- 品牌/商标：蓝田恒远
- 企业类型：制造商
- 新旧程度：全新
- 原产地：西安
- SLV21-816\/2210：SLV21-40/16/221
SLV二位三通直动式电磁阀系列
SLV1常闭型系列;SLV2常开型系列
SLV3换向型系列;SLV4通用型系列
SLV5自动排气型系列
SLV1常闭型号规格
| 接管 口径 | 流量 通径 mm | CV值 | 压力差（Kgf/cm2) | 流体 温度 | 线圈 配置 | 功率 | 线圈 等级 | 订货型号以下表中 | ||||||||||
| 小压力 | 工作压力 | VA | W | |||||||||||||||
| 空气 瓦斯 | 水、热水液体 | 轻油≤20CST | ||||||||||||||||
| 阀体 | 顶部 | 阀体 | 顶部 | AC | DC | AC | DC | AC | DC | AC220V | DC24V | 黄铜阀体 | 不锈钢阀体 | |||||
| 1/8” | 1.5 | 1.2 | .07 | 0.05 | 0 | 8 | 5 | 8 | 5 | 8 | 5 | 80 | D | 22 | 13 | F | SLV1DF02N1AV1 | SLV1DF02N3AV1 |
| 2.0 | 1.2 | .14 | 0.05 | 0 | 6 | 5 | 6 | 5 | 6 | 5 | 80 | D | 22 | 13 | F | SLV1DF02N1AV2 | SLV1DF02N3AV2 | |
| 2.5 | 1.2 | .21 | 0.05 | 0 | 5 | 4 | 5 | 4 | 5 | 4 | 80 | D | 22 | 13 | F | SLV1DF02N1AV3 | SLV1DF02N3AV3 | |
| 3.0 | 1.2 | .23 | 0.05 | 0 | 4 | 3 | 4 | 3 | 4 | 3 | 80 | D | 22 | 13 | F | SLV1DF02N1AV4 | SLV1DF02N3AV4 | |
| 1/4” | 1.5 | 1.2 | .07 | 0.05 | 0 | 8 | 5 | 8 | 5 | 8 | 5 | 80 | D | 22 | 13 | F | SLV1DF02N1BV1 | SLV1DF02N3BV1 |
| 2.0 | 1.2 | .14 | 0.05 | 0 | 6 | 5 | 6 | 5 | 6 | 5 | 80 | D | 22 | 13 | F | SLV1DF02N1BV2 | SLV1DF02N3BV2 | |
| 2.5 | 1.2 | .21 | 0.05 | 0 | 5 | 4 | 5 | 5 | 5 | 4 | 80 | D | 22 | 13 | F | SLV1DF02N1BV3 | SLV1DF02N3BV3 | |
| 3.0 | 1.2 | .23 | 0.05 | 0 | 4 | 3 | 4 | 3 | 4 | 3 | 80 | D | 22 | 13 | F | SLV1DF02N1BV4 | SLV1DF02N3BV4 | |
SLV2常开型号规格
| 接管 口径 | 流量 通径 mm | CV值 | 压力差（Kgf/cm2) | 流体 温度 | 线圈 配置 | 功率 | 线圈等级 | 订货型号以下表中电压为 | ||||||||||
| 小 压力 | 工作压力 | VA | W | |||||||||||||||
| 空气 瓦斯 | 水、热水液体 | 轻油≤20CST | ||||||||||||||||
| 阀体 | 顶部 | 阀体 | 顶部 | AC | DC | AC | DC | AC | DC | AC220V | DC24V | 黄铜阀体 | 不锈钢阀体 | |||||
| 1/8” | 1.5 | 1.2 | .07 | 0.05 | 0 | 8 | 5 | 8 | 5 | 8 | 5 | 80 | D | 22 | 13 | F | SLV2DF02N1AV1 | SLV2DF02N3AV1 |
| 2.0 | 1.2 | .14 | 0.05 | 0 | 6 | 5 | 6 | 5 | 6 | 5 | 80 | D | 22 | 13 | F | SLV2DF02N1AV2 | SLV2DF02N3AV2 | |
| 2.5 | 1.2 | .21 | 0.05 | 0 | 5 | 4 | 5 | 4 | 5 | 4 | 80 | D | 22 | 13 | F | SLV2DF02N1AV3 | SLV2DF02N3AV3 | |
| 3.0 | 1.2 | .23 | 0.05 | 0 | 4 | 3 | 4 | 3 | 4 | 3 | 80 | D | 22 | 13 | F | SLV2DF02N1AV4 | SLV2DF02N3AV4 | |
| 1/4” | 1.5 | 1.2 | .07 | 0.05 | 0 | 8 | 5 | 8 | 5 | 8 | 5 | 80 | D | 22 | 13 | F | SLV2DF02N1BV1 | SLV2DF02N3BV1 |
| 2.0 | 1.2 | .14 | 0.05 | 0 | 6 | 5 | 6 | 5 | 6 | 5 | 80 | D | 22 | 13 | F | SLV2DF02N1BV2 | SLV2DF02N3BV2 | |
| 2.5 | 1.2 | .21 | 0.05 | 0 | 5 | 4 | 5 | 5 | 5 | 4 | 80 | D | 22 | 13 | F | SLV2DF02N1BV3 | SLV2DF02N3BV3 | |
| 3.0 | 1.2 | .23 | 0.05 | 0 | 4 | 3 | 4 | 3 | 4 | 3 | 80 | D | 22 | 13 | F | SLV2DF02N1BV4 | SLV2DF02N3BV4 | |
