德国WTW多功能水质分析仪 PhotoFlex

PhotoLab S6 PhotoLab S12

优点：
◆操作简单
◆AQA功能
◆携带方便
◆MemoChip存贮芯片，升级简单
◆浊度修正
◆6/12个干涉滤光片，光电管阵列技术
◆PhotoLab S12具有50种用户自定义方法
简易操作：
◆PhotoLab 系列是专为操作舒适及简单的例行测试而设计，广泛应用在工业过程及污水分析中。开发的光路系统不含移动件，消除了机械磨损，配有的电子线路。当用户打开翻盖后，仪器自动开机，检测光路系统。翻盖不仅有保护作用，上面还有简明操作指南，方便查阅。大尺寸LCD显示内容布局合理，清晰明了，而且在操作中还可显示操作向导。
AutoSelect自动选定：
◆AutoSelect意味着用户不必去担心采用何种测试方法，只要插入标准试剂管，仪器便自动选择相应的测试方法，测试完成后，自动显示测试结果。
MemoChip存贮芯片：
◆MemoChip使仪器升级非常容易，升级时只要引入MemoChip,打开仪器，PhotoLab S6立刻把新的测试方法地贮存在它的指令系统中，从而不必更换EPROM。

PhotoLab S12特有功能：
◆数字键盘使用户可以方便地更改设定值以及设定标识号
◆Autoselector自动选择器用来自动选择用户自定义的测试方法
◆方形比色皿，规格10，20，50mm

技术参数：
◆型号：PhotoLab S6/s12
◆类别：光度计
◆波段：6个/12个
◆准确度：±2 nm
◆半宽：10 nm
◆自动调零：YES
◆AutoSelect：YES
◆自动确认比色管：YES
◆比色管：圆柱形/圆柱形；方形10,20,50mm
◆数据存贮：500组，带日期时间/1000组，带日期时间
◆接口：RS232
◆电池操作状况：一天，放电保护，用变压器作电源时自动充电
◆日期/时间：内置实时钟

仪器介绍 德国WTW的COD测定仪，快速COD测定，操作简单的COD测定仪，携带方便的COD测定仪，此型号COD测定仪是畅销型，COD测定仪……

COD测定仪 自动光度计 PhotoLab S6

可测参数：COD，总硬度，硫化物，重金属(铬,镉,NH4-N,钙,铁,镁,铝,氯,氟,铜,硝酸盐,亚硝酸盐,总氮,磷酸盐,锌,碘,臭氧,铅,镍,钾,硅,硒)

特点：
操作简单
AQA功能
携带方便
波长精确度±2nm
MemoChip存贮芯片，升级简单
浊度修正
6个干涉滤光片，光电二极管阵列技术
适合在实验室、工厂化验室、污水厂中作水质分析及测试COD
可测试多种参数

PhotoLabS6专为操作舒适及简单的例行测试而设计，广泛应用在工业过程及污水分析中
。开发的光路系统不含移动件，消除了机械磨损，配有的电子线路。当用户打开翻
盖后，仪器自动开机，检测光路系统，翻盖不仅有保护作用，上面还有简明操作指南，方便
查阅。大尺寸LCD显示内容布局合理，清晰明了，而且在操作中还可显示操作向导。

AutoSelect自动选定
AutoSelect意味着用户不必去担心采用何种测试方法，只要插入标准试剂管，仪器便自
动选择相应的测试方法，测试完成后，自动显示测试结果。

MemoChip存贮芯片
MemoChip使仪器升级非常容易，升级时只要引入MemoChip,打开仪器，PhotoLabS6立刻把
新的测试方法地贮存在它的指令系统中，从而不必更换EPROM。

WTW是欧洲的环保仪器制造商。成立于1945年，总部位于德国慕尼黑市郊，具有60多年的制造先进物化分析仪器的成功经验。产品技术处于水平，广泛应用于科研、质量控制、水质分析、污水治理等行业，是世界上主要的环保分析仪器和在线监测仪器的生产厂商。如果您没有找到需要的德国WTW产品，请拨免费热线400-7006595联系我们的销售工程师

This page informs about WTW’s proceeding with respect to EC directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE) , implemented into German law by the “Gesetz über das Inverkehrbringen, die Rücknahme und die umweltverträgliche Entsorgung von Elektro- und Elektronikgeräten ( Elektro- und Elektronikgerätegesetz – ElektroG )“.
The statements made below on the disposal of no longer used WTW instruments apply bindingly only for customers inside Germany. Customers in other EC countries should contact their local distributor and/or their local authorities for correspondent information.

One primary goal of the WEEE directive is to minimise the disposal of  WEEE as unsorted municipal waste and to achieve a high level of separate collection and recovery of WEEE.
As a company committed to the protection of the environment WTW supports this goal expressly.
WEEE may contain materials that are harmful to the environment and the human health and should by no means be disposed of together with the municipal waste.

Proper disposal of WTW instruments taken finally out of use
Can WEEE originating from WTW be handed over to the communal collection points for WEEE ?
The answer is expressly no for the following reason:
WTW instruments are designed for professional use and accordingly they have been approved as b2b (business to business) products by the competent german authority Stiftung EAR ( Elektro-Altgeräte Register) , where WTW is registered under WEEE-Reg.-Nr. 35575700. The b2b classifiaction implies that WTW does not have to pick up WEEE at the communal collection points as the ElektroG demands it from the producers of consumer EEE, and consequently our products are excluded from this path of disposal.

Instead we offer our domestic customers to take back no longer used WTW instruments produced from 2006 on and properly dispose them free of charge.
This complies with the announcement of EAR  that the producer’s obligation of disposal in the case of  b2b becomes effective for instruments supplied after 23.03.2006.
The year of production can be identified from the first two figures of the serial number labeled on the instrument, e.g. 06… for 2006.
Instruments for disposal must be sent in with prepaid postage and marked with "ZUR ENTSORGUNG".

As a voluntary service to our customers we also take back instruments from before 2006 free of charge, if a new instrument with comparable function is purchased.
In other cases we reserve the right, to charge a cost-covering disposal fee.
