转换 |
|
| Measure Level Seletion |
Auto |
Auto |
Auto/MANUAL |
|
| 测量档位选择 |
|
| Data Hold Function |
√ |
√ |
√ |
|
| 数据保持显示功能 |
|
| Auto Power Shut Off |
√ |
√ |
√ |
|
| 自动关机功能 |
|
| Low Battery Indication |
√ |
√ |
√ |
|
| 低电显示功能 |
|
| LCD Back Light Selection |
_______ |
_____ |
√ |
|
| 背光显示选择功能 |
|
| Repeatability |
±2% |
±2% |
±2% |
|
| 重复性 |
|
| The Change As Temperature Change |
0.1%/℃ |
0.1%/℃ |
0.1%/℃ |
|
| 温度特性 |
|
| Samping Frequency |
1.5times/sec |
1.5times/sec |
1.5times/sec |
|
| 取样率 |
|
| Resolution |
1Lux |
0.01～1Lux |
1Lux |
|
| 解析度 |
|
| Response Time |
1s |
1s |
1s |
|
| 响应时间 |
|
| Over level Indication |
√ |
√ |
√ |
|
| 过载提示 |
|
| Max And MinReading Hold Function |
____ |
____ |
√ |
|
| 、最小值锁定功能 |
| |
| |
| GENERAL CHARACTERISTICS |
一般特征 |
| Power |
9v Battery |
9v Battery |
9v Battery |
| 供电 |
9v电池 |
9v电池 |
9v电池 |
| LCD size |
48*31.8mm |
48*31.8mm |
59.0*51.0mm |
| LCD尺寸 |
| Product Color |
Dark Gray+black |
balck+yellow |
Dark Gray |
| 产品颜色 |
深灰+黑 |
黑+黄 |
深灰 |
| Product Net Weight |
116.5g |
116.5g |
209.0g |
| 产品净重 |
| Product Size |
166.2*64.0*30.5mm |
166.2*64.0*30.5mm |
151*83*26.5mm |
| 产品尺寸 | |
| |
| PACKING INFORMATION |
包装 |
| 包装方式1(中国) |
彩盒 |
彩盒 |
彩盒 |
| 标准外箱容量 |
40 |
40 |
40 |
| 标准外箱尺寸 |
45.5*44.8*40.5cm |
45.5*44.8*40.5cm |
55.0*45.0*32.5cm |
| 标准外箱毛重 |
9.85kg |
9.85kg |
14.7kg |
| 包装方式2(Other Countries) |
Blister |
Blister |
Blister |
| Standard Quantity Per Carton |
40 |
40 |
40 |
| Standard Carton Size |
36.8*36.8*25.7cm |
36.8*36.8*25.7cm |
37.1*36.5*28.0cm |
| Standard Carton Gross Weight |
11.84kg |
11.84kg |
6.48kg | |
